S.=Surface mount
6 - 2
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
[MAIN UNIT]
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
[MAIN UNIT]
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
R21 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) B 49.7/7.2
R22 7030005210 S.RES ERJ2GEJ 822 X (8.2 k
Ω
) B 45.8/4.5
R31 7030005530 S.RES ERJ2GEJ 100 X (10
Ω
) T 64.1/9.9
R32 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) B 73.2/8.8
R33 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) B 68.8/15.1
R34 7030005530 S.RES ERJ2GEJ 100 X (10
Ω
) T 63.6/11.2
R35 7030008300 S.RES ERJ2GEJ 184 X (180 k
Ω
) T 69.1/20.4
R36 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) T 68.8/21.9
R37 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) T 67.8/19.9
R38 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) T 63.9/23
R39 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) T 66.4/22.9
R40 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
Ω
)
Except [USA] B 65.2/8.3
R41 7030006461 S.RES ERA3YED 152V B 77/9.2
R42 7030006571 S.RES ERA3YED 392V B 75.7/9
R43 7030009320 S.RES ERJ2GEJ 4R7 X (4.7
Ω
) B 76.3/11.4
R47 7030007290 S.RES ERJ2GEJ 222 X (2.2 k
Ω
) B 80.2/3.2
R51 7030006601 S.RES ERA3YED 272V B 74.3/14.3
R52 7030005331 S.RES ERA3YED 562V B 71.3/15.2
R53 7030009320 S.RES ERJ2GEJ 4R7 X (4.7
Ω
) B 72.5/15.6
R61 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
) B 75.3/19.7
R62 7030005070 S.RES ERJ2GEJ 683 X (68 k
Ω
) B 76.3/17.6
R63 7030009320 S.RES ERJ2GEJ 4R7 X (4.7
Ω
) B 72/22.9
R64 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) B 75/23.8
R65 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
) B 75/21.1
R71 7030005070 S.RES ERJ2GEJ 683 X (68 k
Ω
) B 69.1/23.6
R72 7030004990 S.RES ERJ2GEJ 221 X (220
Ω
) B 69.6/21.6
R81 7030007280 S.RES ERJ2GEJ 331 X (330
Ω
) T 72.9/12.9
R82 7030009280 S.RES ERJ2GEJ 391 X (390
Ω
) T 73.5/14.8
R83 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
Ω
) T 70/18.4
R84 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
Ω
) T 69.1/19.4
R91 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) T 80.5/20.2
R92 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
) T 85/16.2
R93 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) T 84.3/17.2
R94 7030005030 S.RES ERJ2GEJ 152 X (1.5 k
Ω
) T 81.2/10.7
R95 7030005000 S.RES ERJ2GEJ 471 X (470
Ω
) T 83.1/10.7
R96 7030007300 S.RES ERJ2GEJ 332 X (3.3 k
Ω
) T 83.1/11.7
R97 7030005530 S.RES ERJ2GEJ 100 X (10
Ω
) T 86.1/11.8
R98 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
) T 80.9/7
R101 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
Ω
) T 91.1/5.1
R102 7030005060 S.RES ERJ2GEJ 333 X (33 k
Ω
) T 91.6/3.7
R103 7030005590 S.RES ERJ2GEJ 680 X (68
Ω
) T 92/6.6
R111 7030003200 S.RES ERJ3GEYJ 100 V (10
Ω
) T 96.9/5.5
R112 7030005530 S.RES ERJ2GEJ 100 X (10
Ω
) T 96.9/4.3
R113 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
Ω
) T 93/4.3
R114 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) T 93/3.2
R121 7030003580 S.RES ERJ3GEYJ 153 V (15 k
Ω
) T 110.2/16.1
R122 7030000280 S.RES MCR10EZHJ 150
Ω
(151) T 112.8/17.3
R131 7030003670 S.RES ERJ3GEYJ 823 V (82 k
Ω
) B 116.7/8.9
R132 7030007340 S.RES ERJ2GEJ 153 X (15 k
Ω
) T 115.4/17.4
R133 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) T 114.4/17.4
R141 7030005100 S.RES ERJ2GEJ 154 X (150 k
Ω
) T 104.3/25.4
R142 7030007350 S.RES ERJ2GEJ 393 X (39 k
Ω
) T 104.8/24
R143 7030007290 S.RES ERJ2GEJ 222 X (2.2 k
Ω
) T 107.7/21.6
R144 7030009140 S.RES ERJ2GEJ 272 X (2.7 k
Ω
) T 109.1/21.2
R145 7030008010 S.RES ERJ2GEJ 123 X (12 k
Ω
) T 109.2/19.8
R146 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) T 107.8/20.3
R147 7030005100 S.RES ERJ2GEJ 154 X (150 k
Ω
) T 106.4/20.8
R148 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
) T 104.8/22.1
