S.=Surface mount
Ò: L-band, Ó: H-band, N: N-type, M: M-type, W: W-type
e: ETS/CEPT version, u: EIA/TIA version
[MAIN UNIT][MAIN UNIT]
R215 7030005520 S.RESISTOR RR0816R-334-D (330 kΩ)
R216 7030005630 S.RESISTOR RR0816R-154-D (150 kΩ)
R217 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R218 7030003690 S.RESISTOR ERJ3GEYJ 124 V (120 kΩ)
R219 7030003690 S.RESISTOR ERJ3GEYJ 124 V (120 kΩ)
R220 7030003730 S.RESISTOR ERJ3GEYJ 274 V (270 kΩ)
R221 7030003740 S.RESISTOR ERJ3GEYJ 334 V (330 kΩ)
R222 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R224 7030003630 S.RESISTOR ERJ3GEYJ 393 V (39 kΩ) N
7030003620 S.RESISTOR ERJ3GEYJ 333 V (33 kΩ) M, W
R226 7410000950 S.ARRAY EXB-V8V 102JV
R227 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R228 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R229 7030003660 S.RESISTOR ERJ3GEYJ 683 V (68 kΩ)
R230 7030003610 S.RESISTOR ERJ3GEYJ 273 V (27 kΩ)
R231 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R232 7410000950 S.ARRAY EXB-V8V 102JV
R233 7410000950 S.ARRAY EXB-V8V 102JV
R234 7030003600 S.RESISTOR ERJ3GEYJ 223 V (22 kΩ)
R235 7030003780 S.RESISTOR ERJ3GEYJ 684 V (680 kΩ)
R236 7410000950 S.ARRAY EXB-V8V 102JV
R237 7410000950 S.ARRAY EXB-V8V 102JV
R238 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R240 7410000950 S.ARRAY EXB-V8V 102JV
R241 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R242 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R243 7410000950 S.ARRAY EXB-V8V 102JV
R244 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R245 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R249 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R250 7030005320 S.RESISTOR RR0816P-103-D (10 kΩ)
R251 7030003740 S.RESISTOR ERJ3GEYJ 334 V (330 kΩ)
R252 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R253 7030003400 S.RESISTOR ERJ3GEYJ 471 V (470 Ω)
R255 7030003280 S.RESISTOR ERJ3GEYJ 470 V (47 Ω)
R257 7030003800 S.RESISTOR ERJ3GEYJ 105 V (1 MΩ)
R258 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω)
C1 4030006980 S.CERAMIC C1608 CH 1H 070D-T-A
C2 4030009920 S.CERAMIC C1608 CH 1H 050B-T-A
C3 4030009990 S.CERAMIC C1608 CH 1H 200J-T-A
C4 4030009920 S.CERAMIC C1608 CH 1H 050B-T-A
C5 4030007040 S.CERAMIC C1608 CH 1H 180J-T-A
C6 4030007020 S.CERAMIC C1608 CH 1H 120J-T-A Ò
4030007010 S.CERAMIC C1608 CH 1H 100D-T-A Ó
C7 4030007020 S.CERAMIC C1608 CH 1H 120J-T-A Ò
4030007030 S.CERAMIC C1608 CH 1H 150J-T-A Ó
C8 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C9 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C10 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C11 4030007100 S.CERAMIC C1608 CH 1H 560J-T-A
C12 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C13 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C14 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C15 4030007070 S.CERAMIC C1608 CH 1H 330J-T-A
C17 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C18 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C19 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C20 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C21 4510004870 S.ELECTROLYTIC ECEV1CA330P
C22 4030007030 S.CERAMIC C1608 CH 1H 150J-T-A
C23 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C24 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C25 4030007050 S.CERAMIC C1608 CH 1H 220J-T-A
C26 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C27 4030007040 S.CERAMIC C1608 CH 1H 180J-T-A
C28 4030007020 S.CERAMIC C1608 CH 1H 120J-T-A
C29 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C30 4030007050 S.CERAMIC C1608 CH 1H 220J-T-A
C31 4030009920 S.CERAMIC C1608 CH 1H 050B-T-A
C32 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C33 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C34 4030009500 S.CERAMIC C1608 CH 1H 0R5B-T-A
C35 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C36 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C37 4030009520 S.CERAMIC C1608 CH 1H 020B-T-A Ò
4030009510 S.CERAMIC C1608 CH 1H 010B-T-A Ó
C38 4030009540 S.CERAMIC C1608 CH 1H 1R5B-T-A
C39 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C41 4030007080 S.CERAMIC C1608 CH 1H 390J-T-A
