[CHASSIS PARTS]

REF ORDER

DESCRIPTION

QTY.

NO. NO.

J1 6910021491 ANT CONNECTOR 106-1 <SSC> 1

MP1 8010023300 3620 CHASSIS 1

MP2 8210029770 3621 FRONT PANEL ASSEMBLY [#01] 1

8210029770 3621 FRONT PANEL ASSEMBLY [#02] 1

8210029771 3621 FRONT PANEL ASSEMBLY-1 [#03] 1

8210029770 3621 FRONT PANEL ASSEMBLY [#04] 1

8210029791 3621 S-FRONT PANEL ASSEMBLY-1 [#05] 1

8210029791 3621 S-FRONT PANEL ASSEMBLY-1 [#06] 1

8210029791 3621 S-FRONT PANEL ASSEMBLY-1 [#07] 1

8210029791 3621 S-FRONT PANEL ASSEMBLY-1 [#08] 1

8210029781 3621 T-FRONT PANEL ASSEMBLY-1 [#09] 1

8210029781 3621 T-FRONT PANEL ASSEMBLY-1 [#10] 1

8210029781 3621 T-FRONT PANEL ASSEMBLY-1 [#11] 1

8210029781 3621 T-FRONT PANEL ASSEMBLY-1 [#12] 1

8210029781 3621 T-FRONT PANEL ASSEMBLY-1 [#13] 1

MP6 8930089290 3621 SIDE PLATE Y1318 1

MP7 8930089240 3621 SIDE SEAL (TOP) 1

MP11 8930089300 3621 TOP PLATE 1

MP12 8930089281 3621 MIC SEAL-1 (TOP) 1

MP15 8930088670 3521 VENT SHEET 1

MP16 8930084870 3384 REAR SHEET 1

MP19 8830003440 3285 ANT NUT 1

MP22 8930089260 3621 MAIN SEAL (TOP) 1

MP24 8610014711 KNOB N-421-1 1

MP25 8610014720 KNOB N-422 1

MP26 8930089270 3621 CONTACT RUBBER (TOP) 1

MP30 8930090130 3621 SPONGE 1

MP34 8830001701 VR NUT (Q)-1 2

MP35 8850003420 SEALING WASHER (AA) (TOT) 1

MP39 8930085330 O-RING (CQ) (TOP) 1

MP40 8810010850 PHBT B0 M2X8 SUS SSBC 2

MP41 8810008971 BT M2 X3.5 NI-ZC3 9

MP43 8810007391 PH M2 X 6 SUS SSBC 2

MP44 8810009511 PHBT M2 X 4 NI-ZC3 (3.6-4.0) 1

MP45 8810008761 PHBT M2 X 8 NI-ZC3 2

MP49 8210029630 3621 JACK PANEL 1

MP51 8930090110 THERMAL SHEET (CJ) TC-150CAT-20 (6X6) 1

[MAIN UNIT]

REF ORDER

DESCRIPTION

QTY.

NO. NO.

