Icom IC-R2 Service Manual

S.=Surface mount
C1 4030014200 S.CERAMIC ECUE1H101JCQ
C3 4030013970 S.CERAMIC C1005 JB 0J 104K-T-N
C4 4550006760 S.TANTALUM TEMSVB2 1A 336M-8R
C5 4030013850 S.CERAMIC ECUE1E102KBQ
C6 4030008680 S.CERAMIC C2012 JF 1C 105Z-T-A
C8 4030014120 S.CERAMIC ECUE1H100CCQ
C9 4030014120 S.CERAMIC ECUE1H100CCQ
C11 4030013970 S.CERAMIC C1005 JB 0J 104K-T-N
C12 4030013950 S.CERAMIC C1005 JB 1A 393K-T-N
C13 4030013970 S.CERAMIC C1005 JB 0J 104K-T-N
C14 4030013890 S.CERAMIC C1005 JB 1H 152K-T-N
C15 4510007130 S.ELECTROLYTIC EEFCD0J470R
C15 4550006670 S.TANTALUM ECST1AD107R
C16 4030013850 S.CERAMIC ECUE1E102KBQ
C17 4030008680 S.CERAMIC C2012 JF 1C 105Z-T-A
C18 4550006920 S.TANTALLUM TEMSVB2 1E 335M-8R
C19 4030008680 S.CERAMIC C2012 JF 1C 105Z-T-A
C24 4550006200 S.TANTALUM ECST0JY106R
C33 4030008680 S.CERAMIC C2012 JF 1C 105Z-T-A
C35 4030013850 S.CERAMIC ECUE1E102KBQ
C36 4030008680 S.CERAMIC C2012 JF 1C 105Z-T-A
C37 4030013850 S.CERAMIC ECUE1E102KBQ
C39 4030013970 S.CERAMIC C1005 JB 0J 104K-T-N
C40 4030013850 S.CERAMIC ECUE1E102KBQ
C41 4030013970 S.CERAMIC C1005 JB 0J 104K-T-N
C42 4030013970 S.CERAMIC C1005 JB 0J 104K-T-N
C43 4030013850 S.CERAMIC ECUE1E102KBQ
C44 4030013970 S.CERAMIC C1005 JB 0J 104K-T-N
C48 4030008680 S.CERAMIC C2012 JF 1C 105Z-T-A
C51 4030013850 S.CERAMIC ECUE1E102KBQ
C52 4030013850 S.CERAMIC ECUE1E102KBQ
C53 4030013970 S.CERAMIC C1005 JB 0J 104K-T-N
C57 4030013850 S.CERAMIC ECUE1E102KBQ
C58 4030013970 S.CERAMIC C1005 JB 0J 104K-T-N
C60 4550006690 S.TANTALUM ECST1AC476R
C61 4550006550 S.TANTALUM TEMSVD 0G 227M-12R
C62 4030013850 S.CERAMIC ECUE1E102KBQ
C63 4030013970 S.CERAMIC C1005 JB 0J 104K-T-N
C65 4030013970 S.CERAMIC C1005 JB 0J 104K-T-N
C66 4030013970 S.CERAMIC C1005 JB 0J 104K-T-N
C67 4030013970 S.CERAMIC C1005 JB 0J 104K-T-N
C68 4030013930 S.CERAMIC C1005 JB 1C 183K-T-N
C69 4030013910 S.CERAMIC C1005 JB 1E 472K-T-N
C70 4030013910 S.CERAMIC C1005 JB 1E 472K-T-N
C71 4030013880 S.CERAMIC C1005 JB 1H 222K-T-N
C72 4030013910 S.CERAMIC C1005 JB 1E 472K-T-N
C73 4030013970 S.CERAMIC C1005 JB 0J 104K-T-N
C74 4030013970 S.CERAMIC C1005 JB 0J 104K-T-N
C76 4030013970 S.CERAMIC C1005 JB 0J 104K-T-N
C77 4030013970 S.CERAMIC C1005 JB 0J 104K-T-N
C78 4030013960 S.CERAMIC C1005 JB 1A 473K-T-N
C79 4030014200 S.CERAMIC ECUE1H101JCQ
C80 4030013970 S.CERAMIC C1005 JB 0J 104K-T-N
C81 4030013970 S.CERAMIC C1005 JB 0J 104K-T-N
C82 4030013970 S.CERAMIC C1005 JB 0J 104K-T-N
C86 4030008680 S.CERAMIC C2012 JF 1C 105Z-T-A
C87 4030008680 S.CERAMIC C2012 JF 1C 105Z-T-A
C88 4550006320 S.TANTALUM ECST0JY475R
C89 4550006320 S.TANTALUM ECST0JY475R
C90 4030013910 S.CERAMIC C1005 JB 1E 472K-T-N
C91 4030013970 S.CERAMIC C1005 JB 0J 104K-T-N
C92 4030013970 S.CERAMIC C1005 JB 0J 104K-T-N
C93 4030013930 S.CERAMIC C1005 JB 1C 183K-T-N
C94 4030008680 S.CERAMIC C2012 JF 1C 105Z-T-A
C96 4550006320 S.TANTALUM ECST0JY475R
C97 4030013970 S.CERAMIC C1005 JB 0J 104K-T-N
C98 4550006760 S.TANTALUM TEMSVB2 1A 336M-8R
C100 4030013970 S.CERAMIC C1005 JB 0J 104K-T-N
