[MAIN-E UNIT]
R126 7030005420 S.RESISTOR ERJ3GEYJ 202 V (2 kΩ) B
R127 7030005420 S.RESISTOR ERJ3GEYJ 202 V (2 kΩ) B
R141 7030003220 S.RESISTOR ERJ3GEYJ 150 V (15 Ω) T
R146 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ) B
R147 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω) B
R149 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ) T
R150 7030003630 S.RESISTOR ERJ3GEYJ 393 V (39 kΩ) T
R151 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ) T
R152 7030003340 S.RESISTOR ERJ3GEYJ 151 V (150 Ω) T
R153 7030004050 S.RESISTOR ERJ3GEYJ 1R0 V (1 Ω) T
R154 7030003390 S.RESISTOR ERJ3GEYJ 391 V (390 Ω) T
R155 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ) B
R161 7030003860 S.RESISTOR ERJ3GE JPW V T
R162 7030003860 S.RESISTOR ERJ3GE JPW V T
R163 7030003860 S.RESISTOR ERJ3GE JPW V T
R164 7030003860 S.RESISTOR ERJ3GE JPW V T
R165 7030003860 S.RESISTOR ERJ3GE JPW V T
R166 7030003860 S.RESISTOR ERJ3GE JPW V T
R167 7030003860 S.RESISTOR ERJ3GE JPW V B
R168 7030003860 S.RESISTOR ERJ3GE JPW V B
R171 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ) B
R172 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ) B
R173 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ) B
R176 7030003820 S.RESISTOR ERJ3GEYJ 155 V (1.5 MΩ) T
R177 7030003600 S.RESISTOR ERJ3GEYJ 223 V (22 kΩ) T
R178 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ) T
R181 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ) T
R182 7030003200 S.RESISTOR ERJ3GEYJ 100 V (10 Ω) T
R183 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ) T
R185 7030003460 S.RESISTOR ERJ3GEYJ 152 V (1.5 kΩ) B
R201 7030003460 S.RESISTOR ERJ3GEYJ 152 V (1.5 kΩ) B
R202 7030003400 S.RESISTOR ERJ3GEYJ 471 V (470 Ω) B
R203 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ) B
R204 7030003460 S.RESISTOR ERJ3GEYJ 152 V (1.5 kΩ) B
R205 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ) T
R206 7030003390 S.RESISTOR ERJ3GEYJ 391 V (390 Ω) B
R207 7030003460 S.RESISTOR ERJ3GEYJ 152 V (1.5 kΩ) T
R208 7030003460 S.RESISTOR ERJ3GEYJ 152 V (1.5 kΩ) T
R212 7030003430 S.RESISTOR ERJ3GEYJ 821 V (820 Ω) B
R213 7030003620 S.RESISTOR ERJ3GEYJ 333 V (33 kΩ) B
R214 7310002760 S.TRIMMER RV-152 (RH03A3AJ4X0HA) 223 T
R215 7510001660 S.THRMISTOR NTCG16 4LH 473KT T
R216 7030003550 S.RESISTOR ERJ3GEYJ 822 V (8.2 kΩ) T
R218 7030003620 S.RESISTOR ERJ3GEYJ 333 V (33 kΩ) T
R219 7030003400 S.RESISTOR ERJ3GEYJ 471 V (470 Ω) B
R221 7030003760 S.RESISTOR ERJ3GEYJ 474 V (470 kΩ) B
R222 7030003570 S.RESISTOR ERJ3GEYJ 123 V (12 kΩ) B
R223 7030003490 S.RESISTOR ERJ3GEYJ 272 V (2.7 kΩ) B
R224 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ) B
R225 7030003660 S.RESISTOR ERJ3GEYJ 683 V (68 kΩ) B
R226 7030003570 S.RESISTOR ERJ3GEYJ 123 V (12 kΩ) B
R227 7510001550 S.THERMISTOR NTCG16 4LH 333KT B
R231 7030003580 S.RESISTOR ERJ3GEYJ 153 V (15 kΩ) T
R232 7030003580 S.RESISTOR ERJ3GEYJ 153 V (15 kΩ) T
R233 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ) T
R234 7030003760 S.RESISTOR ERJ3GEYJ 474 V (470 kΩ) T
