Icom IC-M504

6 - 1
SECTION 6 PARTS LIST
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
[LOGIC BOARD]
REF ORDER
DESCRIPTION M.
H/V
NO. NO.
LOCATION
IC2 1110006380 S.IC LM2904PWR B 72.9/41.6
IC3 1140008650 S.IC HN58X2464TI B 120.3/30.8
IC4 1110005771 S.IC S-80942CNMC-G9CT2G B 134.9/61.9
IC6 1170000352 S.IC PC357N6J000F B 59.5/47.6
IC8 1180000421 S.IC TA78L05F (TE12R F) B 132/25.3
IC9 1130013100 S.IC KIC7W14FK RTK/P B 62.4/40.4
IC10 1130013200 S.IC TC74LCXR164245 (E F) B 89.3/53.7
IC11 1180002380 S.IC S-817B33AMC-CWW-T2G B 107/76.3
Q1 1520000651 S.TR 2SB1201S-TL-E B 137.5/69.5
Q2 1530003900 S.TR KTC4075 BL-RTK/P B 128.7/67.8
Q3 1530003900 S.TR KTC4075 BL-RTK/P B 129.3/70.9
Q4 1530003960 S.TR KTC2875-B-RTK/P B 123.1/36
Q5 1530002280 S.TR 2SC4081 T106 S B 62.5/52.6
Q6 1590003580 S.TR KRC404 RTK/P B 63.1/48.5
Q7 1530002280 S.TR 2SC4081 T106 S B 60/32.8
Q8 1510000510 S.TR 2SA1576A T106R B 62.8/32.5
Q9 1560000810 S.FET 2SK1069-4-TL B 62.8/35.6
D1 1790001561 S.DIO 1SS372 (TE85R F) B 125.9/35.1
D2 1750001320 S.DIO KDS4148U RTK/P B 59.5/52.6
D3 1750001180 S.DIO KDS122 RTK/P B 61.8/55.4
D4 1730002360 S.ZEN MA8062-M (TX) B 65.1/57.6
D5 1750001180 S.DIO KDS122 RTK/P B 129.2/35.1
D43 1790001810 S.VSR AVR-M1005C080MTABB B 126.2/17
X1 6050012041 S.XTL CR-790A (9.8304 MHz) B 116.5/64.3
R2 7030003560 S.RES ERJ3GEYJ 103 V (10 k
)
B 101/39.3
R7 7030003640 S.RES ERJ3GEYJ 473 V (47 k
)
B 139.3/48.7
R22 7030003680 S.RES ERJ3GEYJ 104 V (100 k
)
B 72.8/44.3
R23 7030003800 S.RES ERJ3GEYJ 105 V (1 M
)
B 72.8/38.9
R24 7030003500 S.RES ERJ3GEYJ 332 V (3.3 k
)
B 77.7/40.4
R25 7030003560 S.RES ERJ3GEYJ 103 V (10 k
)
B 68.3/44
R26 7030003540 S.RES ERJ3GEYJ 682 V (6.8 k
)
B 68.3/41.2
R31 7030003560 S.RES ERJ3GEYJ 103 V (10 k
)
B 119.8/36.9
R32 7030003560 S.RES ERJ3GEYJ 103 V (10 k
)
B 120.3/35.6
R33 7030003560 S.RES ERJ3GEYJ 103 V (10 k
)
B 128.4/18.8
R34 7030003560 S.RES ERJ3GEYJ 103 V (10 k
)
B 129.2/17
R35 7030003560 S.RES ERJ3GEYJ 103 V (10 k
)
B 143.5/17.1
R36 7030003650 S.RES ERJ3GEYJ 563 V (56 k
)
B 100.1/59.4
R37 7030008051 S.RES ERA3YKD 184V (180 k
)
B 100.8/61.4
R38 7030003320 S.RES ERJ3GEYJ 101 V (100) B 127.7/17
R41 7030003680 S.RES ERJ3GEYJ 104 V (100 k
)
B 102.8/29
R43 7030003570 S.RES ERJ3GEYJ 123 V (12 k
)
B 137.1/58.2
R44 7030003640 S.RES ERJ3GEYJ 473 V (47 k
)
B 137.1/59.4
R45 7030003640 S.RES ERJ3GEYJ 473 V (47 k
)
B 134.4/58.2
R46 7030003320 S.RES ERJ3GEYJ 101 V (100) B 115.7/59.9
R48 7030003640 S.RES ERJ3GEYJ 473 V (47 k
)
B 139.3/51.3
R49 7030003640 S.RES ERJ3GEYJ 473 V (47 k
)
B 139.3/52.6
R51 7030006060 S.RES ERJ12YJ100U (10) B 135.3/75.2
R54 7030004120 S.RES ERJ3GEYJ 203 V (20 k
)
B 98.8/70.6
