6 - 5
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
S.=Surface mount
[AF UNIT]
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
IC3 1130011770 S.IC CD4066BPWR T 35.5/25.5
IC4 1130011770 S.IC CD4066BPWR T 78.5/24
IC5 1130011770 S.IC CD4066BPWR T 59/47
IC6 1130011770 S.IC CD4066BPWR T 70/54.4
IC7 1110000960 S.IC NJM4558M-TE1 B 63.5/41.6
IC8 1110000960 S.IC NJM4558M-TE1 B 63.5/28
IC9 1110003091 IC LA4425A-E
IC10 1180002780 REG KIA7805API U/P
IC12 1110006380 S.IC LM2904PWR T 48.1/40
IC13 1110004490 S.IC M62429FP 700C B 88.5/44
IC14 1110006141 IC LA4485-E
IC15 1110003650 S.IC NJM2211M-TE1 B 43/30
IC26 1130013110 S.IC KIC7W53FK-RTK/P T 40/40.4
IC27 1130011760 S.IC CD4094BPWR T 46/12.5
IC28 1130011760 S.IC CD4094BPWR T 46/20.5
IC29 1110002400 S.IC NJM2107F-TE1 T 64.1/37.7
Q31 1530003900 S.TR KTC4075 BL-RTK/P T 73.6/28.8
Q32 1530003900 S.TR KTC4075 BL-RTK/P T 71.4/22.2
Q37 1590003670 S.TR KRA304-RTK/P T 75.7/54.9
Q38 1530003900 S.TR KTC4075 BL-RTK/P T 44.3/50
Q61 1590003560 S.FET TPC6104 (TE85L F) T 15.7/24.5
Q62 1590003580 S.TR KRC404 RTK/P T 17.3/20.1
Q65 1530003960 S.TR KTC2875-B-RTK/P B 7/37.9
Q66 1590003670 S.TR KRA304-RTK/P T 93.2/14.9
Q71 1520000380 TR 2SB1143 S
Q72 1590001190 S.TR XP6501-(TX) AB T 4.6/20.1
D42 1790000700 DIO DSA3A1
R231 7030003600 S.RES ERJ3GEYJ 223 V (22 k
)
T 69.9/26.6
R232 7030003580 S.RES ERJ3GEYJ 153 V (15 k
)
T 70.9/29.7
R233 7030003400 S.RES ERJ3GEYJ 471 V (470) T 68.7/23.8
R234 7030003760 S.RES ERJ3GEYJ 474 V (470 k
)
T 72/26.6
R235 7030003720 S.RES ERJ3GEYJ 224 V (220 k
)
T 73.7/30.9
R236 7030003390 S.RES ERJ3GEYJ 391 V (390) T 70.9/30.9
R237 7030003490 S.RES ERJ3GEYJ 272 V (2.7 k
)
T 74/26.6
R238 7030003620 S.RES ERJ3GEYJ 333 V (33 k
)
T 74/25.3
R239 7030003620 S.RES ERJ3GEYJ 333 V (33 k
)
T 74/24
R240 7030003480 S.RES ERJ3GEYJ 222 V (2.2 k
)
T 74.3/22.6
R241 7030003680 S.RES ERJ3GEYJ 104 V (100 k
)
T 76.7/18.5
R242 7030003680 S.RES ERJ3GEYJ 104 V (100 k
)
T 77.7/30.6
R243 7030003680 S.RES ERJ3GEYJ 104 V (100 k
)
T 81.6/30.6
R244 7030003680 S.RES ERJ3GEYJ 104 V (100 k
)
T 79.3/18
R245 7030003680 S.RES ERJ3GEYJ 104 V (100 k
)
T 78/18.5
R246 7030003680 S.RES ERJ3GEYJ 104 V (100 k
)
T 76.4/30.6
R247 7030003800 S.RES ERJ3GEYJ 105 V (1 M
)
T 79/30.6
R248 7030003800 S.RES ERJ3GEYJ 105 V (1 M
)
T 58.3/41
R250 7030003800 S.RES ERJ3GEYJ 105 V (1 M
)
T 62.7/53.8
R251 7030003800 S.RES ERJ3GEYJ 105 V (1 M
)