R235 7030003720 S.RESISTOR ERJ3GEYJ 224 V (220 kΩ) T
R236 7030003390 S.RESISTOR ERJ3GEYJ 391 V (390 Ω) T
R237 7030003490 S.RESISTOR ERJ3GEYJ 272 V (2.7 kΩ) T
R241 7030003800 S.RESISTOR ERJ3GEYJ 105 V (1 MΩ) T
R243 7030003800 S.RESISTOR ERJ3GEYJ 105 V (1 MΩ) T
R246 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ) B
R252 7030003800 S.RESISTOR ERJ3GEYJ 105 V (1 MΩ) T
R257 7030003490 S.RESISTOR ERJ3GEYJ 272 V (2.7 kΩ) T
R261 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ) T
R262 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ) T
R291 7030003550 S.RESISTOR ERJ3GEYJ 822 V (8.2 kΩ) T
R292 7030003600 S.RESISTOR ERJ3GEYJ 223 V (22 kΩ) T
R293 7030003590 S.RESISTOR ERJ3GEYJ 183 V (18 kΩ) T
R294 7030003200 S.RESISTOR ERJ3GEYJ 100 V (10 Ω) T
R301 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ) B
R302 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ) B
R303 7030003480 S.RESISTOR ERJ3GEYJ 222 V (2.2 kΩ) B
R304 7030003660 S.RESISTOR ERJ3GEYJ 683 V (68 kΩ) B
R305 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ) B
R306 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ) B
R307 7030003530 S.RESISTOR ERJ3GEYJ 562 V (5.6 kΩ) B
R308 7030003750 S.RESISTOR ERJ3GEYJ 394 V (390 kΩ) B
R309 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ) B
R311 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ) B
R312 7030003700 S.RESISTOR ERJ3GEYJ 154 V (150 kΩ) B
R313 7030003700 S.RESISTOR ERJ3GEYJ 154 V (150 kΩ) B
R314 7030003770 S.RESISTOR ERJ3GEYJ 564 V (560 kΩ) B
R315 7030003860 S.RESISTOR ERJ3GE JPW V B
R316 7030003670 S.RESISTOR ERJ3GEYJ 823 V (82 kΩ) B
R317 7030003670 S.RESISTOR ERJ3GEYJ 823 V (82 kΩ) B
R318 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ) B
R323 7030003630 S.RESISTOR ERJ3GEYJ 393 V (39 kΩ) B
S.=Surface mount
6 - 2
REF ORDER
DESCRIPTION M.
NO. NO.
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
[MAIN-E UNIT]
R324 7510001670 S.THRMISTOR NTCG16 4BH 103KT T
R325 7030003570 S.RESISTOR ERJ3GEYJ 123 V (12 kΩ) T
R326 7030003580 S.RESISTOR ERJ3GEYJ 153 V (15 kΩ) T
R327 7310002600 S.TRIMMER RV-110 (RH03A3AS4X0AA) 473 T
R328 7030003550 S.RESISTOR ERJ3GEYJ 822 V (8.2 kΩ) T
R341 7030003600 S.RESISTOR ERJ3GEYJ 223 V (22 kΩ) B
R351 7030003580 S.RESISTOR ERJ3GEYJ 153 V (15 kΩ) B
R352 7030003450 S.RESISTOR ERJ3GEYJ 122 V (1.2 kΩ) B
R353 7030003800 S.RESISTOR ERJ3GEYJ 105 V (1 MΩ) T
R354 7030003580 S.RESISTOR ERJ3GEYJ 153 V (15 kΩ) T
R355 7030009920 S.RESISTOR ERJ3GEYJ 335 V (3.3 MΩ) T
R356 7030000100 S.RESISTOR MCR10EZHJ 4.7 Ω (4R7) B
R381 7030001040 S.RESISTOR MCR50JZHJ 18 Ω (180) T
R382 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ) T
R383 7030003410 S.RESISTOR ERJ3GEYJ 561 V (560 Ω) T
R384 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ) T
R385 7030003480 S.RESISTOR ERJ3GEYJ 222 V (2.2 kΩ) T
R386 7030003510 S.RESISTOR ERJ3GEYJ 392 V (3.9 kΩ) B
R387 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ) B
R401 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω) T
R411 7030003410 S.RESISTOR ERJ3GEYJ 561 V (560 Ω) B
