[MAIN-E UNIT][MAIN-E UNIT]
IC1 1130007610 S.IC µPD3140GS-E1 (DS8) T
IC2 1110003200 S.IC TA31136FN (EL) T
IC3 1150002080 IC RA35H1516M-01 T
IC4 1130007300 S.IC TC4W66FU (TE12L) T
IC7 1110000960 S.IC NJM4558M-T1 B
IC8 1110000960 S.IC NJM4558M-T1 B
IC9 1110003090 IC LA4425A T
IC10 1110002020 IC TA7805S T
IC11 1120002830 S.IC NJM2125F-TE1 B
Q1 1530002850 S.TRANSISTOR 2SC4116-BL (TE85R) T
Q2 1590000430 S.TRANSISTOR DTC144EUA T106 B
Q3 1530002600 S.TRANSISTOR 2SC4215-O (TE85R) T
Q4 1530002920 S.TRANSISTOR 2SC4226-T1 R25 T
Q5 1530002920 S.TRANSISTOR 2SC4226-T1 R25 T
Q6 1530002600 S.TRANSISTOR 2SC4215-O (TE85R) T
Q7 1530002600 S.TRANSISTOR 2SC4215-O (TE85R) T
Q10 1530002920 S.TRANSISTOR 2SC4226-T1 R25 T
Q12 1530002240 S.TRANSISTOR 2SC3775-3-TB T
Q13 1510000920 S.TRANSISTOR 2SA1577 T106 Q T
Q15 1590000430 S.TRANSISTOR DTC144EUA T106 T
Q16 1590000670 S.TRANSISTOR FMW1 T148 T
Q17 1590000430 S.TRANSISTOR DTC144EUA T106 B
Q21 1580000540 S.FET 3SK131-T2-LA T
Q22 1580000540 S.FET 3SK131-T2-LA T
Q23 1530002360 S.TRANSISTOR 2SC2714-Y (TE85R) B
Q31 1530002850 S.TRANSISTOR 2SC4116-BL (TE85R) T
Q34 1590000430 S.TRANSISTOR DTC144EUA T106 T
Q41 1590000430 S.TRANSISTOR DTC144EUA T106 B
Q51 1510000670 S.TRANSISTOR 2SA1588-GR (TE85R) T
Q52 1590000430 S.TRANSISTOR DTC144EUA T106 T
Q53 1510000920 S.TRANSISTOR 2SA1577 T106 Q T
Q54 1590000430 S.TRANSISTOR DTC144EUA T106 T
Q55 1520000460 S.TRANSISTOR 2SB1132 T100 R T
Q56 1530002850 S.TRANSISTOR 2SC4116-BL (TE85R) T
Q61 1530002850 S.TRANSISTOR 2SC4116-BL (TE85R) B
D1 1790000620 S.DIODE MA77 (TX) B
D2 1790000620 S.DIODE MA77 (TX) B
D3 1750000710 S.VARICAP HVC350BTRF T
D4 1750000710 S.VARICAP HVC350BTRF T
D7 1790000620 S.DIODE MA77 (TX) B
D8 1790000620 S.DIODE MA77 (TX) B
D12 1790000690 S.DIODE HSM88ASR-TR B
D13 1790000690 S.DIODE HSM88ASR-TR B
D14 1710001080 DIODE XB15A308 T
D21 1710001080 DIODE XB15A308 T
D24 1790001210 S.DIODE 1SS375-TL B
D25 1720000260 S.VARICAP 1SV214 (TPH2) B
D26 1720000260 S.VARICAP 1SV214 (TPH2) B
D27 1720000260 S.VARICAP 1SV214 (TPH2) B
D28 1720000260 S.VARICAP 1SV214 (TPH2) B
D31 1750000550 S.DIODE 1SS355 TE-17 T
D41 1750000130 S.DIODE DA204U T106 B
D42 1790000700 DIODE DSA3A1 T
D43 1750000550 S.DIODE 1SS355 TE-17 B
FI1 2030000350 MONOLITH 21R15AB (FL-368) T
FI2 2030000270 MONOLITH FL-363 (21.7 MHz) T
FI3 2020001520 CERAMIC CFWLA450KFFA-B0 T
FI4 2040001440 S.LC NFE31PT152Z1E9L T
FI5 2040001440 S.LC NFE31PT152Z1E9L T
X1 6050011760 S.XTAL CR-768 (21.250 MHz) T
X2 6070000190
S.DISCRIMINATOR
CDBCB450KCAY24-R0 T
L1 6200009560 S.COIL MLG1608B R10J-T T
L2 6200010840 S.COIL MLG1608B 56NJ-T T
L3 6200003090 S.COIL NL 322522T-2R7J-3 T
L4 6200008190 S.COIL 0.25-1.9-8TL 80N T
L6 6200009560 S.COIL MLG1608B R10J-T T
L7 6200010840 S.COIL MLG1608B 56NJ-T T
L11 6200009560 S.COIL MLG1608B R10J-T T
L12 6200009560 S.COIL MLG1608B R10J-T T
L14 6200005740 S.COIL ELJRE 47NG-F T
S.=Surface mount
L15 6200002430 S.COIL NL 252018T-082J T
L16 6200009620 S.COIL MLG1608B 68NJ-T T
L17 6200002600 S.COIL NL 252018T-047J T
L18 6200002600 S.COIL NL 252018T-047J T
L19 6110001600 COIL LA-243 T
L20 6170000230 COIL LW-25 T
L21 6110001600 COIL LA-243 T
L22 6110001600 COIL LA-243 T
L31 6110001600 COIL LA-243 T
L35 6150003820 COIL LS-440 T
L36 6150003820 COIL LS-440 T
L38 6150003820 COIL LS-440 T
L39 6150003820 COIL LS-440 T
L42 6200010090 S.COIL ELJND R82JF T
R1 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ) B
R2 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ) B
R3 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ) B
