Icom IC-M504

6 - 3
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
S.=Surface mount
[MAIN UNIT]
REF ORDER
DESCRIPTION M.
H/V
NO. NO.
LOCATION
R24 7030003410 S.RES ERJ3GEYJ 561 V (560) T 84.1/42.7
R25 7030003420 S.RES ERJ3GEYJ 681 V (680) T 85.4/43.2
R26 7030003620 S.RES ERJ3GEYJ 333 V (33 k
)
T 74.2/40.7
R27 7030003600 S.RES ERJ3GEYJ 223 V (22 k
)
T 70.5/42.4
R28 7030003620 S.RES ERJ3GEYJ 333 V (33 k
)
T 74.2/42.4
R31 7030003400 S.RES ERJ3GEYJ 471 V (470) T 76/37
R32 7030003660 S.RES ERJ3GEYJ 683 V (68 k
)
T 73.1/37
R33 7030003370 S.RES ERJ3GEYJ 271 V (270) T 78.5/32
R34 7030003230 S.RES ERJ3GEYJ 180 V (18) T 78.7/34.3
R35 7030003370 S.RES ERJ3GEYJ 271 V (270) T 79.8/36.2
R41 7030003410 S.RES ERJ3GEYJ 561 V (560) T 86.3/31.7
R42 7030003550 S.RES ERJ3GEYJ 822 V (8.2 k
)
T 71.7/26.6
R43 7030003550 S.RES ERJ3GEYJ 822 V (8.2 k
)
T 77.9/26
R44 7030003320 S.RES ERJ3GEYJ 101 V (100) T 73.9/31.6
R45 7030003390 S.RES ERJ3GEYJ 391 V (390) T 73.9/29.8
R46 7030003350 S.RES ERJ3GEYJ 181 V (180) T 75.9/26.6
R51 7030003420 S.RES ERJ3GEYJ 681 V (680) T 71.1/33.1
R52 7030003660 S.RES ERJ3GEYJ 683 V (68 k
)
T 69.4/30.9
R55 7030003400 S.RES ERJ3GEYJ 471 V (470) T 63.8/37.4
R56 7030003600 S.RES ERJ3GEYJ 223 V (22 k
)
T 64.6/35.2
R66 7030003860 S.RES ERJ3GE JPW V T 58.8/23.5
R70 7030003860 S.RES ERJ3GE JPW V T 52/15.5
R81 7030003440 S.RES ERJ3GEYJ 102 V (1 k
)
T 60/34.7
R83 7030003480 S.RES ERJ3GEYJ 222 V (2.2 k
)
T 69.8/53.5
R84 7030003390 S.RES ERJ3GEYJ 391 V (390) T 73/52.7
R86 7030003560 S.RES ERJ3GEYJ 103 V (10 k
)
T 69.8/54.7
R87 7030003580 S.RES ERJ3GEYJ 153 V (15 k
)
T 74.2/54.2
R88 7030003340 S.RES ERJ3GEYJ 151 V (150) T 78/54.1
R89 7030003200 S.RES ERJ3GEYJ 100 V (10) T 69.8/56.9
R100 7030003720 S.RES ERJ3GEYJ 224 V (220 k
)
T 58.8/50.7
R101 7030003480 S.RES ERJ3GEYJ 222 V (2.2 k
)
T 64.8/57.7
R104 7030003500 S.RES ERJ3GEYJ 332 V (3.3 k
)
T 60/48
R105 7030003560 S.RES ERJ3GEYJ 103 V (10 k
)
T 55.3/46.4
R106 7030003440 S.RES ERJ3GEYJ 102 V (1 k
)
T 56.1/42.6
R107 7030003360 S.RES ERJ3GEYJ 221 V (220) T 53.6/49.2
R108 7030003240 S.RES ERJ3GEYJ 220 V (22) T 58.1/41.8
R111 7030003560 S.RES ERJ3GEYJ 103 V (10 k
)
T 49.1/46.6
R112 7310005270 S.TRI RH03ADCJ2X (220) T 46.4/44.1
R113 7030003460 S.RES ERJ3GEYJ 152 V (1.5 k
)
T 49.1/42.9
R114 7030003270 S.RES ERJ3GEYJ 390 V (39) T 51.1/42.2
R121 7030003470 S.RES ERJ3GEYJ 182 V (1.8 k
)
T 49.9/54.9
R122 7030003470 S.RES ERJ3GEYJ 182 V (1.8 k
)
T 49.9/53.6
R123 7030003470 S.RES ERJ3GEYJ 182 V (1.8 k
)
T 43.7/45.6
R124 7030003470 S.RES ERJ3GEYJ 182 V (1.8 k
)
T 42.4/45.6
R125 7030007240 S.RES ERJ12YJ680U (68) T 34.9/38.3