T 57.9/39.6
R252 7030003680 S.RES ERJ3GEYJ 104 V (100 k
)
T 60.3/40.3
R253 7030003680 S.RES ERJ3GEYJ 104 V (100 k
)
T 61.5/42.3
R254 7030003800 S.RES ERJ3GEYJ 105 V (1 M
)
T 61.4/53.8
R255 7030003490 S.RES ERJ3GEYJ 272 V (2.7 k
)
T 69.7/33.9
R256 7030003800 S.RES ERJ3GEYJ 105 V (1 M
)
T 59.6/53.8
R257 7030003490 S.RES ERJ3GEYJ 272 V (2.7 k
)
T 64.1/43.4
R258 7030003680 S.RES ERJ3GEYJ 104 V (100 k
)
T 58.3/53.8
R259 7030003680 S.RES ERJ3GEYJ 104 V (100 k
)
T 57/53.8
R260 7030003680 S.RES ERJ3GEYJ 104 V (100 k
)
T 83.8/27.8
R261 7030003470 S.RES ERJ3GEYJ 182 V (1.8 k
)
T 85.1/27.8
R262 7030003680 S.RES ERJ3GEYJ 104 V (100 k
)
T 70.1/48.5
R263 7030003800 S.RES ERJ3GEYJ 105 V (1 M
)
T 65.8/55.7
R264 7030003420 S.RES ERJ3GEYJ 681 V (680) T 75.7/53
R265 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k
)
T 73.4/53.5
R266 7030003800 S.RES ERJ3GEYJ 105 V (1 M
)
T 72.7/59.7
R267 7030003800 S.RES ERJ3GEYJ 105 V (1 M
)
T 70.1/59.7
R268 7030003800 S.RES ERJ3GEYJ 105 V (1 M
)
T 71.4/59.7
R269 7030003680 S.RES ERJ3GEYJ 104 V (100 k
)
T 71.3/48.5
R270 7030003800 S.RES ERJ3GEYJ 105 V (1 M
)
T 80.3/30.6
R271 7030003590 S.RES ERJ3GEYJ 183 V (18 k
)
T 44.3/46.8
R272 7030003620 S.RES ERJ3GEYJ 333 V (33 k
)
T 41.5/46.8
R273 7030003560 S.RES ERJ3GEYJ 103 V (10 k
)
T 41.6/48.8
R274 7030003560 S.RES ERJ3GEYJ 103 V (10 k
)
T 40.5/51.9
R275 7030003560 S.RES ERJ3GEYJ 103 V (10 k
)
T 44.3/48.1
R276 7030003440 S.RES ERJ3GEYJ 102 V (1 k
)
T 44.3/51.9
R277 7030003560 S.RES ERJ3GEYJ 103 V (10 k
)
T 46.5/49.9
R278 7030003680 S.RES ERJ3GEYJ 104 V (100 k
)
T 80.6/18.5
R292 7030003790 S.RES ERJ3GEYJ 824 V (820 k
)
T 81.9/17.1
R293 7030005321 S.RES ERA3YED 103V (10 k
)
T 83.2/17.1
R294 7030003200 S.RES ERJ3GEYJ 100 V (10) T 36.6/35.6
R295 7030006091 S.RES ERA3YED 822V (8.2 k
)
T 84.5/15.6
R298 7030003860 S.RES ERJ3GE JPW V T 40.1/29.4
R299 7030003640 S.RES ERJ3GEYJ 473 V (47 k
)
B 68.9/37.9
R301 7030003680 S.RES ERJ3GEYJ 104 V (100 k
)
B 70.6/42.4
R302 7030003560 S.RES ERJ3GEYJ 103 V (10 k
)
B 69/44.4
R303 7030003480 S.RES ERJ3GEYJ 222 V (2.2 k
)
T 79.1/39.4
R303 7030003540 S.RES ERJ3GEYJ 682 V (6.8 k
)
T 79.1/39.4
R304 7030003550 S.RES ERJ3GEYJ 822 V (8.2 k
)
B 67.3/37.2
R305 7030003680 S.RES ERJ3GEYJ 104 V (100 k
)
B 59.7/41.3
[AF UNIT]
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
R306 7030003800 S.RES ERJ3GEYJ 105 V (1 M
)
T 36.1/31.1
R307 7030003440 S.RES ERJ3GEYJ 102 V (1 k
