INITIAL SET MODE
Entering the Initial Set mode:
Push [P0] to enter the Initial Set mode.
•WhileintheInitialSetmode,push[P0]again
to select an item, and then change the value
or setting by pushing [CH Up] or [CH Down].
Push [PTT] to exit the Initial Set mode.
Initial Set mode items :
Tuning step (TS)
Set the VFO tuning step to 5, 10, 12.5, 15, 20, 25,
30 or 50 kHz.
(1) Push [P0]
•“TS”appears
(2) Push [CH Up] or [CH Down]
to select the desired
tuning step.
Frequency offset (+-)
Set the duplex frequency offset, the transmit frequency
shifts up or down from the receive frequency by the
offset amount.
(1) Push [P0]
•“+-”appears
(2) Push [CH Up] or [CH Down]
to select the desired
frequency offset.
Reversed Duplex function (REV)
Turn the Reversed Duplex function ON or OFF
WhentheReversedDuplexfunctionisON,thereceive
and transmit frequencies are reversed.
(1) Push [P0]
•“REV”appears
(2) Push [CH Up] or [CH Down]
to select the desired
reversed duplex function.
Output power (H/L)
Set the desired output power to H, L2, or L1
The transceiver has 3 output power levels to suit
your operating requirements. Lower output powers
duringshort-distancecommunicationsmayreduce
the possibility of interference to other stations and
will reduce current consumption.
(1) Push [P0]
•“H/L”appears
(2) Push [CH Up] or [CH Down]
to select the desired
output power.
Passband width (W/N)
Set both the transmission and reception passband
width to wide or narrow.
(1) Push [P0]
•“W/N”appears
(2) Push [CH Up] or [CH Down]
to select the desired
passband width.
Repeater tone frequency (rt)
Select the subaudible tone needed to access the
repeater. A total of 51 tone frequencies (67.0 254.1 Hz)
are selectable. (default: 88.5 Hz)
(1) Push [P0]
•“rt”appears
(2) Push [CH Up] or [CH Down]
to select the desired
tuning step.
Tone squelch frequency (ct)
Select the CTCSS tone frequency to use for the Tone
Squelch function. A total of 51 tone frequencies
(67.0–254.1 Hz) are selectable. (default: 88.5 Hz)
(1) Push [P0]
•“ct”appears
(2) Push [CH Up] or [CH Down]
to select the desired
tone squelch frequency.
DTCS Code (dt)
Set the DTCS code (both encoder and decoder) for
DTCS squelch operation. (default: 023)
(1) Push [P0]
•“dt”appears
(2) Push [CH Up] or [CH Down]
to select the desired
DTCS code.
DTCS Polarity (dtP)
Set the Transmit and Receive DTCS polarity to
“NN,”“NR,”“RN”or“RR.”(default:dtP.nn)
NN(TX/RX:normal)
NR (TX: normal, RX: reverse)
RN (TX: reverse, RX: normal)
RR(TX/RX:reverse)
(1) Push [P0]
•“dtP”appears
(2) Push [CH Up] or [CH Down]
to select the desired
DTCS polarity.
TX permission (TX)
Select“OFF”toinhibittransmittingonthechannel.
•tX.OF:Transmitisinhibited.(Receiveonly)
•tX.ON:Transmitispermitted.(default)
(1) Push [P0]
•“TX”appears
(2) Push [CH Up] or [CH Down]
to select the desired
TX permission.
➥
➥