R126 7030003670 S.RES ERJ3GEYJ 823 V (82 k
)
T 27.4/58.7
R127 7030003680 S.RES ERJ3GEYJ 104 V (100 k
)
T 48.2/40.9
R144 7030003860 S.RES ERJ3GE JPW V T 11.8/30.2
R147 7030003320 S.RES ERJ3GEYJ 101 V (100) T 5.6/11.2
R148 7030003620 S.RES ERJ3GEYJ 333 V (33 k
)
T 4.4/11.4
R149 7030003580 S.RES ERJ3GEYJ 153 V (15 k
)
T 3.1/17.7
R150 7030003560 S.RES ERJ3GEYJ 103 V (10 k
)
T 3.1/11.4
R151 7030003620 S.RES ERJ3GEYJ 333 V (33 k
)
T 2/14.1
R152 7030003280 S.RES ERJ3GEYJ 470 V (47) T 5.8/17.7
R153 7030004050 S.RES ERJ3GEYJ 1R0 V (1) T 8.4/14.3
R154 7030003480 S.RES ERJ3GEYJ 222 V (2.2 k
)
T 6.8/11.2
R157 7030003680 S.RES ERJ3GEYJ 104 V (100 k
)
T 17.6/15.2
R158 7030003270 S.RES ERJ3GEYJ 390 V (39) T 15.6/35.4
R159 7030003480 S.RES ERJ3GEYJ 222 V (2.2 k
)
T 21.2/34
R171 7030003680 S.RES ERJ3GEYJ 104 V (100 k
)
T 21.5/12.3
R172 7030003680 S.RES ERJ3GEYJ 104 V (100 k
)
T 26.3/12.3
R173 7030003560 S.RES ERJ3GEYJ 103 V (10 k
)
T 32.9/14.4
R180 7030003860 S.RES ERJ3GE JPW V T 33.8/11.5
R182 7030003240 S.RES ERJ3GEYJ 220 V (22) T 60.6/6.5
R183 7030003500 S.RES ERJ3GEYJ 332 V (3.3 k
)
T 64/12
R185 7030003320 S.RES ERJ3GEYJ 101 V (100) T 72.6/3.9
R186 7030003400 S.RES ERJ3GEYJ 471 V (470) T 96.2/2.2
R187 7030003200 S.RES ERJ3GEYJ 100 V (10) T 63.3/14
R201 7030003500 S.RES ERJ3GEYJ 332 V (3.3 k
)
T 97.8/8.4
R202 7030003380 S.RES ERJ3GEYJ 331 V (330) T 99.8/5.9
R203 7030003680 S.RES ERJ3GEYJ 104 V (100 k
)
T 99.4/3.9
R205 7030003460 S.RES ERJ3GEYJ 152 V (1.5 k
)
T 102.3/12.6
R206 7030003420 S.RES ERJ3GEYJ 681 V (680) T 98.9/12.6
R209 7030003200 S.RES ERJ3GEYJ 100 V (10) T 114.3/9.3
R210 7030003560 S.RES ERJ3GEYJ 103 V (10 k
)
T 111.6/7.5
R211 7030003760 S.RES ERJ3GEYJ 474 V (470 k
)
T 114.3/13.1
R212 7030003430 S.RES ERJ3GEYJ 821 V (820) T 109.4/20.5
R213 7030003620 S.RES ERJ3GEYJ 333 V (33 k
)
T 112.9/20.7
R214 7310005040 S.TRI RH03ADCJ4X (22 k
)
T 113/18
R218 7030003580 S.RES ERJ3GEYJ 153 V (15 k
)
T 109/15.5
R219 7030003400 S.RES ERJ3GEYJ 471 V (470) T 105.7/16.3
R220 7510001511 S.TMR NTCG16 4LH 223JT T 113.6/22.7
R327 7310005030 S.TRI RH03ADCS4X (47 k
)
T 120.4/31.6
R328 7030003550 S.RES ERJ3GEYJ 822 V (8.2 k
)
T 80/42
R382 7030003560 S.RES ERJ3GEYJ 103 V (10 k
)
T 62/45.7
R383 7030003440 S.RES ERJ3GEYJ 102 V (1 k
)
T 61.3/44.4
R384 7030003440 S.RES ERJ3GEYJ 102 V (1 k
)
T 35.5/31.9
R385 7030003460 S.RES ERJ3GEYJ 152 V (1.5 k
)
T 35.5/30.6
R386 7030003680 S.RES ERJ3GEYJ 104 V (100 k
)
T 107.8/43
R498 7030003620 S.RES ERJ3GEYJ 333 V (33 k
)
T 14.1/26.9
R499 7030003580 S.RES ERJ3GEYJ 153 V (15 k
)
T 13.1/29.5
[MAIN UNIT]
REF ORDER
DESCRIPTION M.
