Icom IC-FR3100 Sales Handbook

Operation Example
 Mch Select
Mch Select Mch Select
Mch Select (0017 Default)
This command is available from both the transceiver
both the transceiverboth the transceiver
both the transceiver
and phone line.
and phone line. and phone line.
and phone line. This explanation shows the step
by step operation from the transceiver or operation
from the phone line when entering the password and
command continuously (one after the other).
This command cannot be performed while repeater
is transmitting, therefore you must stop the repeater
operation before selecting a different memory channel.
[From the transceiver]
[From the transceiver][From the transceiver]
[From the transceiver]
① Enter the programmed password from the
transceiver.
Code: ∗0001#
• Verify the repeater replies “System Password OK
ACK (1111).”
• If the repeater replies “NG ACK (4040),” make
sure the password, header tone and de-limiter tone
are correct, and try again.
② Enter the “Repeat Stop” command within 10 sec.
Code: ∗0004#
• Verify the repeater replies “OK ACK (3333).”
• If the 10 sec. input standby time runs out, enter
the password and command continuously (Code:
∗
0001#0004#).
[From the Phone line]
[From the Phone line][From the Phone line]
[From the Phone line]
① Dial the phone number of the phone line that the
repeater is connected to.
② When the connection has been confirmed, enter the
following DTMF code.
Code: ∗0001#0004#
• Verify the repeater replies “OK ACK (3333).”
• If the repeater replies “NG ACK (4040),” make
sure the password, header tone, de-limiter tone
and Repeat Stop code are correct, and try again.
③ Enter the “Mch Select” command followed by sub
code within 10 sec.
Code: ∗0017#07#
(when your intended channel is 07)
• Verify the repeater replies “OK ACK (3333).”
43
∗
0001#0004#).
③ Enter the “Mch Select” command followed by sub
code within 10 sec.
Code: ∗0017#07#
(when your intended channel is 07)
• Verify the repeater replies “OK ACK (3333).”
• If the 10 sec. input standby time runs out, enter
the password and command continuously (Code:
∗0001#0017#07#).
• The repeater changes to the memory channel 7.
④ Enter the “Repeat Start” command within 10 sec.
Code: ∗0003#
• Verify the repeater replies “OK ACK (3333).”
• If the 10 sec. input standby time runs out, enter
the password and command continuously (Code:
∗0001#0003#).
• Verify the repeater replies “OK ACK (3333).”
• If the 10 sec. input standby time runs out, enter
the password and command continuously (Code:
∗0001#0017#07#).
• The repeater changes to the memory channel 7.
④ Enter the “Repeat Start” command within 10 sec.
Code: ∗0003#
• Verify the repeater replies “OK ACK (3333).”
• If the 10 sec. input standby time runs out, enter
the password and command continuously (Code:
∗0001#0003#).
⑤ Hang up the phone, the repeater automatically
disconnects the phone.
