Icom IC-A25NE

3-2
2. REMOVING THE MAIN/-1 UNIT
Unsolder 11 points on the shield plate, and then 1)
remove it.
MAIN/-1 UNIT
Shield plate
UNSOLDER
Solder
remover
Unsolder a point at the antenna connector.2)
MAIN/-1 UNIT
UNSOLDER
Solder
remover
Remove 11 screws from the MAIN/-1 UNIT, and 3)
then remove it from the chassis.
MAIN/-1 UNIT
Chassis
Screws×11