J1 6450000131 HSJ1102-018540 1

J2 6510025880 TC38-108-01 <CFE> 1

J3* 6510021901 BM02B-ASRS-TF (LF) (SN) 1

F1* 5210001160 ERBRE3R00V 1

DS2 5030003821 EL00624TS9 <SKD> [#05] 1

5030003821 EL00624TS9 <SKD> [#06] 1

5030003821 EL00624TS9 <SKD> [#07] 1

5030003821 EL00624TS9 <SKD> [#08] 1

5030003821 EL00624TS9 <SKD> [#09] 1

5030003821 EL00624TS9 <SKD> [#10] 1

5030003821 EL00624TS9 <SKD> [#11] 1

5030003821 EL00624TS9 <SKD> [#12] 1

5030003821 EL00624TS9 <SKD> [#13] 1

MC1 7700002970 EM6027P-30BC33-G <HOR> 1

S1 2260001900 SW-149 (SKHLLD) 1

S2* 2260003490 TAFG-12W-QR <DIP> 1

S3* 2260003490 TAFG-12W-QR <DIP> 1

S4 2250000900 ED08D13OFT176S065A-1010 <EVT> 1

S5* 2230001060 EVQ-PUL 02K 1

S6* 2260003300 EVQPQHB55 [#09] 1

2260003300 EVQPQHB55 [#10] 1

2260003300 EVQPQHB55 [#11] 1

2260003300 EVQPQHB55 [#12] 1

2260003300 EVQPQHB55 [#13] 1

S7* 2260003300 EVQPQHB55 [#09] 1

2260003300 EVQPQHB55 [#10] 1

2260003300 EVQPQHB55 [#11] 1

2260003300 EVQPQHB55 [#12] 1

2260003300 EVQPQHB55 [#13] 1

S8* 2260003300 EVQPQHB55 [#09] 1

2260003300 EVQPQHB55 [#10] 1

2260003300 EVQPQHB55 [#11] 1

2260003300 EVQPQHB55 [#12] 1

2260003300 EVQPQHB55 [#13] 1

S9* 2260003300 EVQPQHB55 [#05] 1

2260003300 EVQPQHB55 [#06] 1

2260003300 EVQPQHB55 [#07] 1

2260003300 EVQPQHB55 [#08] 1

2260003300 EVQPQHB55 [#09] 1

2260003300 EVQPQHB55 [#10] 1

2260003300 EVQPQHB55 [#11] 1

2260003300 EVQPQHB55 [#12] 1

2260003300 EVQPQHB55 [#13] 1

S10* 2260003300 EVQPQHB55 [#09] 1

2260003300 EVQPQHB55 [#10] 1

2260003300 EVQPQHB55 [#11] 1

2260003300 EVQPQHB55 [#12] 1

2260003300 EVQPQHB55 [#13] 1

S11* 2260003300 EVQPQHB55 [#09] 1

2260003300 EVQPQHB55 [#10] 1

2260003300 EVQPQHB55 [#11] 1

2260003300 EVQPQHB55 [#12] 1

2260003300 EVQPQHB55 [#13] 1

S12* 2260003300 EVQPQHB55 [#09] 1

2260003300 EVQPQHB55 [#10] 1

2260003300 EVQPQHB55 [#11] 1

2260003300 EVQPQHB55 [#12] 1

2260003300 EVQPQHB55 [#13] 1

S13* 2260003300 EVQPQHB55 [#05] 1

2260003300 EVQPQHB55 [#06] 1

2260003300 EVQPQHB55 [#07] 1

2260003300 EVQPQHB55 [#08] 1

2260003300 EVQPQHB55 [#09] 1

2260003300 EVQPQHB55 [#10] 1

2260003300 EVQPQHB55 [#11] 1

2260003300 EVQPQHB55 [#12] 1

2260003300 EVQPQHB55 [#13] 1

S14* 2260003300 EVQPQHB55 [#09] 1

2260003300 EVQPQHB55 [#10] 1

2260003300 EVQPQHB55 [#11] 1

2260003300 EVQPQHB55 [#12] 1

2260003300 EVQPQHB55 [#13] 1

S15* 2260003300 EVQPQHB55 [#09] 1

2260003300 EVQPQHB55 [#10] 1

2260003300 EVQPQHB55 [#11] 1

2260003300 EVQPQHB55 [#12] 1

2260003300 EVQPQHB55 [#13] 1

S16* 2260003300 EVQPQHB55 [#09] 1

2260003300 EVQPQHB55 [#10] 1

2260003300 EVQPQHB55 [#11] 1

2260003300 EVQPQHB55 [#12] 1

2260003300 EVQPQHB55 [#13] 1

SECTION 7

MECHANICAL PARTS

*: Refer to “BOARD LAYOUTS” for the location.

Screw abbreviations A, B0, BT: Self-tapping PH: Pan head ZK: Black NI-ZU: Nickel-Zinc SUS: Stainless

7-1
