2-1
SECTION 2
.
INSIDE VIEWS
• MAIN UNIT
(TOP VIEW)
AF POWER AMP
CONTROLLER (Q9)
VOX AMP
(IC3)
BASEBAND IC
(IC4)
BASEBAND IC CLOCK
(X1)
APC AMP
(IC17)
MIC GAIN CONTROLLER
(IC2)
5 V REGULATOR
(IC19)
AF POWER AMP
(IC1)
