S.=Surface mount
6 - 3
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
[MAIN UNIT]
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
[MAIN UNIT]
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
R431 7030005600 S.RES ERJ2GEJ 273 X (27 k
Ω
) T 106.1/27.6
R432 7030005160 S.RES ERJ2GEJ 105 X (1 M
Ω
) T 107.6/27.1
R433 7030007290 S.RES ERJ2GEJ 222 X (2.2 k
Ω
) T 109.4/33
R434 7030007290 S.RES ERJ2GEJ 222 X (2.2 k
Ω
) T 105.8/29.6
R435 7030007300 S.RES ERJ2GEJ 332 X (3.3 k
Ω
) T 108.1/32.1
R441 7030005170 S.RES ERJ2GEJ 474 X (470 k
Ω
) T 100.7/41
R442 7030005170 S.RES ERJ2GEJ 474 X (470 k
Ω
) T 96.7/38.3
R443 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) T 99.5/39.9
R461 7030005060 S.RES ERJ2GEJ 333 X (33 k
Ω
) B 94.3/48.5
R462 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
Ω
) B 47.8/44.6
R463 7030009290 S.RES ERJ2GEJ 562 X (5.6 k
Ω
) B 50.3/42.8
R467 7030008280 S.RES ERJ2GEJ 271 X (270
Ω
) B 97.3/40.8
R468 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 90.5/40.4
R471 7030007060 S.RES ERJ2GEJ 684X (680 k
Ω
) B 51.7/43.1
R472 7030008290 S.RES ERJ2GEJ 183 X (18 k
Ω
) B 56.2/38.3
R473 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
Ω
) B 50.7/44.2
R474 7030009290 S.RES ERJ2GEJ 562 X (5.6 k
Ω
) B 50.2/40.3
R475 7030010310 S.RES ERJ3GEYF 223 V (22 k
Ω
) B 58/35.5
R476 7030004740 S.RES ERJ3GEYF 392 V (3.9 k
Ω
) B 57.2/33.5
R477 7030004730 S.RES ERJ3GEYF 222 V (2.2 k
Ω
) B 60.7/35.5
R481 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 47.3/35.4
R482 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 42.3/39
R490 7030005720 S.RES ERJ2GEJ 563 X (56 k
Ω
) B 39.3/37.5
R491 7030007340 S.RES ERJ2GEJ 153 X (15 k
Ω
) B 41.1/37.4
R492 7030005110 S.RES ERJ2GEJ 224 X (220 k
Ω
) B 37.4/25.8
R493 7030008310 S.RES ERJ2GEJ 564 X (560 k
Ω
) B 39.1/36.2
R494 7030005250 S.RES ERJ3GEYF 103 V (10 k
Ω
) B 44.4/33.6
R495 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
Ω
) B 38.5/31.3
R496 7030005110 S.RES ERJ2GEJ 224 X (220 k
Ω
) B 38/29.3
R497 7030008300 S.RES ERJ2GEJ 184 X (180 k
Ω
) B 39.4/24.7
R498 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 39.4/25.7
R501 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 43.5/31
R502 7030005060 S.RES ERJ2GEJ 333 X (33 k
Ω
) B 40.7/27.3
R503 7030005310 S.RES ERJ2GEJ 124 X (120 k
Ω
) B 38/27.2
R504 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) B 44.6/29.7
R511 7030005600 S.RES ERJ2GEJ 273 X (27 k
Ω
) B 33/23.6
R512 7030005100 S.RES ERJ2GEJ 154 X (150 k
Ω
) B 36.6/28
R513 7030008290 S.RES ERJ2GEJ 183 X (18 k
Ω
) B 32.6/25.6
R521 7030005010 S.RES ERJ2GEJ 681 X (680
Ω
) B 45.1/31.1
R531 7030005220 S.RES ERJ2GEJ 223 X (22 k
Ω
) B 34.6/18.9
R532 7030005220 S.RES ERJ2GEJ 223 X (22 k
Ω
) B 33.4/15.5
R533 7030005720 S.RES ERJ2GEJ 563 X (56 k
Ω
) B 34.1/16.5
R534 7030008300 S.RES ERJ2GEJ 184 X (180 k
Ω
) B 34.1/17.5
R535 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) B 35.5/17.3
R536 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) B 36.3/18.9
R537 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) B 36.3/20.8
R538 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) B 35/23.4
R539 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) B 39.3/21.3
R540 7030007340 S.RES ERJ2GEJ 153 X (15 k
Ω
) B 39.3/22.3
R551 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) B 99.9/36.5
R552 7030007290 S.RES ERJ2GEJ 222 X (2.2 k
Ω
) B 100.4/35
R553 7030005220 S.RES ERJ2GEJ 223 X (22 k
Ω
) B 100.5/33.5
R561 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) T 100.3/21.8
R562 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
Ω
) T 98.7/23.4
