Icom IC-PW1 Service Manual

S.=Surface mount
L21 6180000990 COIL LAL 04NA 101K
L22 6140001000 COIL LR-123
L23 6180000990 COIL LAL 04NA 101K
L27 6110003440 COIL LA-538
L28 6110003460 COIL LA-537
L29 6110003460 COIL LA-537
L30 6180001220 COIL LAL 04NA 100K
L31 6110002260 COIL LA-403
L32 6180000990 COIL LAL 04NA 101K
L33 6910000670 COIL BL01RN1-A62-001
R2 7010004320 RESISTOR R20J 10 kΩ
R3 7010004320 RESISTOR R20J 10 kΩ
R4 7010004320 RESISTOR R20J 10 kΩ
R5 7010004320 RESISTOR R20J 10 kΩ
R7 7030007360 S.RESISTOR ERJ1WYJ470H (47 Ω)
R8 7030007360 S.RESISTOR ERJ1WYJ470H (47 Ω)
R9 7030007360 S.RESISTOR ERJ1WYJ470H (47 Ω)
R10 7030007360 S.RESISTOR ERJ1WYJ470H (47 Ω)
R11 7010004320 RESISTOR R20J 10 kΩ
R12 7010004320 RESISTOR R20J 10 kΩ
R13 7030007360 S.RESISTOR ERJ1WYJ470H (47 Ω)
R14 7030007360 S.RESISTOR ERJ1WYJ470H (47 Ω)
R15 7540000050 ABSORBER DSA-701MA
C1 4010004770 CERAMIC DE0910 SL 390J 6KV
C4 4010005130 CERAMIC DE0910 SL 470J 6KV
C5 4010005130 CERAMIC DE0910 SL 470J 6KV
C6 4010004770 CERAMIC DE0910 SL 390J 6KV
C7 4010004760 CERAMIC DE0910 SL 330J 6KV
C8 4010004770 CERAMIC DE0910 SL 390J 6KV
C9 4010004800 CERAMIC DE1210 SL 820J 6KV
C10 4010004790 CERAMIC DE1210 SL 680J 6KV
C11 4010004780 CERAMIC DE1010 SL 560J 6KV
C12 4010004810 CERAMIC DE1310 SL 101J 6KV
C13 4010004780 CERAMIC DE1010 SL 560J 6KV
C14 4010004780 CERAMIC DE1010 SL 560J 6KV
C15 4010004780 CERAMIC DE1010 SL 560J 6KV
C16 4010004770 CERAMIC DE0910 SL 390J 6KV
C18 4010004800 CERAMIC DE1210 SL 820J 6KV
C19 4010004780 CERAMIC DE1010 SL 560J 6KV
C20 4010004790 CERAMIC DE1210 SL 680J 6KV
C23 4010004800 CERAMIC DE1210 SL 820J 6KV
C24 4010004800 CERAMIC DE1210 SL 820J 6KV
C25 4010004820 CERAMIC DE1410 SL 121J 6KV
C26 4010004830 CERAMIC DE1510 SL 151J 6KV
C27 4010004830 CERAMIC DE1510 SL 151J 6KV
C28 4010004830 CERAMIC DE1510 SL 151J 6KV
C29 4010004820 CERAMIC DE1410 SL 121J 6KV
C30 4010004820 CERAMIC DE1410 SL 121J 6KV
C31 4010004810 CERAMIC DE1310 SL 101J 6KV
C32 4010004810 CERAMIC DE1310 SL 101J 6KV
C33 4010005130 CERAMIC DE0910 SL 470J 6KV
C34 4010004820 CERAMIC DE1410 SL 121J 6KV
C35 4010004290 CERAMIC DE1310 SL 181J 3KV
C36 4010004830 CERAMIC DE1510 SL 151J 6KV
C37 4010004830 CERAMIC DE1510 SL 151J 6KV
C38 4010004830 CERAMIC DE1510 SL 151J 6KV
C39 4010004290 CERAMIC DE1310 SL 181J 3KV
C40 4010004290 CERAMIC DE1310 SL 181J 3KV
C41 4010004750 CERAMIC DE1510 SL 151J 6KV
C42 4010004810 CERAMIC DE1310 SL 101J 6KV
C43 4010004740 CERAMIC DE1207 SL 271J 2KV
C44 4010004300 CERAMIC DE1410 SL 221J 3KV
C45 4010004740 CERAMIC DE1207 SL 271J 2KV
C46 4010004740 CERAMIC DE1207 SL 271J 2KV
C47 4010004830 CERAMIC DE1510 SL 151J 6KV
C48 4010004830 CERAMIC DE1510 SL 151J 6KV
C49 4320000640 DIP MICA DM20C681J5-N
C50 4320000640 DIP MICA DM20C681J5-N
C51 4010004300 CERAMIC DE1410 SL 221J 3KV
C52 4010004300 CERAMIC DE1410 SL 221J 3KV
C53 4010004300 CERAMIC DE1410 SL 221J 3KV
C54 4010004300 CERAMIC DE1410 SL 221J 3KV
C55 4320000640 DIP MICA DM20C681J5-N
C56 4320000640 DIP MICA DM20C681J5-N
C58 4040000150 BARRIER UAT 05X 472K
C60 4040000150 BARRIER UAT 05X 472K
C62 4040000150 BARRIER UAT 05X 472K
C64 4040000150 BARRIER UAT 05X 472K
5 - 5
REF ORDER
DESCRIPTION
NO. NO.