H/V
NO. NO.
LOCATION
R501 7030003560 S.RES ERJ3GEYJ 103 V (10 k
)
T 15.4/27.9
R502 7030003620 S.RES ERJ3GEYJ 333 V (33 k
)
T 12.7/32.5
R504 7030003280 S.RES ERJ3GEYJ 470 V (47) T 12.7/34.3
R505 7030003440 S.RES ERJ3GEYJ 102 V (1 k
)
T 18/27.5
R506 7030004050 S.RES ERJ3GEYJ 1R0 V (1) T 16.7/27.9
R507 7030003320 S.RES ERJ3GEYJ 101 V (100) T 19.6/30.1
R521 7030003200 S.RES ERJ3GEYJ 100 V (10) T 46.9/37.7
R522 7030003500 S.RES ERJ3GEYJ 332 V (3.3 k
)
T 51.3/36.1
R523 7030003200 S.RES ERJ3GEYJ 100 V (10) T 56.4/38.3
R524 7030003400 S.RES ERJ3GEYJ 471 V (470) T 87.8/51.7
R531 7030003500 S.RES ERJ3GEYJ 332 V (3.3 k
)
T 91.9/47
R532 7030003680 S.RES ERJ3GEYJ 104 V (100 k
)
T 89.9/50.2
R533 7030003380 S.RES ERJ3GEYJ 331 V (330) T 94.1/49.1
R534 7030003480 S.RES ERJ3GEYJ 222 V (2.2 k
)
T 57.2/23.5
R541 7030003420 S.RES ERJ3GEYJ 681 V (680) T 100.1/43.6
R542 7030003460 S.RES ERJ3GEYJ 152 V (1.5 k
)
T 106.4/59.2
R544 7030003400 S.RES ERJ3GEYJ 471 V (470) T 98.9/47.3
R551 7030003240 S.RES ERJ3GEYJ 220 V (22) T 50.6/29.4
R561 7030003540 S.RES ERJ3GEYJ 682 V (6.8 k
)
T 100.1/40.8
R562 7030003760 S.RES ERJ3GEYJ 474 V (470 k
)
T 100.1/34.4
R563 7030003340 S.RES ERJ3GEYJ 151 V (150) T 106.6/50.2
R602 7030003450 S.RES ERJ3GEYJ 122 V (1.2 k
)
T 102.4/20.1
R603 7030003490 S.RES ERJ3GEYJ 272 V (2.7 k
)
T 92.9/15.3
R606 7030003400 S.RES ERJ3GEYJ 471 V (470) T 91.5/13.3
R608 7030003400 S.RES ERJ3GEYJ 471 V (470) T 68.6/17.9
R609 7030003480 S.RES ERJ3GEYJ 222 V (2.2 k
)
T 71.9/15
R610 7030003530 S.RES ERJ3GEYJ 562 V (5.6 k
)
T 72.6/13
R611 7030003280 S.RES ERJ3GEYJ 470 V (47) T 84.1/12.2
R615 7030003400 S.RES ERJ3GEYJ 471 V (470) T 77.5/8.8
R616 7030003420 S.RES ERJ3GEYJ 681 V (680) T 85/14.7
R617 7030003660 S.RES ERJ3GEYJ 683 V (68 k
)
T 82.9/15.3
R621 7030003660 S.RES ERJ3GEYJ 683 V (68 k
)
T 80.3/18
R622 7030003380 S.RES ERJ3GEYJ 331 V (330) T 78.7/19.9
R623 7030003320 S.RES ERJ3GEYJ 101 V (100) T 89.9/19.1
R624 7030003300 S.RES ERJ3GEYJ 680 V (68) T 91.9/18.6
R625 7030003320 S.RES ERJ3GEYJ 101 V (100) T 93.9/17.8
R631 7030003400 S.RES ERJ3GEYJ 471 V (470) T 59.4/14.7
R632 7030003500 S.RES ERJ3GEYJ 332 V (3.3 k
)
T 57.4/15.4
R633 7030003400 S.RES ERJ3GEYJ 471 V (470) T 55.7/12.1
R634 7030003480 S.RES ERJ3GEYJ 222 V (2.2 k
)
T 58.5/12.1
