Icom IC-A6E Service Manual

5 - 6
SOFTWARE ADJUSTMENT (continued)
ADJUSTMENT ADJUSTMENT CONDITION OPERATION
VOR OFF
(IC-A24 only)
[ ]
1 • Operating frequency: 108.000 MHz
• Connect a VOR tester to the antenna connector and set
as:
Level : –90 dBm* (7.1 µV)
Modulation : 9960 Hz, 10%
30 Hz, 30%
Bearing : 0°
• Receiving
• Push [ENT] key.
VOR PHASE
(IC-A24 only)
[ ]
1 • Operating frequency: 108.000 MHz
• Connect a VOR tester to the antenna connector and set
as:
Level : –60 dBm* (220 µV)
Modulation : 9960 Hz, 30%
30 Hz, 30%
Bearing : 0°
• Receiving
• Push [ENT] key.
Finished. Turn off the radio.
*This output level of a standard signal generator (SSG) is indicated as SSG's open circuit.
