[L]: L-band, [ML]: ML-band, [MH]: MH-band, [H1]: H1-band, [H2]: H2-band S.=Surface mount
N: N-type, W: W-type, e: ETS/CEPT version, u: EIA/TIA version
[MAIN UNIT]
C436 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C438 4030008630 S.CERAMIC C1608 JF 1C 104Z-T-A
C439 4030008630 S.CERAMIC C1608 JF 1C 104Z-T-A
C440 4030008630 S.CERAMIC C1608 JF 1C 104Z-T-A
C441 4030008630 S.CERAMIC C1608 JF 1C 104Z-T-A
C442 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
C443 4030008920 S.CERAMIC C1608 JB 1C 473K-T-A
C444 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C446 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
C447 4510004420 S.ELECTROLYTIC ECEV0JV330SR
C448 4030007030 S.CERAMIC C1608 CH 1H 150J-T-A
[L], [ML]
4030007020 S.CERAMIC C1608 CH 1H 120J-T-A
[MH]
4030011530 S.CERAMIC C1608 CH 1H 110J-T-A
[H1], [H2]
C449 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
C450 4030009520 S.CERAMIC C1608 CH 1H 020B-T-A N
4030009510 S.CERAMIC C1608 CH 1H 010B-T-A W
C451 4030009990 S.CERAMIC C1608 CH 1H 200J-T-A N
4030006990 S.CERAMIC C1608 CH 1H 080D-T-A W
C452 4030009530 S.CERAMIC C1608 CH 1H 030B-T-A
C454 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C455 4030007010 S.CERAMIC C1608 CH 1H 100D-T-A
[L], [ML], [MH]
4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
[H1], [H2]
C456 4550006200 S.TANTALUM ECST0JY106R
C457 4030009520 S.CERAMIC C1608 CH 1H 020B-T-A
[L], [ML]
C458 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
C459 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
[L], [ML]
4030009910 S.CERAMIC C1608 CH 1H 040B-T-A
[MH], [H1], [H2]
C460 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A N
4030009970 S.CERAMIC C1608 JB 1H 182K-T-A W
C463 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
[L], [ML], [MH]
C464 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C465 4030006870 S.CERAMIC C1608 JB 1H 222K-T-A
C466 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
C467 4610001590 S.TRIMMER TZC03R100A110 10P
C468 4030008680 S.CERAMIC C2012 JF 1C 105Z-T-A
C469 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
C470 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
C471 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
C472 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
C473 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
C474 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C475 4030009350 S.CERAMIC C1608 CH 1H 3R5B-T-A [L]
4030009540 S.CERAMIC C1608 CH 1H 1R5B-T-A [ML]
C476 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
C477 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
C479 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
C481 4030006850 S.CERAMIC C1608 JB 1H 471K-T-A
C482 4030006850 S.CERAMIC C1608 JB 1H 471K-T-A
C483 4030006850 S.CERAMIC C1608 JB 1H 471K-T-A
C486 4030009920 S.CERAMIC C1608 CH 1H 050B-T-A
C487 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
C488 4030006870 S.CERAMIC C1608 JB 1H 222K-T-A
C489 4030008860 S.CERAMIC C1608 JB 1C 153K-T-A
C490 4030007170 S.CERAMIC C1608 CH 1H 221J-T-A
C491 4550006450 S.TANTALUM ECST1EY105R
C492 4030007010 S.CERAMIC C1608 CH 1H 100D-T-A
[L], [ML], [MH]
C493 4030008920 S.CERAMIC C1608 JB 1C 473K-T-A
[L], [ML]
4030008890 S.CERAMIC C1608 JB 1C 273K-T-A
[MH], [H1], [H2]
C496 4030006850 S.CERAMIC C1608 JB 1H 471K-T-A
C497 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
C498 4030007100 S.CERAMIC C1608 CH 1H 560J-T-A
C499 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
C500 4030011810 S.CERAMIC C1608 JB 1A 224K-T-N
J2 6450001680 CONNECTOR HSJ1122-010010
J3 6450001690 CONNECTOR HSJ1456-01-220
J4 6450000870 CONNECTOR HEC2711-01-020
J5 6510018430 S.CONNECTOR AXN330C038P
6 - 11
REF ORDER
DESCRIPTION
NO. NO.
[MAIN UNIT]
J6 6510007080 CONNECTOR PI28A-02M
J7 6910010850 CONNECTOR IMSA-9230B-1-05Z080-T
DS1 5030001460 LCD LM-1462B
DS2 5010000160 S.LED LNJ310M6URA
DS3 5010000160 S.LED LNJ310M6URA
DS4 5040002190 S.LED LNJ808R8ERA
MC1 7700002160 MICROPHONE KUC3523-040245
S1 2230000990 S.SWITCH EVQ-PJ705K
SP1 2510000960 SPEAKER K036NA500-26
W1 7030003860 S.JUMPER ERJ3GE JPW V
W2 7030003860 S.JUMPER ERJ3GE JPW V
W6 7120000480 S.JUMPER MJP-0.4-T
W7 7030003860 S.JUMPER ERJ3GE JPW V [16 ch]
W8 7030003860 S.JUMPER ERJ3GE JPW V [2-BANK]
W12 7030003860 S.JUMPER ERJ3GE JPW V
WS1 8600035811 M.OTHER FX1923 P01MA-1
EP1 0910048568 PCB B 4929H
EP2 8930042590 LCD CONTACT SRCN-1922-SP-N-W
R1 7210002950 VARIABLE RV-312 (RK0971110)
EP1 0910048852 PCB B 4968B
REF ORDER
DESCRIPTION
NO. NO.
[VR BOARD]
REF ORDER
DESCRIPTION
NO. NO.
F4/S
