Eqv.= This component is equivalent to the REF No. component listed above, and
may be substituted on parts orders and repairs.
6-1
SECTION 6. PARTS LIST
IC1 1110008450 S.IC ISD8102SYI T&R <MSK> T 94.1/14.7
IC2 1130015760 S.IC TC74VHC4066AFK(EK) T 78.1/31.6
IC3 1110008550 S.IC NJM2904CRB1-TE1-#HMZR T 84.2/23.8
IC4 1110007810 S.IC AK2346AP-L T 69.8/22.3
IC5 1110008550 S.IC NJM2904CRB1-TE1-#HMZR B 40.5/14.2
IC6 1180004430 S.REG XC6209F502MR-G B 33.2/11.4
IC7 1110008550 S.IC NJM2904CRB1-TE1-#HMZR B 50.7/29.0
IC8 1110007620 S.IC NJU7704F3-42A-TE1-#ZZZB B 9.0/10.2
IC9 1140016890 S.IC R4F20335RDFE B 19.1/14.2
IC10 1110007290 S.IC AK2330P-L B 57.1/21.9
IC11 1110008550 S.IC NJM2904CRB1-TE1-#HMZR B 57.5/28.5
IC13 1130016620 S.IC GT24C128A-2ZLI-TR <MSK> B 8.6/28.1
IC14 1130009581 S.IC TC7W66FU(TE12LF) B 25.6/33.7
IC15 1130017460 S.IC AK1542A-L B 19.5/35.9
IC16 1110008392 S.IC SC-1451A (AK2365AM-L) B 55.3/10.4
IC17 1110002751 S.IC TA75S01F(TE85RF) T 85.6/35.0
IC19 1180004430 S.REG XC6209F502MR-G T 100.0/23.3
IC20 1180004430 S.REG XC6209F502MR-G B 97.2/15.1
IC21 1130017430 S.IC NJU6434KS4-TE4-#ZZZB [#05] T 54.3/20.2
1130017430 S.IC NJU6434KS4-TE4-#ZZZB [#06]
1130017430 S.IC NJU6434KS4-TE4-#ZZZB [#07]
1130017430 S.IC NJU6434KS4-TE4-#ZZZB [#08]
1130017430 S.IC NJU6434KS4-TE4-#ZZZB [#09]
1130017430 S.IC NJU6434KS4-TE4-#ZZZB [#10]
1130017430 S.IC NJU6434KS4-TE4-#ZZZB [#11]
1130017430 S.IC NJU6434KS4-TE4-#ZZZB [#12]
1130017430 S.IC NJU6434KS4-TE4-#ZZZB [#13]
IC22 1190003700 S.IC KXCJ9-1008 B 8.0/34.6
IC23 1130014200 S.IC TC7WPB307FK(TE85LF) B 12.3/34.2
IC24 1180004140 S.REG XC6221A302MR-G B 12.5/30.1
Q1 1590004070 S.TRA LDTC144EET1G <SLVJ> B 65.6/41.3
Q2 1590004070 S.TRA LDTC144EET1G <SLVJ> T 78.8/35.8
Q3 1590004220 S.TRA DRA9123Y0L T 85.1/28.5
Q4 1590004070 S.TRA LDTC144EET1G <SLVJ> B 93.4/14.0
Q5 1590004390 S.TRA DMG504010R B 37.0/7.6
Q9 1520000910 S.TRA 2SB1132L-R-AB3-R <SLVJ> T 89.5/7.9
Q10 1590004590 S.TRA DMC506010R B 89.3/8.4
Q14 1560000841 S.FET 2SK1829(TE85RF) [#02] B 89.1/17.3
1560000841 S.FET 2SK1829(TE85RF) [#03]
1560000841 S.FET 2SK1829(TE85RF) [#06]
1560000841 S.FET 2SK1829(TE85RF) [#07]
1560000841 S.FET 2SK1829(TE85RF) [#10]
1560000841 S.FET 2SK1829(TE85RF) [#11]
Q15 1590003490 S.TRA DTA113ZE TL T 90.0/25.0
Q16 1590004310 S.TRA LDTA114EET1G <SLVJ> T 97.5/27.4
Q17 1590003490 S.TRA DTA113ZE TL B 100.3/28.0
Q19 1590004070 S.TRA LDTC144EET1G <SLVJ> B 51.6/34.1
Q20 1590004340 S.TRA DRC9144T0L B 6.7/21.0
Q21 1590004050 S.TRA LDTA144EET1G <SLVJ> T 103.0/22.9
Q22 1590004050 S.TRA LDTA144EET1G <SLVJ> T 102.6/25.7
Q23 1530002851 S.TRA 2SC4116-BL(TE85RF) B 40.3/18.4
Q24 1590004070 S.TRA LDTC144EET1G <SLVJ> B 39.6/39.6
Q25 1530002921 S.TRA 2SC4226-T1 Y25 (R25) B 42.5/27.9
Q27 1530002921 S.TRA 2SC4226-T1 Y25 (R25) B 42.5/35.3
Q28 1590004090 S.TRA LDTC114YET1G <SLVJ> B 32.8/39.6
Q29 1590004090 S.TRA LDTC114YET1G <SLVJ> B 35.2/39.7