[FILTER UNIT]
C66 4040000150 BARRIER UAT 05X 472K
C68 4040000150 BARRIER UAT 05X 472K
C70 4040000150 BARRIER UAT 05X 472K
C71 4030004740 S.CERAMIC C2012 JB 1H 472K-T-A
C72 4030004740 S.CERAMIC C2012 JB 1H 472K-T-A
C73 4610001220 TRIMMER CVE101-56 (100P)
C74 4030005040 S.CERAMIC C2012 CH 1H 271J-T-A
C75 4040000150 BARRIER UAT 05X 472K
C76 4010005080 CERAMIC DE0707 SL 470J 3KV
C77 4010005070 CERAMIC DE0707 SL 390J 3KV
C78 4010005110 CERAMIC DE0910 SL 220J 6KV
C79 4010004760 CERAMIC DE0910 SL 330J 6KV
C80 4010004310 CERAMIC DE0705 SL 100D 1KV
C81 4010004310 CERAMIC DE0705 SL 100D 1KV
C83 4010005030 CERAMIC DE0707 SL 120J 3KV
C86 4010005030 CERAMIC DE0707 SL 120J 3KV
C87 4010005030 CERAMIC DE0707 SL 120J 3KV
C88 4010005110 CERAMIC DE0910 SL 220J 6KV
C89 4010005030 CERAMIC DE0707 SL 120J 3KV
C90 4010005030 CERAMIC DE0707 SL 120J 3KV
C91 4010005030 CERAMIC DE0707 SL 120J 3KV
C95 4010004710 CERAMIC DE0707 SL 150J 3KV
C96 4010005030 CERAMIC DE0707 SL 120J 3KV
C98 4010004700 CERAMIC DE0707 SL 220J 3KV
C100 4010000500 CERAMIC DD104 B 102K 50V
C101 4040000150 BARRIER UAT 05X 472K
C102 4040000150 BARRIER UAT 05X 472K
C103 4040000150 BARRIER UAT 05X 472K
C104 4040000150 BARRIER UAT 05X 472K
C107 4030004740 S.CERAMIC C2012 JB 1H 472K-T-A
C108 4030004740 S.CERAMIC C2012 JB 1H 472K-T-A
C110 4010004820 CERAMIC DE1410 SL 121J 6KV
C112 4010004800 CERAMIC DE1210 SL 820J 6KV
C115 4010006900 CERAMIC HE80SJ YB 472K 50V
C116 4010004770 CERAMIC DE0910 SL 390J 6KV
C117 4010004750 CERAMIC DE1510 SL 151J 6KV
C118 4010005120 CERAMIC DE0910 SL 270J 6KV
C119 4010005120 CERAMIC DE0910 SL 270J 6KV
C120 4010005030 CERAMIC DE0707 SL 120J 3KV
C123 4010005030 CERAMIC DE0707 SL 120J 3KV
C124 4010004800 CERAMIC DE1210 SL 820J 6KV
C125 4010004800 CERAMIC DE1210 SL 820J 6KV
C126 4010004790 CERAMIC DE1210 SL 680J 6KV
C128 4010005030 CERAMIC DE0707 SL 120J 3KV
C129 4010005030 CERAMIC DE0707 SL 120J 3KV
C130 4010005030 CERAMIC DE0707 SL 120J 3KV
C131 4010004290 CERAMIC DE1310 SL 181J 3KV
C133 4030008960 S.CERAMIC C2012 JB 1C 104K-T-A
C134 4030008960 S.CERAMIC C2012 JB 1C 104K-T-A
C135 4030006850 S.CERAMIC C1608 JB 1H 471K-T-A
C136 4030006850 S.CERAMIC C1608 JB 1H 471K-T-A
C137 4010004770 CERAMIC DE0910 SL 390J 6KV
C138 4010004300 CERAMIC DE1410 SL 221J 3KV
C139 4010004300 CERAMIC DE1410 SL 221J 3KV
C140 4010004300 CERAMIC DE1410 SL 221J 3KV
C141 4010004300 CERAMIC DE1410 SL 221J 3KV
C142 4010004300 CERAMIC DE1410 SL 221J 3KV
C143 4010004300 CERAMIC DE1410 SL 221J 3KV
RL1 6330000201 RELAY VS-12TBU-E-UC
RL2 6330000201 RELAY VS-12TBU-E-UC
RL3 6330000201 RELAY VS-12TBU-E-UC
RL4 6330000201 RELAY VS-12TBU-E-UC
RL5 6330000201 RELAY VS-12TBU-E-UC
RL6 6330000201 RELAY VS-12TBU-E-UC
RL7 6330000201 RELAY VS-12TBU-E-UC
RL8 6330000201 RELAY VS-12TBU-E-UC
RL9 6330000201 RELAY VS-12TBU-E-UC
RL10 6330000201 RELAY VS-12TBU-E-UC
RL11 6330000201 RELAY VS-12TBU-E-UC
RL12 6330000201 RELAY VS-12TBU-E-UC
RL13 6330000201 RELAY VS-12TBU-E-UC
RL14 6330000201 RELAY VS-12TBU-E-UC
RL15 6330001500 RELAY AW3033
RL16 6330001210 RELAY VB-12TBU-UC (UL3)
RL17 6330001210 RELAY VB-12TBU-UC (UL3)
REF ORDER
DESCRIPTION
NO. NO.
[FILTER UNIT]