C42 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C44 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A Ò
4030008650 S.CERAMIC C1608 JB 1H 332K-T-A Ó
C45 4030010760 S.CERAMIC C1608 CH 1H 331J-T-A Ò
4030007130 S.CERAMIC C1608 CH 1H 101J-T-A Ó
C46 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C47 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C48 4550006170 S.TANTALUM ECST1AY225R
C49 4550006590 S.TANTALUM ECST1CY684R
C50 4550006200 S.TANTALUM ECST0JY106R
C51 4030007030 S.CERAMIC C1608 CH 1H 150J-T-A
C52 4030007050 S.CERAMIC C1608 CH 1H 220J-T-A
C53 4030007020 S.CERAMIC C1608 CH 1H 120J-T-A
C54 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C55 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C56 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C57 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
C58 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
C59 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
C60 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C61 4030007040 S.CERAMIC C1608 CH 1H 180J-T-A Ò
4030007020 S.CERAMIC C1608 CH 1H 120J-T-A Ó
C62 4030007040 S.CERAMIC C1608 CH 1H 180J-T-A Ò
4030007000 S.CERAMIC C1608 CH 1H 090D-T-A Ó
C63 4030007100 S.CERAMIC C1608 CH 1H 560J-T-A
C64 4030007020 S.CERAMIC C1608 CH 1H 120J-T-A
C65 4030009910 S.CERAMIC C1608 CH 1H 040B-T-A
C66 4030007040 S.CERAMIC C1608 CH 1H 180J-T-A
C67 4030007010 S.CERAMIC C1608 CH 1H 100D-T-A
C69 4030007070 S.CERAMIC C1608 CH 1H 330J-T-A
C70 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C71 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C72 4550006150 S.TANTALUM ECST1CY105R
C73 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C75 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C76 4030009990 S.CERAMIC C1608 CH 1H 200J-T-A Ò
4030007040 S.CERAMIC C1608 CH 1H 180J-T-A Ó
C78 4030007010 S.CERAMIC C1608 CH 1H 100D-T-A
C79 4030009910 S.CERAMIC C1608 CH 1H 040B-T-A
C80 4030009920 S.CERAMIC C1608 CH 1H 050B-T-A Ò
4030009350 S.CERAMIC C1608 CH 1H 3R5B-T-A Ó
C81 4030007130 S.CERAMIC C1608 CH 1H 101J-T-A
C82 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C83 4030009510 S.CERAMIC C1608 CH 1H 010B-T-A
C84 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C85 4030007140 S.CERAMIC C1608 CH 1H 121J-T-A
C86 4030007000 S.CERAMIC C1608 CH 1H 090D-T-A Ò
4030009920 S.CERAMIC C1608 CH 1H 050B-T-A Ó
C87 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C88 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C89 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C90 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C91 4030006990 S.CERAMIC C1608 CH 1H 080D-T-A
C92 4030007130 S.CERAMIC C1608 CH 1H 101J-T-A
C93 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C94 4030009520 S.CERAMIC C1608 CH 1H 020B-T-A
C95 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C96 4030007130 S.CERAMIC C1608 CH 1H 101J-T-A
C97 4030006990 S.CERAMIC C1608 CH 1H 080D-T-A
C98 4030009920 S.CERAMIC C1608 CH 1H 050B-T-A
C99 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C100 4030007030 S.CERAMIC C1608 CH 1H 150J-T-A
C101 4030007100 S.CERAMIC C1608 CH 1H 560J-T-A
C102 4030007030 S.CERAMIC C1608 CH 1H 150J-T-A
C104 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C105 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C106 4030007100 S.CERAMIC C1608 CH 1H 560J-T-A
C107 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C108 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C109 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C110 4030011530 S.CERAMIC C1608 CH 1H 110J-T-A N, M
4030007000 S.CERAMIC C1608 CH 1H 090D-T-A W
C111 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C112 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C113 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C114 4030008900 S.CERAMIC C1608 JB 1C 333K-T-A
C115 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C116 4030007130 S.CERAMIC C1608 CH 1H 101J-T-A N
4030007120 S.CERAMIC C1608 CH 1H 820J-T-A M, W
C117 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C118 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
6 - 3
REF ORDER
DESCRIPTION
NO. NO.
REF ORDER
DESCRIPTION
NO. NO.
F3/S
