Icom IC-R3 Service Manual

SECTION 2 INSIDE VIEWS
2 - 1
•
RF, RF-B, VCO AND FM-TV UNITS
•
LOGIC UNIT
2nd IF circuit
(FI3: FL-319)
FM-TV UNIT
([OTH-2] only])
RF-B UNIT
VCO UNIT
RF UNIT
CPU system clock
(X1: CR-613)
Power amplifier
(IC3: XC62FP3002MR)
DC-DC converter
CPU
(IC1: M38267M8L-256GP)
PLL converter circuit
(IC15: TA31056F)
IC801: MB3776APFV
Q804: 2SK2493
T1: TO-47