R4 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ) B
R5 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ) T
R6 7030003380 S.RESISTOR ERJ3GEYJ 331 V (330 Ω) T
R7 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ) B
R8 7030003200 S.RESISTOR ERJ3GEYJ 100 V (10 Ω) B
R9 7030003480 S.RESISTOR ERJ3GEYJ 222 V (2.2 kΩ) B
R10 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ) B
R11 7030003380 S.RESISTOR ERJ3GEYJ 331 V (330 Ω) T
R21 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ) T
R22 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ) B
R23 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ) B
R24 7030003410 S.RESISTOR ERJ3GEYJ 561 V (560 Ω) B
R25 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω) B
R26 7030003620 S.RESISTOR ERJ3GEYJ 333 V (33 kΩ) T
R27 7030003600 S.RESISTOR ERJ3GEYJ 223 V (22 kΩ) T
R28 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ) T
R31 7030003400 S.RESISTOR ERJ3GEYJ 471 V (470 Ω) T
R32 7030003660 S.RESISTOR ERJ3GEYJ 683 V (68 kΩ) T
R34 7030003300 S.RESISTOR ERJ3GEYJ 680 V (68 Ω) B
R36 7030003290 S.RESISTOR ERJ3GEYJ 560 V (56 Ω) T
R41 7030003410 S.RESISTOR ERJ3GEYJ 561 V (560 Ω) T
R42 7030003550 S.RESISTOR ERJ3GEYJ 822 V (8.2 kΩ) T
R43 7030003550 S.RESISTOR ERJ3GEYJ 822 V (8.2 kΩ) T
R44 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω) T
R45 7030003390 S.RESISTOR ERJ3GEYJ 391 V (390 Ω) T
R46 7030003350 S.RESISTOR ERJ3GEYJ 181 V (180 Ω) T
R51 7030003420 S.RESISTOR ERJ3GEYJ 681 V (680 Ω) T
R52 7030003660 S.RESISTOR ERJ3GEYJ 683 V (68 kΩ) T
R55 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω) T
R56 7030003610 S.RESISTOR ERJ3GEYJ 273 V (27 kΩ) T
R74 7030003480 S.RESISTOR ERJ3GEYJ 222 V (2.2 kΩ) B
R81 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ) B
R82 7030003270 S.RESISTOR ERJ3GEYJ 390 V (39 Ω) T
R83 7030003480 S.RESISTOR ERJ3GEYJ 222 V (2.2 kΩ) T
R84 7030003390 S.RESISTOR ERJ3GEYJ 391 V (390 Ω) T
R85 7030003200 S.RESISTOR ERJ3GEYJ 100 V (10 Ω) T
R86 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ) T
R87 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ) T
R88 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω) T
R91 7030003480 S.RESISTOR ERJ3GEYJ 222 V (2.2 kΩ) T
R92 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω) T
R93 7030003240 S.RESISTOR ERJ3GEYJ 220 V (22 Ω) T
R94 7030003240 S.RESISTOR ERJ3GEYJ 220 V (22 Ω) T
R95 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ) T
R96 7030003270 S.RESISTOR ERJ3GEYJ 390 V (39 Ω) T
R97 7030003280 S.RESISTOR ERJ3GEYJ 470 V (47 Ω) B
R103 7030003800 S.RESISTOR ERJ3GEYJ 105 V (1 MΩ) B
R104 7030003400 S.RESISTOR ERJ3GEYJ 471 V (470 Ω) T
R107 7030003500 S.RESISTOR ERJ3GEYJ 332 V (3.3 kΩ) T
R110 7030003530 S.RESISTOR ERJ3GEYJ 562 V (5.6 kΩ) T
R111 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ) T
R112 7030003480 S.RESISTOR ERJ3GEYJ 222 V (2.2 kΩ) T
R113 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ) T
R114 7310002670 S.TRIMMER RV-143 (RH03A3AS2) 471 T
R115 7030003580 S.RESISTOR ERJ3GEYJ 153 V (15 kΩ) B
R116 7030003310 S.RESISTOR ERJ3GEYJ 820 V (82 Ω) B
R121 7030005420 S.RESISTOR ERJ3GEYJ 202 V (2 kΩ) B
R122 7030005420 S.RESISTOR ERJ3GEYJ 202 V (2 kΩ) B
R123 7030001120 S.RESISTOR MCR50JZHJ 82 Ω (820) T
R124 7030003670 S.RESISTOR ERJ3GEYJ 823 V (82 kΩ) B
R125 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ) T
6 - 1
SECTION 6 PARTS LIST
REF ORDER
DESCRIPTION M.
NO. NO.
REF ORDER
DESCRIPTION M.
NO. NO.
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
6-1 IC-M401E
