Icom IC-R2 - Basic Operation: Receiving Signals; Receiving Signals Guide; Setting Volume and Squelch Levels

5 - 2
■ CONNECTION
DC power supply
3.0 V/1.0 A
-
+
Standard signal
generator
AD-92SMA
Optional SMA–BNC adaptor
1/8" (3.5 mm)
3-conductor plug
Terminator for the entering
adjustment mode
68 kΩ
-
+
to [SP] jack