R149 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) T 104.2/20.6
R151 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
) B 111.6/13.9
R152 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
)
[GEN], [EUR], [UK] B 114.8/17.5
7030005220 S.RES ERJ2GEJ 223 X (22 k
Ω
) [USA] B 114.8/17.5
R153 7030005110 S.RES ERJ2GEJ 224 X (220 k
Ω
) B 108.9/22.2
R154 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) B 107.4/23.2
R155 7030005110 S.RES ERJ2GEJ 224 X (220 k
Ω
) B 103.1/23.4
R156 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) B 101.7/23.8
R165 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) [USA] B 98.1/19.3
7030008290 S.RES ERJ2GEJ 183 X (18 k
Ω
)
[GEN], [EUR], [UK] B 98.1/19.3
R166 7030005100 S.RES ERJ2GEJ 154 X (150 k
Ω
)
[GEN], [EUR], [UK] B 97/16.6
7030005700 S.RES ERJ2GEJ 274 X (270 k
Ω
) [USA] B 97/16.6
R167 7030005000 S.RES ERJ2GEJ 471 X (470
Ω
) B 98.6/21.4
R171 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) B 100.2/22.4
R172 7030005170 S.RES ERJ2GEJ 474 X (470 k
Ω
) B 101.9/18.6
R173 7030009290 S.RES ERJ2GEJ 562 X (5.6 k
Ω
) B 100.8/16.6
R174 7030007060 S.RES ERJ2GEJ 684X (680 k
Ω
)
Except [USA] B 96/16.6
R175 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) B 99.1/19.3
R181 7030009270 S.RES ERJ2GEJ 821 X (820
Ω
) B 92.7/17.4
R182 7030005110 S.RES ERJ2GEJ 224 X (220 k
Ω
) B 93.1/23.7
R183 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) B 93.7/25.4
R184 7030005110 S.RES ERJ2GEJ 224 X (220 k
Ω
) B 90.5/23.7
R185 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) B 91.4/25.1
R191 7030005710 S.RES ERJ2GEJ 121 X (120
Ω
) B 87.2/23.4
R192 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
) B 85.2/22
R193 7030007300 S.RES ERJ2GEJ 332 X (3.3 k
Ω
) B 82.8/17.8
R194 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k
Ω
) B 87.2/16.8
R201 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) T 84.8/23.7
R202 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) T 83.5/22.8
R203 7030005000 S.RES ERJ2GEJ 471 X (470
Ω
) T 87.2/22
R204 7030010430 S.RES ERJ2GEJ 120 X (12
Ω
) T 85.9/20.8
R205 7030005000 S.RES ERJ2GEJ 471 X (470
Ω
) T 86.4/19.5
R206 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
Ω
) B 85.9/16.5
R211 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) B 85.9/25.2
R213 7030005030 S.RES ERJ2GEJ 152 X (1.5 k
Ω
)
[GEN], [EUR], [UK] T 88.3/38.5
7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) [USA] T 88.3/38.5
R214 7030005000 S.RES ERJ2GEJ 471 X (470
Ω
) T 85/35.9
R215 7030005310 S.RES ERJ2GEJ 124 X (120 k
Ω
) T 86.3/38.5
R216 7030005010 S.RES ERJ2GEJ 681 X (680
Ω
) T 86.6/36.8
R221 7030007060 S.RES ERJ2GEJ 684X (680 k
Ω
) B 63.3/29.8
R222 7030007570 S.RES ERJ2GEJ 122 X (1.2 k
Ω
) B 62.3/29.8
R223 7030007270 S.RES ERJ2GEJ 151 X (150
Ω
) B 81.3/38.2
R231 7030007300 S.RES ERJ2GEJ 332 X (3.3 k
Ω
) T 80.6/35
R232 7030004970 S.RES ERJ2GEJ 470 X (47
Ω
) T 83.1/35.9
R233 7030007340 S.RES ERJ2GEJ 153 X (15 k
Ω
) T 76.1/43.4
R234 7030005220 S.RES ERJ2GEJ 223 X (22 k
Ω
) T 71.9/39.2
R235 7030005220 S.RES ERJ2GEJ 223 X (22 k
Ω
) T 72.5/36
R236 7030009320 S.RES ERJ2GEJ 4R7 X (4.7
Ω
) T 73.9/39.3
R237 7030008010 S.RES ERJ2GEJ 123 X (12 k
Ω
) T 71.9/38.2
R238 7030007340 S.RES ERJ2GEJ 153 X (15 k
Ω
) T 78.5/37.6
R239 7030005230 S.RES ERJ2GEJ 334 X (330 k
Ω
) B 80.7/34.3
R240 7030005600 S.RES ERJ2GEJ 273 X (27 k
Ω
) B 78.2/33.2
R241 7030007290 S.RES ERJ2GEJ 222 X (2.2 k
Ω
) B 82.9/36
R242 7030009280 S.RES ERJ2GE B 73.1/33.2
R243 7030009320 S.RES ERJ2GEJ 4R7 X (4.7
Ω
) T 71.9/37.2
R244 7030007290 S.RES ERJ2GEJ 222 X (2.2 k
Ω
) T 82.6/34.6
R245 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) T 85.1/32.2
R246 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) T 86.8/31.1
R247 7030007570 S.RES ERJ2GEJ 122 X (1.2 k
Ω
)
[USA], [GEN] B 81.9/32.3
7030009140 S.RES ERJ2GEJ 272 X (2.7 k
Ω
)
