7
NXDN™ OPERATION
7-8
D Transmitting a Call Alert call
A Call Alert call enables you to notify another user
who may be away from the transceiver that you want
to talk�
(Menu > Signaling/Call > Call Menu)
1� Push [Menu] to display the Menu screen�
2� Push [P2 (Up)] or [P1 (Down)] to select “Signaling/
Call,” then
push [OK]�
Channel/Scan ►
Signaling/Call ►
Menu
3� Push [P2 (Up)] or [P1 (Down)] to select “Call
Menu,” then
push [OK]�
Call List Select ►
Call Menu ►
Signaling/Call
4� Push [P2 (Up)] or [P1 (Down)] to select the
Individual or Group ID, then push [OK]�
✔ Station 1 ►
✔ Group 1 ►
Call Menu
5� Push [P2 (Up)] or [P1 (Down)] to select “Call
Alert,” then push [PTT] to transmit the Call Alert
call�
✔ Write Message ►
✔ Call Alert
Station 1
• “Success” is displayed when an acknowledgment is
received from the targeted station�
• “Failed” is displayed if an acknowledgment is not
received from the targeted station�
TIP: Hold down [Call Alert] for 1 second to transmit
a Call Alert call�
Transmitting a call
D Transmitting a Remote Monitor call
Remote Monitor call enables you to send a signal that
requires the target station to transmit its microphone
audio�
(Menu > Signaling/Call > Call Menu)
1� Push [Menu] to display the Menu screen�
2� Push [P2 (Up)] or [P1 (Down)] to select “Signaling/
Call,” then
push [OK]�
Channel/Scan ►
Signaling/Call ►
Menu
3� Push [P2 (Up)] or [P1 (Down)] to select “Call
Menu,” then
push [OK]�
Call List Select ►
Call Menu ►
Signaling/Call
4� Push [P2 (Up)] or [P1 (Down)] to select the
Individual ID, then push [OK]�
✔ Station 1 ►
✔ Group 1 ►
Call Menu
5� Push [P2 (Up)] or [P1 (Down)] to select “Remote
Monitor,” then push [PTT] to transmit the Remote
Monitor call�
✔ Call Alert
✔ Remote Monitor
Station 1
• “Success” is displayed when an acknowledgment is
received from the targeted station� The microphone
audio can be heard for the preset period of time�
• “Failed” is displayed if an acknowledgment is not
received from the targeted station�
To Next Page
