Icom IC-PW1 Service Manual

5 - 6
S.=Surface mount
WS1 8600035753 M.OTHER EX1900 P01*J01FI-3
WS2 8970022640 M.OTHER EX1900 1.5D COAXIAL (1)/FI
WS3 8970022650 M.OTHER EX1900 TEFLON COAXIAL (1)/FI
WS5 8970023250 M.OTHER EX1900 J LEAD SET (1)/FI
EP1 6910011330 TERMINAL OT-009 M3
EP2 6910011330 TERMINAL OT-009 M3
EP3 6910011330 TERMINAL OT-009 M3
EP4 6910011330 TERMINAL OT-009 M3
EP5 0910048749 PCB B 4888I
D1 1710000040 DIODE 1S953
D2 1710000040 DIODE 1S953
D3 1710000040 DIODE 1S953
L1 6140000970 COIL LR-119
L2 6140000970 COIL LR-119
L3 6140001950 COIL LR-211
L5 6140003290 COIL LR-365
R1 7070000830 RESISTOR ERG3SJ 101 (100 Ω)
R2 7070000830 RESISTOR ERG3SJ 101 (100 Ω)
R3 7010004070 RESISTOR R20J 100 Ω
R4 7010003950 RESISTOR R20J 10 Ω
R5 7010003950 RESISTOR R20J 10 Ω
R6 7100000580 RESISTOR SRW7P-M 50 Ω (500)
R7 7010003910 RESISTOR R20J 4.7 Ω
R8 7010003970 RESISTOR R20J 15 Ω
R9 7010003950 RESISTOR R20J 10 Ω
R10 7010003950 RESISTOR R20J 10 Ω
R11 7010004070 RESISTOR R20J 100 Ω
C1 4040000690 BARRIER UAT 08X 473K
C2 4040000690 BARRIER UAT 08X 473K
C3 4010004790 CERAMIC DE1210 SL 680J 6KV
C4 4010004790 CERAMIC DE1210 SL 680J 6KV
C5 4010005110 CERAMIC DE0910 SL 220J 6KV
C6 4010005110 CERAMIC DE0910 SL 220J 6KV
C7 4030005050 S.CERAMIC C2012 CH 1H 331J-T-A
C8 4030005050 S.CERAMIC C2012 CH 1H 331J-T-A
J1 6510017920 CONNECTOR 1811P342
J2 6510017920 CONNECTOR 1811P342
J3 6510017920 CONNECTOR 1811P342
J4 6510017920 CONNECTOR 1811P342
J5 6510003080 CONNECTOR RT01T-1.0B
J6 6510003080 CONNECTOR RT01T-1.0B
J7 6510003080 CONNECTOR RT01T-1.0B
WS1 8970022610 M.OTHER EX1900 0.8D COAXIAL (3)/CO
WS2 8600035730 M.OTHER EX1900 P01*J08CO
EP1 6910011330 TERMINAL OT-009 M3
EP2 6910011330 TERMINAL OT-009 M3
EP3 0910048756 PCB B 4889F
EP5 0910049250 PCB B 5039
REF ORDER
DESCRIPTION
NO. NO.
