39
9
OPTIONS
VOX gain and delay adjustment
q Attach the connector of the VS-1SC into the [SP/MIC] con-
nector on the transceiver and tighten the screw.
• Toggle the toggle switch to [VOX].
w Enter user set mode. (p. 17)
e Push [P0] several times to select the “VOX Gain” or “VOX
Delay” items. Then, push [Up] or [Down] to set the desired
level/condition.
r Rotate [VOL] to turn the power OFF to exit set mode.
• VOX Gain
The VOX sensitivity level can be adjusted from OFF or 1 to 6
(more sensitive).
• VOX Delay
The VOX delay time can be set from 0.5 to 3.0 sec. (0.5 sec.
step) for a convenient interval before returning to receive.
NOTE: MIC/VOX gain can be adjusted via the Adjusting
pot using a thin screw driver.