R635 7030003360 S.RES ERJ3GEYJ 221 V (220) T 58/13.4
C1 4030016970 S.CER ECJ0EB1C223K T 106.8/27.7
C2 4030016790 S.CER ECJ0EB1C103K T 99.2/21
C3 4030016930 S.CER ECJ0EB1A104K T 96/23.8
C4 4550000510 S.TAN TEESVA 1V 473M8R T 96.3/35.2
C5 4550007390 S.TAN F931C225MAABMA T 96.3/37.4
C7 4030017460 S.CER ECJ0EB1E102K T 98/32.9
C11 4030017640 S.CER ECJ0EC1H150J T 94.7/28.3
C12 4610001590 S.TRI TZC3R100A110R00 T 92.4/24.7
C13 4030017390 S.CER ECJ0EC1H180J T 94.3/29.6
C20 4030017460 S.CER ECJ0EB1E102K T 87.9/45.2
C21 4510008540 S.ELE EEE1CA100SR T 95.7/43.6
C22 4030016790 S.CER ECJ0EB1C103K T 90.5/39.9
C23 4030017460 S.CER ECJ0EB1E102K T 89.7/43.4
C24 4030017730 S.CER ECJ0EB1E471K T 85.5/41
C26 4030016790 S.CER ECJ0EB1C103K T 72.3/42
C27 4030017490 S.CER C1608 JB 1A 105K-T T 77.2/42.4
C29 4030017460 S.CER ECJ0EB1E102K T 81.8/32
C30 4030017460 S.CER ECJ0EB1E102K T 86.5/42.2
C31 4030017730 S.CER ECJ0EB1E471K T 78.3/35.6
C32 4030017380 S.CER ECJ0EC1H050B T 70.8/37.1
C33 4030017640 S.CER ECJ0EC1H150J T 74.8/34.1
C34 4030017650 S.CER ECJ0EC1H270J T 75/33.1
C35 4030017650 S.CER ECJ0EC1H270J T 78/33.2
C36 4030017460 S.CER ECJ0EB1E102K T 79.8/33.1
C40 4030017600 S.CER ECJ0EC1H080C T 80.3/29
C41 4030017660 S.CER ECJ0EC1H330J T 82.9/30.9
C42 4030017700 S.CER ECJ0EC1H151J T 83.6/29.6
C43 4550007590 S.TAN F931V474MAABMA T 84.6/33.1
C44 4030017460 S.CER ECJ0EB1E102K T 85.2/29.9
C45 4030017550 S.CER ECJ0EC1H1R5B T 78.6/29.7
C46 4030017550 S.CER ECJ0EC1H1R5B T 79.9/27.7
C47 4030017460 S.CER ECJ0EB1E102K T 74.3/25.7
C48 4030017730 S.CER ECJ0EB1E471K T 75.8/28.8
C49 4030017730 S.CER ECJ0EB1E471K T 76/30.7
C51 4030017540 S.CER ECJ0EC1HR75B T 72/28.6
C52 4030017730 S.CER ECJ0EB1E471K T 69.1/33.2
C55 4030017460 S.CER ECJ0EB1E102K T 65.3/38.4
C56 4030017640 S.CER ECJ0EC1H150J T 69.1/35.5
C57 4030017730 S.CER ECJ0EB1E471K T 65.3/37.4
C58 4030017640 S.CER ECJ0EC1H150J T 60.7/33.5
C78 4030017660 S.CER ECJ0EC1H330J T 51.4/12.5
C79 4030017460 S.CER ECJ0EB1E102K T 48/11.8
C81 4030017460 S.CER ECJ0EB1E102K T 69.4/52.4
C82 4030017460 S.CER ECJ0EB1E102K T 74.2/51.9
C83 4030017700 S.CER ECJ0EC1H151J T 72/54.9
C87 4030017420 S.CER ECJ0EC1H470J T 76.8/53.6
C88 4030017460 S.CER ECJ0EB1E102K T 75.8/53.6
C89 4030017460 S.CER ECJ0EB1E102K T 70.3/55.8