)
B 61.1/19.2
R308 7030003770 S.RES ERJ3GEYJ 564 V (560 k
)
B 67.3/26.4
R309 7030003680 S.RES ERJ3GEYJ 104 V (100 k
)
B 66.6/22.3
R311 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k
)
B 63/22.1
R312 7030003610 S.RES ERJ3GEYJ 273 V (27 k
)
B 67.3/29.5
R313 7030003680 S.RES ERJ3GEYJ 104 V (100 k
)
B 71.1/31
R314 7030003590 S.RES ERJ3GEYJ 183 V (18 k
)
B 69.5/29.5
R315 7030003670 S.RES ERJ3GEYJ 823 V (82 k
)
B 67.3/32.6
R316 7030003670 S.RES ERJ3GEYJ 823 V (82 k
)
B 65.7/34.1
R317 7030003670 S.RES ERJ3GEYJ 823 V (82 k
)
B 62.3/34.1
R318 7030003680 S.RES ERJ3GEYJ 104 V (100 k
)
B 59.7/44.4
R319 7030003610 S.RES ERJ3GEYJ 273 V (27 k
)
B 67.3/40.6
R320 7030003800 S.RES ERJ3GEYJ 105 V (1 M
)
B 63.9/48.2
R321 7030003470 S.RES ERJ3GEYJ 182 V (1.8 k
)
B 65.7/47.6
R323 7030003560 S.RES ERJ3GEYJ 103 V (10 k
)
B 33.3/28.4
R324 7510001671 S.TMR NTCG16 4BH 103JT B 31.4/28.4
R325 7030003560 S.RES ERJ3GEYJ 103 V (10 k
)
B 30.1/31.7
R326 7030003580 S.RES ERJ3GEYJ 153 V (15 k
)
B 29.5/28.4
R331 7030003800 S.RES ERJ3GEYJ 105 V (1 M
)
T 37.4/31.1
R332 7030003800 S.RES ERJ3GEYJ 105 V (1 M
)
T 36.5/19.3
R333 7030003800 S.RES ERJ3GEYJ 105 V (1 M
)
T 35.2/19.3
R334 7030003800 S.RES ERJ3GEYJ 105 V (1 M
)
T 40.2/45
R335 7030003800 S.RES ERJ3GEYJ 105 V (1 M
)
T 40.2/43.7
R336 7030003800 S.RES ERJ3GEYJ 105 V (1 M
)
T 39.2/31.4
R337 7030003800 S.RES ERJ3GEYJ 105 V (1 M
)
T 34.8/31.1
R338 7030003800 S.RES ERJ3GEYJ 105 V (1 M
)
T 33.9/19.3
R341 7030003860 S.RES ERJ3GE JPW V B 68.9/23.3
R343 7030003860 S.RES ERJ3GE JPW V T 13.9/38.5
R344 7030003860 S.RES ERJ3GE JPW V T 12.1/37
R353 7030003770 S.RES ERJ3GEYJ 564 V (560 k
)
B 7.8/33.6
R354 7030003580 S.RES ERJ3GEYJ 153 V (15 k
)
B 6/34.4
R355 7030003620 S.RES ERJ3GEYJ 333 V (33 k
)
B 6/42.1
R356 7030000100 S.RES MCR10EZHJ 4.7 (4R7) T 9.2/40.1
R361 7030003620 S.RES ERJ3GEYJ 333 V (33 k
)
T 65.3/40.5
R362 7030003640 S.RES ERJ3GEYJ 473 V (47 k
)
T 67.3/40.6
R363 7030003760 S.RES ERJ3GEYJ 474 V (470 k
)
T 67.8/37.1
R411 7030003680 S.RES ERJ3GEYJ 104 V (100 k
)
T 78.9/44.4
R412 7030003590 S.RES ERJ3GEYJ 183 V (18 k
)
B 81.1/43.5
R421 7030003860 S.RES ERJ3GE JPW V T 87.3/43.4
R423 7030003860 S.RES ERJ3GE JPW V T 92/50.5
R425 7030003860 S.RES ERJ3GE JPW V T 79.2/42.2
R427 7030003560 S.RES ERJ3GEYJ 103 V (10 k
)
T 91.1/17.3
R428 7030003560 S.RES ERJ3GEYJ 103 V (10 k
)
T 95.8/23.2