R55 7030003560 S.RES ERJ3GEYJ 103 V (10 k
)
B 100/70.6
R56 7030003590 S.RES ERJ3GEYJ 183 V (18 k
)
B 101.2/70.6
R57 7030003560 S.RES ERJ3GEYJ 103 V (10 k
)
B 102.4/70.6
R58 7030004120 S.RES ERJ3GEYJ 203 V (20 k
)
B 103.6/70.6
R59 7030003560 S.RES ERJ3GEYJ 103 V (10 k
)
B 104.8/70.6
R60 7030003590 S.RES ERJ3GEYJ 183 V (18 k
)
B 106/70.6
R61 7030003560 S.RES ERJ3GEYJ 103 V (10 k
)
B 107.2/70.6
R62 7030003630 S.RES ERJ3GEYJ 393 V (39 k
)
B 97.6/70.6
R63 7030003660 S.RES ERJ3GEYJ 683 V (68 k
)
B 127.4/70.8
R64 7030003440 S.RES ERJ3GEYJ 102 V (1 k
)
B 130.6/67.5
R65 7030003560 S.RES ERJ3GEYJ 103 V (10 k
)
B 131.9/70.3
R66 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k
)
B 131.9/67.5
R71 7030003370 S.RES ERJ3GEYJ 271 V (270) B 49.4/15.9
R72 7030003370 S.RES ERJ3GEYJ 271 V (270) B 134.2/17.5
R74 7030003320 S.RES ERJ3GEYJ 101 V (100) B 90.7/26.9
R75 7030003320 S.RES ERJ3GEYJ 101 V (100) B 54.7/23
R76 7030003320 S.RES ERJ3GEYJ 101 V (100) B 74/74.3
S.=Surface mount
[LOGIC BOARD]
REF ORDER
DESCRIPTION M.
H/V
NO. NO.
LOCATION
R77 7030003320 S.RES ERJ3GEYJ 101 V (100) B 121.1/74.3
R79 7030003680 S.RES ERJ3GEYJ 104 V (100 k
)
B 121.9/56.1
R80 7030003680 S.RES ERJ3GEYJ 104 V (100 k
)
B 118.3/56.1
R81 7030003680 S.RES ERJ3GEYJ 104 V (100 k
)
B 120.5/39
R82 7030003440 S.RES ERJ3GEYJ 102 V (1 k
)
B 124.7/39.1
R83 7030003580 S.RES ERJ3GEYJ 153 V (15 k
)
B 122.6/38.4
R84 7030003440 S.RES ERJ3GEYJ 102 V (1 k
)
B 122.6/39.7
R85 7030003680 S.RES ERJ3GEYJ 104 V (100 k
)
B 61.6/58.4
R86 7030003210 S.RES ERJ3GEYJ 120 V (12) B 64.4/54.4
R87 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k
)
B 63/50.4
R88 7030003680 S.RES ERJ3GEYJ 104 V (100 k
)
B 67.8/49.5
R89 7030003640 S.RES ERJ3GEYJ 473 V (47 k
)
B 122.8/32.9
R91 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k
)
B 60.9/35.5
R92 7030003280 S.RES ERJ3GEYJ 470 V (47) B 65.4/32.2
R93 7030003430 S.RES ERJ3GEYJ 821 V (820) B 58/54.9
R94 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k
)
B 62.6/43.7
R95 7030003440 S.RES ERJ3GEYJ 102 V (1 k
)
B 65.4/33.4
R96 7030003640 S.RES ERJ3GEYJ 473 V (47 k
)
B 65.4/34.7
R97 7030003440 S.RES ERJ3GEYJ 102 V (1 k
)
B 65.4/36
R98 7030003440 S.RES ERJ3GEYJ 102 V (1 k
)
B 58.2/41.7
R102 7030003860 S.RES ERJ3GE JPW V B 104.5/64
R119 7030003680 S.RES ERJ3GEYJ 104 V (100 k
)
B 88.1/45.2
R120 7030003680 S.RES ERJ3GEYJ 104 V (100 k
)
B 88.1/44
R121 7030003680 S.RES ERJ3GEYJ 104 V (100 k
)
B 88.1/42.8
R122 7030003680 S.RES ERJ3GEYJ 104 V (100 k
)
B 91.8/45.2
R123 7030003680 S.RES ERJ3GEYJ 104 V (100 k
)
B 90.5/47.2
R126 7030003680 S.RES ERJ3GEYJ 104 V (100 k
)
B 120.7/56.1
R127 7030003680 S.RES ERJ3GEYJ 104 V (100 k
)
B 119.5/56.1