[EUR], [UK] B 81.9/32.3
R251 7030005000 S.RES ERJ2GEJ 471 X (470
Ω
) B 57.8/18.3
R261 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
Ω
) B 62.8/36.5
R262 7030008010 S.RES ERJ2GEJ 123 X (12 k
Ω
) B 61.2/39.2
R263 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) B 60.8/37.8
R264 7030005210 S.RES ERJ2GEJ 822 X (8.2 k
Ω
) B 60.9/40.2
R264 7030010040 S.RES ERJ2GE-JPW B 60.9/40.2
R265 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) B 58.6/37.8
R266 7030009290 S.RES ERJ2GEJ 562 X (5.6 k
Ω
) B 59.8/38.3
R267 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) B 63.5/41.1
R269 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 57.6/37.8
R270 7030007340 S.RES ERJ2GEJ 153 X (15 k
Ω
) B 60.9/43.3
R271 7030005720 S.RES ERJ2GEJ 563 X (56 k
Ω
) B 63.4/43.1
R272 7030005100 S.RES ERJ2GEJ 154 X (150 k
Ω
) B 60.7/44.7
R273 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) B 59.7/45.3
R274 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) B 62.1/44.5
R275 7030008300 S.RES ERJ2GEJ 184 X (180 k
Ω
) T 56.6/41.3
R276 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) T 56.9/44.9
R277 7030006610 S.RES ERJ2GEJ 394 X (390 k
Ω
) T 55.5/43.5
R281 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) T 62.2/38.8
R282 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) T 57.8/35.7
R283 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) T 58.9/44.3
R284 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) T 59.7/35.7
R291 7030005070 S.RES ERJ2GEJ 683 X (68 k
Ω
) T 61.5/34.1
R292 7030005070 S.RES ERJ2GEJ 683 X (68 k
Ω
) T 62/32
R293 7030005070 S.RES ERJ2GEJ 683 X (68 k
Ω
) T 61/32
R294 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) T 63.4/29.6
R296 7030007340 S.RES ERJ2GEJ 153 X (15 k
Ω
) T 60/34.3
R297 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) T 56.1/31.7
R298 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
Ω
) T 56.6/29.4
R305 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) T 60.5/30.5
R306 7030005070 S.RES ERJ2GEJ 683 X (68 k
Ω
) T 59.2/30.2
R307 7030007570 S.RES ERJ2GEJ 122 X (1.2 k
Ω
) T 57.1/32.2
R321 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) T 93.5/21.4
R322 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
Ω
) T 91.5/23.2
R323 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) T 95.4/22.2
R324 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
Ω
) T 95.1/23.7
R325 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) T 97.8/26.5
R326 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
Ω
) T 96.8/26.5
R381 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) B 35.4/30.3
R382 7030005720 S.RES ERJ2GEJ 563 X (56 k
Ω
) B 33.2/29.6
R383 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 35.6/32
R384 7030008290 S.RES ERJ2GEJ 183 X (18 k
Ω
) B 30.6/34.1
R385 7030007300 S.RES ERJ2GEJ 332 X (3.3 k
Ω
) B 33/38.4
R386 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 36/35.7
R387 7030005160 S.RES ERJ2GEJ 105 X (1 M
Ω
) B 9.8/41.7
R388 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) B 7.2/40.2
R389 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) B 7.3/36.6
R390 7030010040 S.RES ERJ2GE-JPW [USA] only B 62.9/10.4
R391 7030010040 S.RES ERJ2GE-JPW T 83/14.8
R393 7030010040 S.RES ERJ2GE-JPW T 82.5/6.4
R394 7030010040 S.RES ERJ2GE-JPW T 89.2/4
R398 7030010040 S.RES ERJ2GE-JPW B 60.6/41.5
R399 7030010040 S.RES ERJ2GE-JPW T 58.9/42.5
R411 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) T 98.7/31.4
R412 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) T 94.3/32
R413 7030005060 S.RES ERJ2GEJ 333 X (33 k
Ω
) T 94.3/30.1
R414 7030007310 S.RES ERJ2GEJ 155 X (1.5 M
Ω
) T 99.2/29
R415 7030007310 S.RES ERJ2GEJ 155 X (1.5 M
Ω
) T 97.2/29
R421 7030005530 S.RES ERJ2GEJ 100 X (10
Ω
) T 107/33.5
R422 7030005530 S.RES ERJ2GEJ 100 X (10
Ω
) B 104.4/38.7
To Next Page
Loading...