R429 7030003320 S.RES ERJ3GEYJ 101 V (100) T 90.3/14.3
R431 7030003620 S.RES ERJ3GEYJ 333 V (33 k
)
B 9.8/37.8
R441 7030003640 S.RES ERJ3GEYJ 473 V (47 k
)
T 18.1/24.5
R442 7030003680 S.RES ERJ3GEYJ 104 V (100 k
)
T 17.2/22
R443 7030000010 S.RES MCR10EZHJ JPW (000) B 96.5/13.7
R444 7030000010 S.RES MCR10EZHJ JPW (000) B 94.1/14.6
R571 7030003680 S.RES ERJ3GEYJ 104 V (100 k
)
T 48.5/44.6
R572 7030003680 S.RES ERJ3GEYJ 104 V (100 k
)
T 49.4/43.3
R573 7030003560 S.RES ERJ3GEYJ 103 V (10 k
)
T 46.5/43.8
R574 7030003560 S.RES ERJ3GEYJ 103 V (10 k
)
T 44.4/43.6
R575 7030003560 S.RES ERJ3GEYJ 103 V (10 k
)
T 44.4/42.3
R576 7030003560 S.RES ERJ3GEYJ 103 V (10 k
)
T 42.5/37.3
R577 7030003440 S.RES ERJ3GEYJ 102 V (1 k
)
T 45.7/37.4
R578 7030003460 S.RES ERJ3GEYJ 152 V (1.5 k
)
T 48.6/36.1
R580 7030003760 S.RES ERJ3GEYJ 474 V (470 k
)
T 48.5/37.4
R581 7030003760 S.RES ERJ3GEYJ 474 V (470 k
)
T 51.3/37.4
R582 7030003760 S.RES ERJ3GEYJ 474 V (470 k
)
B 43.5/24
R583 7030003280 S.RES ERJ3GEYJ 470 V (47) T 36.4/33.3
R584 7030003680 S.RES ERJ3GEYJ 104 V (100 k
)
B 40/37.3
R585 7030003630 S.RES ERJ3GEYJ 393 V (39 k
)
B 43.2/37.3
R586 7030003580 S.RES ERJ3GEYJ 153 V (15 k
)
B 45.6/37.9
R587 7030003470 S.RES ERJ3GEYJ 182 V (1.8 k
)
B 48.1/37.5
R591 7030005341 S.RES ERA3YED 332V (3.3 k
)
B 6/12.8
R592 7030005321 S.RES ERA3YED 103V (10 k
)
B 6/16.4
R593 7030005321 S.RES ERA3YED 103V (10 k
)
T 5.8/17.1
R594 7030000320 S.RES MCR10EZHJ 330 (331) T 5.5/13
R595 7030000320 S.RES MCR10EZHJ 330 (331) T 5.5/14.8
R596 7030003440 S.RES ERJ3GEYJ 102 V (1 k
)
T 5.4/23
C106 4030016790 S.CER ECJ0EB1C103K T 81/7.9
C107 4030016790 S.CER ECJ0EB1C103K T 58.8/14.7
C231 4030018900 S.CER ECJ0EB0J474K T 68.8/26.7
C232 4030016930 S.CER ECJ0EB1A104K T 69/29.9
C233 4030016970 S.CER ECJ0EB1C223K T 69.6/28.5
C234 4030016970 S.CER ECJ0EB1C223K T 71.4/28.5
C235 4510008540 S.ELE EEE1CA100SR T 65/27.3
C236 4030017760 S.CER ECJ0EB1H222K T 71.9/24.3
C237 4030018820 S.CER ECJ0EB1H561K T 74.3/21.5
C238 4510008530 S.ELE EEE1HA2R2SR T 73/18.3
C241 4510008530 S.ELE EEE1HA2R2SR T 65.1/32.1
C243 4510008530 S.ELE EEE1HA2R2SR T 83.9/34.7
C245 4030011810 S.CER C1608 JB 1A 224K-T B 75.5/45.9
C246 4510008530 S.ELE EEE1HA2R2SR T 79.1/35.7
C247 4030016790 S.CER ECJ0EB1C103K T 83.7/23.7
C248 4510008530 S.ELE EEE1HA2R2SR T 65.2/48.9
C249 4030017490 S.CER C1608 JB 1A 105K-T T 61.4/33
C250 4030017490 S.CER C1608 JB 1A 105K-T T 64.1/44.7