[FILTER UNIT]
IC1 1180001250 S.IC TA7808F (TE16L)
D1 1750000270 S.DIODE 1SS301 (TE85R)
D2 1750000270 S.DIODE 1SS301 (TE85R)
D3 1790000490 S.DIODE HSM88AS-TR
D4 1710000950 DIODE RG3D
D5 1710000950 DIODE RG3D
L1 6200003260 S.COIL NL 322522T-101J
L2 6140000970 COIL LR-119
L3 6140000970 COIL LR-119
L4 6140001000 COIL LR-123
L5 6180000900 COIL LAL 03NA 101K
L6 6140001000 COIL LR-123
L7 6200003260 S.COIL NL 322522T-101J
L8 6200003260 S.COIL NL 322522T-101J
L9 6200003260 S.COIL NL 322522T-101J
L10 6200003260 S.COIL NL 322522T-101J
L11 6200003260 S.COIL NL 322522T-101J
R1 7070000591 RESISTOR ERG1SJ 333 (33 kΩ)
R2 7030003480 S.RESISTOR ERJ3GEYJ 222 V (2.2 kΩ)
R3 7100000580 RESISTOR SRW7P-M 50 Ω (500)
R4 7100000580 RESISTOR SRW7P-M 50 Ω (500)
R5 7100000580 RESISTOR SRW7P-M 50 Ω (500)
R6 7100000580 RESISTOR SRW7P-M 50 Ω (500)
R7 7030008020 S.RESISTOR ERJ12YJ472H (4.7 kΩ)
R8 7030003400 S.RESISTOR ERJ3GEYJ 471 V (470 Ω)
R9 7030006180 S.RESISTOR ERJ1WYJ101H (100 Ω)
R10 7030006180 S.RESISTOR ERJ1WYJ101H (100 Ω)
R11 7030006070 S.RESISTOR ERJ12YJ101H (100 Ω)
R12 7030006070 S.RESISTOR ERJ12YJ101H (100 Ω)
R13 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R14 7030003590 S.RESISTOR ERJ3GEYJ 183 V (18 kΩ)
R15 7030003690 S.RESISTOR ERJ3GEYJ 124 V (120 kΩ)
R16 7510000140 THERMISTOR ERT-D2FHL 802S
R17 7030003460 S.RESISTOR ERJ3GEYJ 152 V (1.5 kΩ)
R18 7030006210 S.RESISTOR ERJ12YJ4R7H (4.7 Ω)
C1 4030006880 S.CERAMIC C1608 JB 1H 472K-T-A
C2 4030011790 S.CERAMIC GRM44-1 Y5V 684Z 100PT
C3 4030006880 S.CERAMIC C1608 JB 1H 472K-T-A
C4 4510005840 S.ELECTROLYTIC ECEV1HANR47R
C5 4030006880 S.CERAMIC C1608 JB 1H 472K-T-A
C7 4030006960 S.CERAMIC C1608 CH 1H 050C-T-A
C8 4010006900 CERAMIC HE80SJ YB 472K 50V
C9 4510006880 ELECTROLYTIC 100 MV 33 CZ
C10 4010006900 CERAMIC HE80SJ YB 472K 50V
C11 4010005740 CERAMIC HM60SJ SL 560J 500V
C14 4010005740 CERAMIC HM60SJ SL 560J 500V
C17 4010005740 CERAMIC HM60SJ SL 560J 500V
C18 4010005610 CERAMIC HM60SJ SL 100D 500V
C19 4010005690 CERAMIC HM60SJ SL 300J 500V
C20 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C21 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C22 4510005600 S.ELECTROLYTIC ECEV1CS100SR
C23 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C24 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C25 4510005600 S.ELECTROLYTIC ECEV1CS100SR
C26 4010005370 CERAMIC HM11SJ SL 331J 500V
RL1 6330001330 RELAY AG 201344
RL2 6330000470 RELAY NR-HD (12V) AE5343
J1 6510007020 CONNECTOR TMP-J01X-V6
J2 6510007020 CONNECTOR TMP-J01X-V6
J4 6510007020 CONNECTOR TMP-J01X-V6
J5 6510007020 CONNECTOR TMP-J01X-V6
J6 6510007020 CONNECTOR TMP-J01X-V6
J7 6510007020 CONNECTOR TMP-J01X-V6
J8 6510007020 CONNECTOR TMP-J01X-V6
J11 6510019970 S.CONNECTOR 52808-1090
WS1 8600035721 M.OTHER EX1900 P01*J03*09SP-1
REF ORDER
DESCRIPTION
NO. NO.
[SPLITR UNIT]
REF ORDER
DESCRIPTION
NO. NO.
[COMBINR UNIT]
