1
ACCESSORIES
1-5
D Connector cover
CAUTION: BE SURE to attach the connector cover
when an optional device is not in use. Otherwise the
terminals of the multi-connector may be shorted by
a metal object, or become rusty by water intrusion.
This could damage the transceiver.
To attach:
1. Attach the connector cover over the multi-
connector. (q)
2. Tighten the screw. (w)
To detach:
1. Remove the screw. (z)
2. Detach the connector cover, and then connect an
optional device. (x)
Accessory attachments (Continued)
z
x
q
w
To Next Page
