Icom IC-PW1 Service Manual

S.=Surface mount
EP1 0910048784 PCB B 4890D
EP2 9034901004 TUBE D=1.0, L=10 mm
EP3 9050409902 TUBE D=1.0, L=15 mm
EP4 9019000830 TUBE PLASTIC TUBE D=6.0, L=750 mm
EP5 9001602001 TUBE IRRAX 0.7 (d) L=10 mm
Q1 1560001000 FET MRF150MP (SRFJ150MP) PAIR
Q2 1560001000 FET MRF150MP (SRFJ150MP) PAIR
Q3 1560001000 FET MRF150MP (SRFJ150MP) PAIR
Q4 1560001000 FET MRF150MP (SRFJ150MP) PAIR
MF1 2710000620 FAN PUDC12Z4-992
MF2 2710000620 FAN PUDC12Z4-992
MF3 2710000620 FAN PUDC12Z4-992
W1 8900006990 CABLE OPC-683
W2 8900007360 CABLE OPC-711
W3 8900006990 CABLE OPC-683
W4 8900007360 CABLE OPC-711
WS1 8970022930 M.OTHER EX1900 J BOARD SET (4)/PA
D1 1750000270 S.DIODE 1SS301 (TE85R)
D2 1750000270 S.DIODE 1SS301 (TE85R)
D3 1750000270 S.DIODE 1SS301 (TE85R)
D4 1750000270 S.DIODE 1SS301 (TE85R)
L1 6110001730 COIL LA-262
L2 6140003040 COIL LR-322B
L3 6140002590 COIL LR-296
L4 6140000720 COIL LR-95
L5 6180000900 COIL LAL 03NA 101K
L6 6180000900 COIL LAL 03NA 101K
L7 6140002030 COIL LR-230
L9 6200003260 S.COIL NL 322522T-101J
L11 6200003950 S.COIL HF50ACC 322513-T
R2 7030003480 S.RESISTOR ERJ3GEYJ 222 V (2.2 kΩ)
R4 7030003480 S.RESISTOR ERJ3GEYJ 222 V (2.2 kΩ)
R5 7070000890 RESISTOR ERG3SJ 150 (15 Ω)
R6 7070000890 RESISTOR ERG3SJ 150 (15 Ω)
R7 7030006140 S.RESISTOR ERJ1WYJ560H (56 Ω)
R8 7030006140 S.RESISTOR ERJ1WYJ560H (56 Ω)
R9 7310003180 TRIMMER EVN-2ACA00 B24 (203)
R10 7310003180 TRIMMER EVN-2ACA00 B24 (203)
R11 7070000900 RESISTOR ERX3SJ 1R8 (1.8 Ω)
R12 7070000900 RESISTOR ERX3SJ 1R8 (1.8 Ω)
R15 7070000960 RESISTOR ERG3SJ 561 (560 Ω)
R16 7080001300 RESISTOR ERG3SJ 270 (27 Ω)
R17 7070000940 RESISTOR ERG3SJ 331 (330 Ω)
R18 7070000890 RESISTOR ERG3SJ 150 (15 Ω)
R19 7070000890 RESISTOR ERG3SJ 150 (15 Ω)
R20 7070000930 RESISTOR ERG3SJ 330 (33 Ω)
R21 7070001000 RESISTOR ERG3SJ 821 (820 Ω)
R23 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R24 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
5 - 7
REF ORDER
DESCRIPTION
NO. NO.
[SPLITR UNIT]
C1 4010005740 CERAMIC HM60SJ SL 560J 500V
C3 4030011790 S.CERAMIC GRM44-1 Y5V 684Z 100PT
C4 4030011790 S.CERAMIC GRM44-1 Y5V 684Z 100PT
C11 4030006480 S.CERAMIC GRM42-6 B 104K 50PT
C13 4030006480 S.CERAMIC GRM42-6 B 104K 50PT
C16 4030011790 S.CERAMIC GRM44-1 Y5V 684Z 100PT
C17 4030011790 S.CERAMIC GRM44-1 Y5V 684Z 100PT
C18 4030011790 S.CERAMIC GRM44-1 Y5V 684Z 100PT
C19 4030011790 S.CERAMIC GRM44-1 Y5V 684Z 100PT
C23 4510006830 ELECTROLYTIC 63 MV 470CZ
C24 4510006830 ELECTROLYTIC 63 MV 470CZ
C25 4030006480 S.CERAMIC GRM42-6 B 104K 50PT
C26 4030003410 S.CERAMIC GRM42-6 B 473K 50PT
C27 4030001170 S.CERAMIC GRM42-6 B 102K 50PT
C29 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C35 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C37 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C40 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C41 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C42 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C43 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C44 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C45 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C46 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C51 4030011790 S.CERAMIC GRM44-1 Y5V 684Z 100PT
C52 4030011790 S.CERAMIC GRM44-1 Y5V 684Z 100PT
C55 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C56 4030006880 S.CERAMIC C1608 JB 1H 472K-T-A
C57 4030006880 S.CERAMIC C1608 JB 1H 472K-T-A
J2 6510017920 CONNECTOR 1811P342
J3 6510019970 S.CONNECTOR 52808-1090
J4 6510019970 S.CONNECTOR 52808-1090
J5 6510003390 CONNECTOR B03B-EH-S
W6 7030003860 S.JUMPER ERJ3GE JPW V
WS1 8970022531 M.OTHER EX1900 J BOARD SET-1 (1)/PA-1
WS2 8970022540 M.OTHER EX1900 1.5D COAXIAL (1)/PA-1
EP1 6910011330 TERMINAL OT-009 M3
EP2 6910011330 TERMINAL OT-009 M3
EP3 6910000640 BEAD FSOH090RN
EP4 0910048706 PCB B 4884F
D1 1750000270 S.DIODE 1SS301 (TE85R)
D2 1750000270 S.DIODE 1SS301 (TE85R)
D3 1750000270 S.DIODE 1SS301 (TE85R)
D4 1750000270 S.DIODE 1SS301 (TE85R)
L1 6110001730 COIL LA-262
L2 6140003040 COIL LR-322B
L3 6140002590 COIL LR-296
L4 6140000720 COIL LR-95
L5 6180000900 COIL LAL 03NA 101K
L6 6180000900 COIL LAL 03NA 101K
L7 6140002030 COIL LR-230
L9 6200003260 S.COIL NL 322522T-101J
L11 6200003950 S.COIL HF50ACC 322513-T
R2 7030003480 S.RESISTOR ERJ3GEYJ 222 V (2.2 kΩ)
R4 7030003480 S.RESISTOR ERJ3GEYJ 222 V (2.2 kΩ)
R5 7070000890 RESISTOR ERG3SJ 150 (15 Ω)
R6 7070000890 RESISTOR ERG3SJ 150 (15 Ω)
R7 7030006140 S.RESISTOR ERJ1WYJ560H (56 Ω)
R8 7030006140 S.RESISTOR ERJ1WYJ560H (56 Ω)
R9 7310003180 TRIMMER EVN-2ACA00 B24 (203)
REF ORDER
DESCRIPTION
NO. NO.
[PA-1 BOARD]
REF ORDER
DESCRIPTION
NO. NO.
[PA UNIT]
REF ORDER
DESCRIPTION
NO. NO.
[PA-1 BOARD]
REF ORDER
DESCRIPTION
NO. NO.
[PA-2 BOARD]