R571 7030005930 S.RES ERJ3GEYF 334 V (330 k
Ω
) B 105.2/30
R572 7030008090 S.RES ERJ3EKF 1503 V (150 k
Ω
) B 103.1/27.3
R581 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) B 9.2/12.3
R583 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) T 6.4/34.4
R584 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) T 6.9/33
R591 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) B 10.7/12.1
R592 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) B 8/9.6
R601 7030005530 S.RES ERJ2GEJ 100 X (10
Ω
) T 6.6/17.4
R602 7030005160 S.RES ERJ2GEJ 105 X (1 M
Ω
) T 6.1/18.9
R603 7030008010 S.RES ERJ2GEJ 123 X (12 k
Ω
) T 7.8/15
R604 7030008010 S.RES ERJ2GEJ 123 X (12 k
Ω
) T 6.5/14.4
R605 7030008010 S.RES ERJ2GEJ 123 X (12 k
Ω
) T 7.3/10.3
R606 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) T 6.8/8.8
R611 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) T 54.8/42.5
R612 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
Ω
) T 54.3/44.8
R631 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) B 25.5/7.6
R632 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 23.9/5.2
R633 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) B 15.9/6.7
R634 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) B 23.9/7.1
R635 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) B 17.1/5.8
R636 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) B 14.7/5.3
R637 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) B 14.3/6.6
R638 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) B 13.7/9.6
R639 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) B 12.7/9.8
R651 7030007280 S.RES ERJ2GEJ 331 X (330
Ω
)
[USA], [GEN] T 63.1/4.3
7030005010 S.RES ERJ2GEJ 681 X (680
Ω
) [Others] T 63.1/4.3
R652 7030004990 S.RES ERJ2GEJ 221 X (220
Ω
) T 62.1/3.8
R653 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) T 15.8/38.2
R654 7030005010 S.RES ERJ2GEJ 681 X (680
Ω
) T 14.8/38.2
R656 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) T 16.3/11.8
R657 7030005010 S.RES ERJ2GEJ 681 X (680
Ω
) T 15.3/11.8
R658 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) T 16.2/22.7
R659 7030005010 S.RES ERJ2GEJ 681 X (680
Ω
) T 15.2/22.7
R662 7030007280 S.RES ERJ2GEJ 331 X (330
Ω
)
[USA], [GEN] T 68.9/4.3
7030005010 S.RES ERJ2GEJ 331 X (680
Ω
) [Others] T 68.9/4.3
R663 7030004990 S.RES ERJ2GEJ 221 X (220
Ω
) T 70.3/3.3
R681 7030009150 S.RES ERJ2GEJ 824 X (820 k
Ω
) B 12.7/27.2
R682 7030005700 S.RES ERJ2GEJ 274 X (270 k
Ω
) B 6.6/26.5
R683 7030006610 S.RES ERJ2GEJ 394 X (390 k
Ω
) B 12/29.3
R684 7030003830 S.RES ERJ3GEYJ 185 V (1.8 M
Ω
) B 13.2/29.7
R685 7030007340 S.RES ERJ2GEJ 153 X (15 k
Ω
) B 8.4/31.4
R686 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) B 8.1/33.2
R687 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) B 5.4/31.3
R688 7030005080 S.RES ERJ2GEJ 823 X (82 k
Ω
) B 4.3/34.2
R689 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) B 3.6/33.2
R690 7030010040 S.RES ERJ2GE-JPW B 47.7/31.3
R691 7030010040 S.RES ERJ2GE-JPW B 50.7/30.5
R692 7030010040 S.RES ERJ2GE-JPW T 5.4/38.7
R693 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) T 119.6/20.5
R694 7030005170 S.RES ERJ2GEJ 474 X (470 k
Ω
) B 28.2/11.2
R695 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 88.9/47.7
R696 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 41.2/40.8
R697 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 48.2/40.8
R698 7030007340 S.RES ERJ2GEJ 153 X (15 k
Ω
) B 40.3/45.6
R699 7030005230 S.RES ERJ2GEJ 334 X (330 k
Ω
) B 38.3/45.6
R700 7030007570 S.RES ERJ2GEJ 122 X (1.2 k
Ω
) B 38.8/40.6
R701 7030006610 S.RES ERJ2GEJ 394 X (390 k
Ω
) B 36.9/40.6