C101 4030013850 S.CERAMIC ECUE1E102KBQ
C102 4030014200 S.CERAMIC ECUE1H101JCQ
C103 4030013970 S.CERAMIC C1005 JB 0J 104K-T-N
C106 4030013970 S.CERAMIC C1005 JB 0J 104K-T-N
C107 4030011810 S.CERAMIC C1608 JB 1A 224K-T-N
C108 4030013850 S.CERAMIC ECUE1E102KBQ
C114 4030013970 S.CERAMIC C1005 JB 0J 104K-T-N
C116 4030013970 S.CERAMIC C1005 JB 0J 104K-T-N
C118 4550006140 S.TANTALUM ECST1EY474R
C119 4030008680 S.CERAMIC C2012 JF 1C 105Z-T-A
C120 4030008680 S.CERAMIC C2012 JF 1C 105Z-T-A
C121 4030008680 S.CERAMIC C2012 JF 1C 105Z-T-A
C123 4030013970 S.CERAMIC C1005 JB 0J 104K-T-N
DS2 5040002230 S.LED CL-200YG-C-TS
DS8 5030001610 LCD DLC-7995YBGF
S8 2230000900 S.SWITCH JPM1990-2013R
S9 2250000390 ENCODER TP90N00E20-16F-1995
S10 2230000900 S.SWITCH JPM1990-2013R
J1 6510020560 S.CONNECTOR AXK5S40340P
J2 6450001910 CONNECTOR HSJ1594-010050
W2 7030003860 S.JUMPER ERJ3GE JPW V
W3 7030003860 S.JUMPER ERJ3GE JPW V
W5 7030003860 S.JUMPER ERJ3GE JPW V
EP1 0910050773 PCB B 5164C
EP2 8930046581 LCD CONTACT SRCN-1995-SP-N-W-1
IC1 1110004020 S.IC µPC2757T-E3
IC2 1110003200 S.IC TA31136FN (EL)
IC3 1130007610 S.IC µPD3140GS-E1 (DS8)
IC4 1110003470 S.IC µPC2746T-E3
IC10 1110004020 S.IC µPC2757T-E3
IC11 1110003470 S.IC µPC2746T-E3
Q1 1590001190 S.TRANSISTOR XP6501-(TX).AB
Q2 1560000540 S.FET 2SK880-Y (TE85R)
Q4 1590001190 S.TRANSISTOR XP6501-(TX).AB
Q5 1530003580 S.TRANSISTOR 2SC5231C8-TL
Q6 1530003610 S.TRANSISTOR FH102-TL
Q14 1530003610 S.TRANSISTOR FH102-TL
Q24 1530003590 S.TRANSISTOR 2SC5277D2-TL
Q26 1530003590 S.TRANSISTOR 2SC5277D2-TL
Q28 1530003260 S.TRANSISTOR 2SC5006-T1
Q29 1590001940 S.TRANSISTOR DTC144EE TL
Q30 1530003260 S.TRANSISTOR 2SC5006-T1
Q31 1530003610 S.TRANSISTOR FH102-TL
Q33 1590001810 S.TRANSISTOR XP1113 (TX)
Q35 1590002650 S.TRANSISTOR UPA805T-T1
Q36 1530003580 S.TRANSISTOR 2SC5231C8-TL
Q37 1530003630 S.TRANSISTOR 2SC4617 TLS
Q40 1530003580 S.TRANSISTOR 2SC5231C8-TL
Q41 1590002430 S.TRANSISTOR DTA144EE TL
Q43 1530003580 S.TRANSISTOR 2SC5231C8-TL
Q44 1590001660 S.TRANSISTOR XP4312 (TX)
Q45 1530003010 S.TRANSISTOR 2SC4117-GR (TE85R)
Q46 1590001660 S.TRANSISTOR XP4312 (TX)
Q501 1590002430 S.TRANSISTOR DTA144EE TL
Q502 1590001810 S.TRANSISTOR XP1113 (TX)
Q503 1590001810 S.TRANSISTOR XP1113 (TX)
Q504 1590001810 S.TRANSISTOR XP1113 (TX)
Q505 1530002600 S.TRANSISTOR 2SC4215-O (TE85R)
Q506 1590002430 S.TRANSISTOR DTA144EE TL
Q507 1530003590 S.TRANSISTOR 2SC5277D2-TL
Q508 1590001660 S.TRANSISTOR XP4312 (TX)
Q509 1590002430 S.TRANSISTOR DTA144EE TL
D1 1720000370 S.VARICAP HVU350TRF
D2 1720000370 S.VARICAP HVU350TRF
D3 1790001620 S.DIODE ISV308 (TPL3)
D4 1720000370 S.VARICAP HVU350TRF
D5 1720000370 S.VARICAP HVU350TRF
D11 1790001620 S.DIODE ISV308 (TPL3)
D13 1790001620 S.DIODE ISV308 (TPL3)
D17 1720000700 S.VARICAP 1SV305 (TPL3)
D18 1720000370 S.VARICAP HVU350TRF
D20 1790001590 S.DIODE MA6S718 (TX)
D21 1790001590 S.DIODE MA6S718 (TX)
6 - 2
REF ORDER
DESCRIPTION
NO. NO.
[LOGIC UNIT]
REF ORDER
DESCRIPTION
NO. NO.
[LOGIC UNIT]
REF ORDER
DESCRIPTION
NO. NO.
[RF UNIT]
