PRECAUTIONS TABLE OF CONTENTS
USE the supplied microphone only. Other microphones have
different pin assignments and may damage the transceiver.
DO NOT use or place the transceiver in areas with tem-
peratures below –25°C or above +55°C, or in areas subject to
direct sunlight, such as the dashboard.
DO NOT operate the transceiver without running the ve-
hicle’s engine. The vehicle’s battery will quickly run out if the
transceiver transmits while the vehicle’s engine OFF.
DO NOT place the transceiver in excessively dusty envi-
ronments.
DO NOT place the transceiver against walls. This will ob-
struct heat dissipation.
DO NOT use of chemical agents such as benzine or alco-
hol when cleaning, as they damage the transceiver surfaces.
BE CAREFUL! The transceiver will become hot when
operating continuously for long periods.
ii
IMPORTANT .......................................................................... i
EXPLICIT DEFINITIONS ....................................................... i
PRECAUTIONS ..................................................................... i
TABLE OF CONTENTS ........................................................ ii
1
PANEL DESCRIPTION ................................................1–6
■ Front panel ...................................................................1
■ Function display ...........................................................2
■ Programmable function keys ........................................3
2
OPERATION ..............................................................7–10
■ Turning power ON ........................................................7
■ Channel selection .........................................................7
■ Receiving and transmitting ...........................................8
3
CONNECTION AND MAINTENANCE ....................11–15
■ Rear panel and connection ........................................11
■Supplied Accessories .................................................12
■Mounting the transceiver ............................................13
■ Optional UT-108 installation .......................................13
■ Optional UT-109 or UT-110 installation .......................14
■ Optional OPC-617 installation ....................................... 14
■ Antenna ......................................................................15
■ Fuse replacement ......................................................15
■ Cleaning .....................................................................15
4
OPTIONS .......................................................................16
5
CE ............................................................................17–18
