Icom IC-R30 Service Manual

4-4
ADJUSTMENT
ADJUSTMENT DISPLAY
SETTING CONDITION VALUE
ITEM FREQUENCY MODE SUB
Noise
squelch
42 A NSQL 22.500 FM 14 5.10 0 Set the standard signal generator to:
Frequency: The same as the displayed
frequency on the MAIN band.
Modulation: 1 kHz
Deviation: ±3.5 kHz
Level: –26 dBµ (–133 dBm)
Push
[ENTER].
(Automatic
adjustment)
43 A NSQL 40.10 0 FM 145.100
44 A NSQL 63.10 0 FM 145.100
45 A NSQL 92.10 0 FM 145.100
46 A NSQL 14 5.10 0 FM 145.100
47 B NSQL 145.10 0 FM 145.10 0
48 A NSQL 217.10 0 FM 217.10 0
49 B NSQL 217.10 0 FM 217.10 0
50 A NSQL 320.100 FM 32 0.10 0
51 B NSQL 320.100 FM 320.10 0
52 A NSQL 470.100 FM 470.100
53 B NSQL 470.100 FM 470.100
54 A NSQL 65 0.10 0 FM 145.10 0
55 A NSQL 1167. 50 0 FM 14 5 .10 0
56 A NSQL 23 41.100 FM 145.100 Set the standard signal generator to:
Level: –22 dBµ (–129 dBm)
4-2 ADJUSTMENT (CONTINUED)