R702 7030005220 S.RES ERJ2GEJ 223 X (22 k
Ω
) B 34.8/44.5
R703 7030003830 S.RES ERJ3GEYJ 185 V (1.8 M
Ω
) B 33.3/43.3
R704 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 11/31.1
R705 7030008290 S.RES ERJ2GEJ 183 X (18 k
Ω
) B 49.9/37.5
R706 7030008090 S.RES ERJ3EKF 1503 V (150 k
Ω
) B 44.4/35
R707 7030005210 S.RES ERJ2GEJ 822 X (8.2 k
Ω
) B 49.9/38.5
R708 7030008410 S.RES ERJ2GEJ 392 X (3.9 k
Ω
) B 49.8/36
R709 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
Ω
) B 50.3/41.8
R710 7030005210 S.RES ERJ2GEJ 822 X (8.2 k
Ω
) B 51.7/40.1
R711 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 56.2/37.1
R712 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
Ω
) B 52.6/37.9
R715 7030010040 S.RES ERJ2GE-JPW B 24.9/5.7
R717 7030010040 S.RES ERJ2GE-JPW B 28.9/10.1
R718 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) B 92.7/42.9
R720 7030010040 S.RES ERJ2GE-JPW B 45/45.5
C1 4030016930 S.CER ECJ0EB1A104K B 51/17.8
C2 4030016930 S.CER ECJ0EB1A104K B 52.6/17.8
C3 4030017460 S.CER ECJ0EB1E102K B 53.6/17.8
C4 4030017420 S.CER ECJ0EC1H470J B 55.8/16.4
C5 4030016930 S.CER ECJ0EB1A104K B 42.6/7.5
C6 4030018560 S.CER C2012 JB 1A 475K-T B 46.5/20
C10 4030016930 S.CER ECJ0EB1A104K B 46.3/8.8
C11 4030017460 S.CER ECJ0EB1E102K B 45.3/8.8
C12 4030007010 S.CER C1608 CH 1H 100D-T B 48.2/9.1
C13 4030017430 S.CER ECJ0EC1H101J B 51.2/10.6
C14 4030017460 S.CER ECJ0EB1E102K B 55.5/15.4
C16 4550006300 S.TAN ECST1AY475R B 51.6/6.7
C17 4550006160 S.TAN ECST1CY155R B 58/8.2
C19 4030017460 S.CER ECJ0EB1E102K B 45.3/5.8
C20 4030017460 S.CER ECJ0EB1E102K B 50/5.7
C21 4030017460 S.CER ECJ0EB1E102K B 44.8/4.5
C31 4030007040 S.CER C1608 CH 1H 180J-T B 69.8/12
C32 4030007000 S.CER C1608 CH 1H 090D-T B 67.6/14.9
C33 4030007070 S.CER C1608 CH 1H 330J-T B 65.9/18
C34 4030017460 S.CER ECJ0EB1E102K T 67.8/21.9
C35 4030017730 S.CER ECJ0EB1E471K T 65.4/22.9
C36 4030018860 S.CER ECJ0EB0J105K T 61.9/23
C37 4030009540 S.CER C1608 CH 1H 1R5B-T T 67.2/17.7
C38 4030018860 S.CER ECJ0EB0J105K Except [USA] B 63.2/8.3
C39 4030009920 S.CER C1608 CH 1H 050B-T Except [USA] B 66.7/9.9
C40 4030009350 S.CER C1608 CH 1H 3R5B-T Except [USA] B 64.1/10
C41 4030009550 S.CER C1608 CH 1H 2R5B-T B 74.4/9
C42 4030007090 S.CER C1608 CH 1H 470J-T B 74.4/11
C43 4030007020 S.CER C1608 CH 1H 120J-T B 74.4/12.3
C44 4030017730 S.CER ECJ0EB1E471K B 78.5/9.3
C45 4030016790 S.CER ECJ0EB1C103K B 78.5/8.3
C46 4030009560 S.CER C1608 CH 1H R75B-T B 78.7/14.6
C47 4550006700 S.TAN ECST1AY106R B 83.3/3
C48 4550006700 S.TAN ECST1AY106R B 74.1/3.6
C51 4030009560 S.CER C1608 CH 1H R75B-T B 68.8/18.9
C52 4030009920 S.CER C1608 CH 1H 050B-T B 70/14.9
C52 4030011770 S.CER C1608 CH 1H 060B-T B 70/14.9
C53 4030007050 S.CER C1608 CH 1H 220J-T B 71.7/17.2
C54 4030007040 S.CER C1608 CH 1H 180J-T B 71.7/18.5
C55 4030017730 S.CER ECJ0EB1E471K B 76.9/14.5
C56 4030016790 S.CER ECJ0EB1C103K B 76.9/15.5
C57 4030009500 S.CER C1608 CH 1H 0R5B-T B 74.4/18.1
C61 4030017460 S.CER ECJ0EB1E102K B 78.3/19.5
C62 4030006980 S.CER C1608 CH 1H 070D-T B 72.7/21
C63 4030017460 S.CER ECJ0EB1E102K B 73/23.8
C64 4030016930 S.CER ECJ0EB1A104K B 74/23.8
C65 4030007040 S.CER C1608 CH 1H 180J-T B 78.7/23
C71 4030009550 S.CER C1608 CH 1H 2R5B-T B 70.8/22.7
C72 4030017460 S.CER ECJ0EB1E102K B 68.1/23.6
C73 4030006990 S.CER C1608 CH 1H 080D-T B 66.5/21.1
C74 4030007100 S.CER C1608 CH 1H 560J-T B 64.4/23.6
C75 4030007100 S.CER C1608 CH 1H 560J-T B 63.1/23.6
C81 4030007020 S.CER C1608 CH 1H 120J-T T 74.9/10.9
C82 4030007020 S.CER C1608 CH 1H 120J-T T 75.1/17.7
C83 4030017420 S.CER ECJ0EC1H470J T 74.8/19.4
C84 4030016930 S.CER ECJ0EB1A104K T 69.3/17.1