C1 4510008540 S.ELE EEE1CA100SR B 94.7/42.1
C2 4030016930 S.CER ECJ0EB1A104K B 100.2/41.5
C5 4030017460 S.CER ECJ0EB1E102K B 138.3/40.4
C6 4030017730 S.CER ECJ0EB1E471K B 138.3/37.6
C15 4030016790 S.CER ECJ0EB1C103K B 100.5/57.4
C16 4030016790 S.CER ECJ0EB1C103K B 61.1/19.6
C21 4030011600 S.CER C1608 JB 1E 104K-T B 75.6/38.9
C31 4030016790 S.CER ECJ0EB1C103K B 123/27.3
C32 4030016930 S.CER ECJ0EB1A104K B 123/28.3
C33 4030016930 S.CER ECJ0EB1A104K B 124.3/32.7
C35 4030016790 S.CER ECJ0EB1C103K B 100.5/58.3
C36 4030016790 S.CER ECJ0EB1C103K B 101.9/60.9
C37 4030016790 S.CER ECJ0EB1C103K B 102.8/60.9
C38 4030016790 S.CER ECJ0EB1C103K B 103.7/60.9
C39 4030016790 S.CER ECJ0EB1C103K B 104.6/60.9
C40 4030016790 S.CER ECJ0EB1C103K B 105/62.9
C41 4030017480 S.CER C1608 JB 1A 474K-T B 107.2/64
C42 4030017480 S.CER C1608 JB 1A 474K-T B 134.4/59.4
C44 4030017030 S.CER ECJ0EB1A273K B 137.4/63.3
C45 4030017400 S.CER ECJ0EC1H220J B 115.6/61
C46 4030017400 S.CER ECJ0EC1H220J B 117.4/61
C52 4030017460 S.CER ECJ0EB1E102K B 139.3/73.9
C81 4030017920 S.CER ECJ0EB1A683K B 59.5/54
C82 4030016790 S.CER ECJ0EB1C103K B 59.3/43.2
C83 4030016930 S.CER ECJ0EB1A104K B 59.3/41.4
C86 4030016930 S.CER ECJ0EB1A104K B 64.8/52.1
C87 4030017460 S.CER ECJ0EB1E102K B 65.2/50.4
C88 4030017460 S.CER ECJ0EB1E102K B 56.8/58
C89 4030017460 S.CER ECJ0EB1E102K B 59.5/54.9
C90 4030017460 S.CER ECJ0EB1E102K B 63.5/56.9
C91 4550007750 S.TAN TEESVA 1V 225M8R B 80.6/55
C92 4550007750 S.TAN TEESVA 1V 225M8R B 71.2/68.8
C93 4550007750 S.TAN TEESVA 1V 225M8R B 71.2/66.6
C94 4550007750 S.TAN TEESVA 1V 225M8R B 71.2/64.4
C95 4550007650 S.TAN F931V105MAABMA B 78.5/55
C96 4550007650 S.TAN F931V105MAABMA B 76.4/55
C97 4550007650 S.TAN F931V105MAABMA B 74.5/60
C98 4550007650 S.TAN F931V105MAABMA B 72.3/60
C99 4550007650 S.TAN F931V105MAABMA B 70.1/60
C101 4030017460 S.CER ECJ0EB1E102K B 130.9/28.5
C102 4510008540 S.ELE EEE1CA100SR B 128.9/31.4
C104 4030017460 S.CER ECJ0EB1E102K B 73.6/29.7
C105 4030017460 S.CER ECJ0EB1E102K B 74.6/31.1
C106 4030016790 S.CER ECJ0EB1C103K B 88.4/26.7
C107 4030016790 S.CER ECJ0EB1C103K B 89/24.8
C108 4030016790 S.CER ECJ0EB1C103K B 133.1/28.5
C109 4510008540 S.ELE EEE1CA100SR B 135.1/31.4
C111 4030016930 S.CER ECJ0EB1A104K B 119.5/58.4
C141 4030016930 S.CER ECJ0EB1A104K B 59.5/34.6
C142 4030016930 S.CER ECJ0EB1A104K B 59.5/37.3
C334 4030017420 S.CER ECJ0EC1H470J B 113.5/12.8
C336 4030017420 S.CER ECJ0EC1H470J B 112.5/11.3
C337 4030017460 S.CER ECJ0EB1E102K B 126.2/16.1
• IC-M504
[REPLACEMENT UNITS]
ORDER NO. UNIT NAME COLOR
0329140101
0329140301
U M504 #01 FRONT
(including HM-126B-3 ACC)
U M504 #03 FRONT
(including HM-126G ACC)
BLACK
GRAY