R412 7030003600 S.RESISTOR ERJ3GEYJ 223 V (22 kΩ) B
R413 7030003620 S.RESISTOR ERJ3GEYJ 333 V (33 kΩ) B
R414 7030003480 S.RESISTOR ERJ3GEYJ 222 V (2.2 kΩ) B
R415 7030003630 S.RESISTOR ERJ3GEYJ 393 V (39 kΩ) B
R416 7030003670 S.RESISTOR ERJ3GEYJ 823 V (82 kΩ) B
R417 7030003580 S.RESISTOR ERJ3GEYJ 153 V (15 kΩ) B
C1 4030008880 S.CERAMIC C1608 JB 1H 223K-T T
C2 4030006900 S.CERAMIC C1608 JB 1H 103K-T T
C3 4030011600 S.CERAMIC C1608 JB 1E 104K-T T
C4 4550000510 S.TANTALUM TEESVA 1V 473M8L B
C5 4550006560 S.TANTALUM ECST1CY225R B
C7 4030006860 S.CERAMIC C1608 JB 1H 102K-T T
C11 4030007020 S.CERAMIC C1608 CH 1H 120J-T T
C12 4610001590 S.TRIMMER TZC3R100A110R00 T
C13 4030007040 S.CERAMIC C1608 CH 1H 180J-T T
C21 4510004630
S.ELECTROLYTIC
ECEV1CA100SR T
C22 4030006900 S.CERAMIC C1608 JB 1H 103K-T B
C23 4030006860 S.CERAMIC C1608 JB 1H 102K-T B
C24 4030011340 S.CERAMIC C1608 CH 1H 471J-T B
C25 4550006700 S.TANTALUM ECST1AY106R B
C26 4030006900 S.CERAMIC C1608 JB 1H 103K-T T
C27 4030017490 S.CERAMIC C1608 JB 1A 105K-T T
C28 4030006860 S.CERAMIC C1608 JB 1H 102K-T B
C29 4030011340 S.CERAMIC C1608 CH 1H 471J-T B
C31 4030011340 S.CERAMIC C1608 CH 1H 471J-T T
C32 4030009920 S.CERAMIC C1608 CH 1H 050B-T T
C33 4030007050 S.CERAMIC C1608 CH 1H 220J-T T
C34 4030007060 S.CERAMIC C1608 CH 1H 270J-T T
C35 4030007060 S.CERAMIC C1608 CH 1H 270J-T T
C36 4030006860 S.CERAMIC C1608 JB 1H 102K-T T
C41 4030007080 S.CERAMIC C1608 CH 1H 390J-T T
C42 4030007090 S.CERAMIC C1608 CH 1H 470J-T T
C43 4550006130 S.TANTALUM ECST1VY224R T
C44 4030006860 S.CERAMIC C1608 JB 1H 102K-T T
C45 4030009540 S.CERAMIC C1608 CH 1H 1R5B-T T
C46 4030009540 S.CERAMIC C1608 CH 1H 1R5B-T T
C47 4030006860 S.CERAMIC C1608 JB 1H 102K-T T
C48 4030011340 S.CERAMIC C1608 CH 1H 471J-T T
C49 4030011340 S.CERAMIC C1608 CH 1H 471J-T T
C51 4030009500 S.CERAMIC C1608 CH 1H 0R5B-T T
C52 4030011340 S.CERAMIC C1608 CH 1H 471J-T T
C55 4030006860 S.CERAMIC C1608 JB 1H 102K-T T
C56 4030007020 S.CERAMIC C1608 CH 1H 120J-T T
C57 4030011340 S.CERAMIC C1608 CH 1H 471J-T T
C58 4030007070 S.CERAMIC C1608 CH 1H 330J-T T
C74 4030006900 S.CERAMIC C1608 JB 1H 103K-T B
C75 4030006860 S.CERAMIC C1608 JB 1H 102K-T T
C77 4030009910 S.CERAMIC C1608 CH 1H 040B-T T
C81 4030006860 S.CERAMIC C1608 JB 1H 102K-T T
C82 4030006860 S.CERAMIC C1608 JB 1H 102K-T T
C83 4030007090 S.CERAMIC C1608 CH 1H 470J-T T
C84 4030007040 S.CERAMIC C1608 CH 1H 180J-T T
C85 4030007040 S.CERAMIC C1608 CH 1H 180J-T T
C86 4030006860 S.CERAMIC C1608 JB 1H 102K-T T
C87 4030007090 S.CERAMIC C1608 CH 1H 470J-T T
C88 4030006860 S.CERAMIC C1608 JB 1H 102K-T T
C91 4030007040 S.CERAMIC C1608 CH 1H 180J-T T
C93 4030006860 S.CERAMIC C1608 JB 1H 102K-T T
C94 4030009530 S.CERAMIC C1608 CH 1H 030B-T T
C95 4030006860 S.CERAMIC C1608 JB 1H 102K-T T
C96 4030007090 S.CERAMIC C1608 CH 1H 470J-T T
C97 4030011340 S.CERAMIC C1608 CH 1H 471J-T T
C98 4030007090 S.CERAMIC C1608 CH 1H 470J-T B
C99 4030011340 S.CERAMIC C1608 CH 1H 471J-T B
C100 4030007010 S.CERAMIC C1608 CH 1H 100D-T B
REF ORDER
DESCRIPTION M.
NO. NO.