Q30 1530003321 S.TRA 2SC5108-Y(TE85RF) B 36.5/23.0
Q31 1530003321 S.TRA 2SC5108-Y(TE85RF) B 40.5/23.9
Q32 1530003321 S.TRA 2SC5108-Y(TE85RF) B 32.1/22.9
Q33 1530003231 S.TRA 2SC5085-Y(TE85RF) [#01] B 57.7/6.5
1530002381 S.TRA 2SC4215-Y(TE85LF) [#02]
1530002381 S.TRA 2SC4215-Y(TE85LF) [#03]
1530003231 S.TRA 2SC5085-Y(TE85RF) [#04]
1530003231 S.TRA 2SC5085-Y(TE85RF) [#05]
1530002381 S.TRA 2SC4215-Y(TE85LF) [#06]
1530002381 S.TRA 2SC4215-Y(TE85LF) [#07]
1530003231 S.TRA 2SC5085-Y(TE85RF) [#08]
1530003231 S.TRA 2SC5085-Y(TE85RF) [#09]
1530002381 S.TRA 2SC4215-Y(TE85LF) [#10]
1530002381 S.TRA 2SC4215-Y(TE85LF) [#11]
1530003231 S.TRA 2SC5085-Y(TE85RF) [#12]
1530003231 S.TRA 2SC5085-Y(TE85RF) [#13]
Q34 1530003321 S.TRA 2SC5108-Y(TE85RF) B 54.5/36.7
Q36 1560001910 S.FET RD01MUS2B-T113 B 61.4/36.7
Q37 1580000731 S.FET 3SK293(TE85LF) B 69.4/18.1
Q38 1560001701 S.FET RD07MUS2B-T214 B 71.2/34.9
Q39 1580000731 S.FET 3SK293(TE85LF) B 84.5/15.8
Q40 1590004050 S.TRA LDTA144EET1G <SLVJ> T 90.0/32.1
Q41 1590004060 S.TRA LDTC114EET1G <SLVJ> [#05] B 23.5/24.8
1590004060 S.TRA LDTC114EET1G <SLVJ> [#06]
1590004060 S.TRA LDTC114EET1G <SLVJ> [#07]
1590004060 S.TRA LDTC114EET1G <SLVJ> [#08]
1590004060 S.TRA LDTC114EET1G <SLVJ> [#09]
1590004060 S.TRA LDTC114EET1G <SLVJ> [#10]
1590004060 S.TRA LDTC114EET1G <SLVJ> [#11]
1590004060 S.TRA LDTC114EET1G <SLVJ> [#12]
1590004060 S.TRA LDTC114EET1G <SLVJ> [#13]
Q42 1590004070 S.TRA LDTC144EET1G <SLVJ> B 90.4/13.0
Q44 1590004070 S.TRA LDTC144EET1G <SLVJ> B 8.3/37.4
D1 1790001860 S.VAR EZJZ0V80010 T 74.6/22.7
D4 1750001810 S.DIO L1SS400T1G <SLVJ> T 95.1/11.3
D5 1790001670 S.DIO RB706F-40T106 T 86.9/26.7
D6 1750001790 S.DIO 1SS390 TE61 B 8.0/18.7
D7 1750001820 S.DIO LRB706F-40T1G <SLVJ> B 4.4/20.8
REF PARTS
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
[MAIN UNIT]
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
S.=Surface mount
REF PARTS
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
[MAIN UNIT]
D9 1750001770 S.VAR 1SV323(TPH3F) B 31.5/26.7
D10 1750002860 S.VAR BBY57-02V H6327 <RYOYO> B 38.0/29.1
D11 1750002860 S.VAR BBY57-02V H6327 <RYOYO> B 35.3/31.5
D12 1750001770 S.VAR 1SV323(TPH3F) B 31.9/33.2
D13 1750001770 S.VAR 1SV323(TPH3F) B 37.4/31.6
D16 1750002990 S.DIO BAR88-02V H6327 <RYOYO> B 45.7/26.3
D17 1750002990 S.DIO BAR88-02V H6327 <RYOYO> B 46.3/23.8
D18 1720000701 S.VAR 1SV305(TPL3F) B 79.5/13.2
D19 1750002990 S.DIO BAR88-02V H6327 <RYOYO> B 83.9/36.0
D20 1750001810 S.DIO L1SS400T1G <SLVJ> T 89.9/34.3
D22 1790001790 S.DIO RB876W TL B 80.2/29.1
D23 1790001790 S.DIO RB876W TL B 82.4/29.1
D24 1750001810 S.DIO L1SS400T1G <SLVJ> [#02] B 90.1/19.8
1750001810 S.DIO L1SS400T1G <SLVJ> [#03]
1750001810 S.DIO L1SS400T1G <SLVJ> [#06]
1750001810 S.DIO L1SS400T1G <SLVJ> [#07]
1750001810 S.DIO L1SS400T1G <SLVJ> [#10]
1750001810 S.DIO L1SS400T1G <SLVJ> [#11]
