Icom IC-FR4000 - Page 66

9 - 16
The combination of this page and the previous page
shows the unit layout in the same configuration as the
actual P.C. Board.
JACK1 UNIT [FR4100]
¡BOTTOM VIEW
JACK2 UNIT [FR4100]
¡BOTTOM VIEW
to LOGIC UNIT J10
AF GND DISC OUT DC GND AF OUT AF GND E MODG E MOD2 E MOD3 E MODG E DTCS E MODG RSSI
131
J3
+E15V
