S.=Surface mount
Ò: L-band, Ó: H-band, N: N-type, M: M-type, W: W-type
e: ETS/CEPT version, u: EIA/TIA version
[MAIN UNIT]
6-1 IC-F3/F3S
[MAIN UNIT]
IC1 1130007610 S.IC µPD3140GS-E1 (DS8)
IC2 1110003490 S.IC TA31136FN (D,EL)
IC3 1110003780 S.IC NJM2902V-TE1
IC4 1130008090 S.IC BU4066BCFV-E1
IC5 1110001810 S.IC TA7368F (TP1)
IC6 1180001080 S.IC S-81250PG-PD-T1
IC7 1140005620 S.IC X25080SI-2.7T6 [16 ch]
1130008670 S.IC 25LC160T-I/SN [2-BANK]
IC8 1140006460 S.IC HD6433875A40H [16 ch]
1140008380 S.IC HD6433875B26H [2-BANK]
IC10 1110003690 S.IC M62354GP 75EC
IC11 1110003500 S.IC S-80742SL-A6-T1
Q1 1560000950 S.FET 2SK2595AXTB
Q2 1560000960 S.FET 2SK2596BXTL
Q3 1530002920 S.TRANSISTOR 2SC4226-T2 R25
Q4 1530002600 S.TRANSISTOR 2SC4215-O (TE85R)
Q5 1530002600 S.TRANSISTOR 2SC4215-O (TE85R)
Q6 1530002600 S.TRANSISTOR 2SC4215-O (TE85R)
Q7 1530002920 S.TRANSISTOR 2SC4226-T2 R25
Q8 1530002920 S.TRANSISTOR 2SC4226-T2 R25
Q9 1590002160 S.TRANSISTOR XP6401-(TX)
Q11 1530002060 S.TRANSISTOR 2SC4081 T107 R
Q12 1580000720 S.FET 3SK239AXRTL
Q13 1580000490 S.FET 3SK166A-2-T7
Q14 1530002360 S.TRANSISTOR 2SC2714-Y (TE85R)
Q15 1520000460 S.TRANSISTOR 2SB1132 T100 R
Q16 1590001190 S.TRANSISTOR XP6501-(TX).AB
Q17 1590002530 S.TRANSISTOR UN911H(TX)
Q18 1520000460 S.TRANSISTOR 2SB1132 T100 R
Q19 1590001190 S.TRANSISTOR XP6501-(TX).AB
Q20 1510000670 S.TRANSISTOR 2SA1588-GR (TE85R)
Q21 1510000670 S.TRANSISTOR 2SA1588-GR (TE85R)
Q22 1510000670 S.TRANSISTOR 2SA1588-GR (TE85R)
Q23 1530002060 S.TRANSISTOR 2SC4081 T107 R
Q25 1530000160 S.TRANSISTOR 2SC2712-Y (TE85RTEM)
Q26 1590000430 S.TRANSISTOR DTC144EUA T106
Q27 1520000460 S.TRANSISTOR 2SB1132 T100 R
Q28 1530002060 S.TRANSISTOR 2SC4081 T107 R
Q29 1590001770 S.TRANSISTOR XP1213 (TX)
Q31 1590000660 S.TRANSISTOR DTC144TU T107
Q32 1590000430 S.TRANSISTOR DTC144EUA T106
Q33 1590001650 S.TRANSISTOR XP4601 (TX)
Q34 1560000540 S.FET 2SK880-Y (TE85R)
Q35 1530002060 S.TRANSISTOR 2SC4081 T107 R
Q36 1530002060 S.TRANSISTOR 2SC4081 T107 R
Q37 1590000720 S.TRANSISTOR DTA144EUA T106
Q38 1590000430 S.TRANSISTOR DTC144EUA T106
D1 1790000620 S.DIODE MA77 (TX)
D3 1790000620 S.DIODE MA77 (TX)
D4 1790000620 S.DIODE MA77 (TX)
D5 1720000370 S.VARICAP HVU350TRF
D6 1790000620 S.DIODE MA77 (TX)
D7 1720000670 S.VARICAP HVU17TRF
D8 1790000450 S.DIODE MA862 (TX)
D9 1720000370 S.VARICAP HVU350TRF
D10 1720000370 S.VARICAP HVU350TRF
D11 1720000370 S.VARICAP HVU350TRF
D12 1720000370 S.VARICAP HVU350TRF
D13 1720000370 S.VARICAP HVU350TRF
D15 1790001280 S.DIODE MA111 (TX)
D16 1790001200 S.DIODE MA6S121 (TX)
D17 1790001200 S.DIODE MA6S121 (TX)
D18 1790001280 S.DIODE MA111 (TX) F3 only
D19 1790001280 S.DIODE MA111 (TX)
D21 1720000370 S.VARICAP HVU350TRF
D22 1720000370 S.VARICAP HVU350TRF
D24 1750000130 S.DIODE DA204U T107
D25 1790000670 S.DIODE SB07-03C-TB