D25 1750002860 S.VAR BBY57-02V H6327 <RYOYO> B 84.1/24.3
D27 1750002990 S.DIO BAR88-02V H6327 <RYOYO> B 86.2/27.7
D28 1750002990 S.DIO BAR88-02V H6327 <RYOYO> B 57.0/4.6
D29 1720000701 S.VAR 1SV305(TPL3F) B 82.9/13.2
D31 1750002860 S.VAR BBY57-02V H6327 <RYOYO> B 87.7/21.6
D32 1750001770 S.VAR 1SV323(TPH3F) B 32.8/26.7
D33 1750001770 S.VAR 1SV323(TPH3F) B 31.3/34.9
D34 1750001790 S.DIO 1SS390 TE61 T 64.5/14.5
D35 1790001860 S.VAR EZJZ0V80010 T 77.5/21.7
D36 1720000701 S.VAR 1SV305(TPL3F) [#02] B 80.7/13.2
1720000701 S.VAR 1SV305(TPL3F) [#03]
1720000701 S.VAR 1SV305(TPL3F) [#06]
1720000701 S.VAR 1SV305(TPL3F) [#07]
1720000701 S.VAR 1SV305(TPL3F) [#10]
1720000701 S.VAR 1SV305(TPL3F) [#11]
D37 1720000701 S.VAR 1SV305(TPL3F) [#02] B 80.8/10.7
1720000701 S.VAR 1SV305(TPL3F) [#03]
1720000701 S.VAR 1SV305(TPL3F) [#06]
1720000701 S.VAR 1SV305(TPL3F) [#07]
1720000701 S.VAR 1SV305(TPL3F) [#10]
1720000701 S.VAR 1SV305(TPL3F) [#11]
D38 1720000701 S.VAR 1SV305(TPL3F) [#02] B 79.6/10.7
1720000701 S.VAR 1SV305(TPL3F) [#03]
1720000701 S.VAR 1SV305(TPL3F) [#06]
1720000701 S.VAR 1SV305(TPL3F) [#07]
1720000701 S.VAR 1SV305(TPL3F) [#10]
1720000701 S.VAR 1SV305(TPL3F) [#11]
FI1 2030000870 S.MON MFT46.3P3 46.350 MHz
(FL-442) [#01] B 64.8/10.6
2030000150 S.MON DSF753SB 46.350 MHz
(FL-335) [#02]
2030000150 S.MON DSF753SB 46.350 MHz
(FL-335) [#03]
2030000870 S.MON MFT46.3P3 46.350 MHz
(FL-442) [#04]
2030000870 S.MON MFT46.3P3 46.350 MHz
(FL-442) [#05]
2030000150 S.MON DSF753SB 46.350 MHz
(FL-335) [#06]
2030000150 S.MON DSF753SB 46.350 MHz
(FL-335) [#07]
2030000870 S.MON MFT46.3P3 46.350 MHz
(FL-442) [#08]
2030000870 S.MON MFT46.3P3 46.350 MHz
(FL-442) [#09]
2030000150 S.MON DSF753SB 46.350 MHz
(FL-335) [#10]
2030000150 S.MON DSF753SB 46.350 MHz
(FL-335) [#11]
2030000870 S.MON MFT46.3P3 46.350 MHz
(FL-442) [#12]
2030000870 S.MON MFT46.3P3 46.350 MHz
(FL-442) [#13]
X1 6050013800 S.XTA CR-980 14.7456 MHz<SKD> T 64.7/19.3
X2 6050013790 S.XTA CR-981 19.6608 MHz<SKD> B 6.3/12.9
X3 6050013760 S.XTA CR-978 TTS18VSH 15.3 MHz B 47.2/17.2
L2 6200003640 S.COI MLF1608E 100K-T B 34.7/28.6
L3 6190002030 S.COI MLG1608S 1R0J-T B 36.8/28.6
L5 6200007170 S.COI MLF1608A 3R3K-T B 30.2/26.7
L6 6200008090 S.COI LQW2BHN68NJ03L B 36.5/26.5
L7 6200007760 S.COI LQW2BHN82NJ03L B 35.1/34.8
L9 6200012170 S.COI MLG1608S R18J-T B 52.8/18.0
L10 6200012170 S.COI MLG1608S R18J-T B 51.8/13.8
L11 6200007881 S.COI ELJRF 33NJFB B 26.8/25.8
L13 6200011031 S.COI ELJRF R10JFB [#01] B 38.6/23.7
6200011031 S.COI ELJRF R10JFB [#04]
6200011031 S.COI ELJRF R10JFB [#05]
6200011031 S.COI ELJRF R10JFB [#08]
6200011031 S.COI ELJRF R10JFB [#09]
6200011031 S.COI ELJRF R10JFB [#12]
6200011031 S.COI ELJRF R10JFB [#13]
L14 6200011031 S.COI ELJRF R10JFB B 43.3/23.5
L15 6200011031 S.COI ELJRF R10JFB B 32.1/24.4
L16 6200013800 S.COI MLK1005S39NJT B 55.1/38.2