D26 1160000060 S.DIODE DAN202U T107
D27 1750000130 S.DIODE DA204U T107
D28 1790000620 S.DIODE MA77 (TX)
D29 1730002260 S.ZENER MA8030-H (TX)
FI1 2010002080 XTAL FL-268 (31.05 MHz) N, M
2010002110 XTAL FL-270 (31.05 MHz) W
FI2 2020001410 CERAMIC CFWM450G N
2020001270 CERAMIC CFWM450E M, W
X1 6050009981 XTAL CR-575A (15.3 MHz) e
6050009991 XTAL CR-576A (15.3 MHz) u
X2 6050008840 S.XTAL CR-463 (6.8 MHz)
X3 6070000210
S.DISCRIMINATOR CDBCA450CX24
L1 6110002000 COIL LA-226
L2 6110002040 COIL LA-225
L3 6110002040 COIL LA-225
L4 6200002100 S.COIL LQN 1A 17NJ04
L5 6200005780 S.COIL 33CS-Y655LY-03K=P3
L6 6200002820 S.COIL LQN 1A 47NJ04
L7 6200006980 S.COIL ELJRE R10G-F
L8 6200006980 S.COIL ELJRE R10G-F
L9 6200004600 S.COIL MLF1608D R15K-T Ò
6200006980 S.COIL ELJRE R10G-F Ó
L10 6200004600 S.COIL MLF1608D R15K-T Ò
6200006980 S.COIL ELJRE R10G-F Ó
L11 6200004850 S.COIL MC152-E558CN-100024
L12 6200003090 S.COIL NL 322522T-2R7J-3
L13 6200003960 S.COIL MLF1608A 1R0K-T
L14 6200005740 S.COIL ELJRE 47NG-F Ò
6200007000 S.COIL ELJRE 82NG-F Ó
L15 6200002820 S.COIL LQN 1A 47NJ04
L16 6200007160 S.COIL LQN1H 54NK04
L17 6200007160 S.COIL LQN1H 54NK04
L18 6200002360 S.COIL LQN 1A 33NJ04
L19 6200002360 S.COIL LQN 1A 33NJ04
L20 6200004790 S.COIL MLF1608D R47K-T
L21 6200005740 S.COIL ELJRE 47NG-F
L22 6200002820 S.COIL LQN 1A 47NJ04
L23 6200002370 S.COIL LQN 1A 39NJ04 Ò
6200002360 S.COIL LQN 1A 33NJ04 Ó
L24 6200003090 S.COIL NL 322522T-2R7J-3
L25 6200003960 S.COIL MLF1608A 1R0K-T
L26 6200003590 S.COIL EXCCL3225U1
L27 6200003590 S.COIL EXCCL3225U1
L28 6200006670 S.COIL ELJRE 68NG-F
L29 6200006980 S.COIL ELJRE R10G-F
L30 6200007220 S.COIL EXCCL4532U1
R1 7030003670 S.RESISTOR ERJ3GEYJ 823 V (82 kΩ)
R2 7030005320 S.RESISTOR RR0816P-103-D (10 kΩ)
R3 7030005390 S.RESISTOR RR0816P-102-D (1 kΩ)
R4 7030003240 S.RESISTOR ERJ3GEYJ 220 V (22 Ω)
R5 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω)
R7 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω)
R8 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ) Ò
7030003570 S.RESISTOR ERJ3GEYJ 123 V (12 kΩ) Ó
R9 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R10 7030003250 S.RESISTOR ERJ3GEYJ 270 V (27 Ω) Ò
7030003310 S.RESISTOR ERJ3GEYJ 820 V (82 Ω) Ó
R11 7030003450 S.RESISTOR ERJ3GEYJ 122 V (1.2 kΩ)
R12 7030003500 S.RESISTOR ERJ3GEYJ 332 V (3.3 kΩ)
R13 7030003260 S.RESISTOR ERJ3GEYJ 330 V (33 Ω)
R14 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ)
R15 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω)
R16 7030004050 S.RESISTOR ERJ3GEYJ 1R0 V (1 Ω)
R17 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ)
R18 7030003630 S.RESISTOR ERJ3GEYJ 393 V (39 kΩ)
R19 7030003390 S.RESISTOR ERJ3GEYJ 391 V (390 Ω)
6 - 1
SECTION 6 PARTS LIST
REF ORDER
DESCRIPTION
NO. NO.
REF ORDER
DESCRIPTION
NO. NO.
F3/S
