Icom IC-R6 Service Manual

6 - 6
REF PARTS
DESCRIPTION M.
H/V
NO. NO.
LOCATION
[LOGIC UNIT]
C351 4030016930 S.CER C1005 JB 1A 104K-T B 19.5/22.1
C352 4030016930 S.CER C1005 JB 1A 104K-T B 18.6/18.9
C400 4030016930 S.CER C1005 JB 1A 104K-T B 19.7/25.6
C402 4030016930 S.CER C1005 JB 1A 104K-T B 26.1/20.1
C403 4030017490 S.CER C1608 JB 1A 105K-T B 33.9/7.5
C404 4030017780 S.CER C1005 JB 1H 472K-T B 21.2/19.6
C406 4030017780 S.CER C1005 JB 1H 472K-T B 19.4/27.6
C451 4550006050 S.TAN TEESVA 0J 106M8R B 10.3/50.9
C452 4520000030 S.NIO NOJB107M004R B 6.6/33.1
C453 4510010090 S.ELE 10 CE 33 BSS B 20.2/48.4
C455 4030016930 S.CER C1005 JB 1A 104K-T B 18.7/42.6
C458 4550000530 S.TAN TEESVA 1V 104M8R B 12/40.6
C500 4030017460 S.CER C1005 JB 1H 102K-T B 43.5/50.1
C501 4030017460 S.CER C1005 JB 1H 102K-T B 40.1/50.1
C503 4030017460 S.CER C1005 JB 1H 102K-T B 34.6/39.6
C504 4030017460 S.CER C1005 JB 1H 102K-T T 53.8/49.2
C505 4550002950 S.TAN TEESVA 0J 335M8R B 29.1/19.3
C506 4030018900 S.CER C1005 JB 0J 474K-T B 17.9/28.4
C507 4030017460 S.CER C1005 JB 1H 102K-T B 13.3/36.5
C508 4030017790 S.CER C1005 JB 1H 682K-T T 53.9/3.1
C510 4030016930 S.CER C1005 JB 1A 104K-T B 34.3/4.7
C514 4030016930 S.CER C1005 JB 1A 104K-T B 20/19.6
C515 4030016950 S.CER C1005 JB 1A 473K-T B 13.2/49.6
C516 4030016930 S.CER C1005 JB 1A 104K-T B 17.8/26.6
C517 4030016930 S.CER C1005 JB 1A 104K-T B 19.9/37.1
C518 4030018860 S.CER C1005 JB 0J 105K-T T 29.5/30.7
C519 4030018860 S.CER C1005 JB 0J 105K-T B 73.8/49.3
C520 4030016930 S.CER C1005 JB 1A 104K-T B 20.1/43.1
C521 4030018860 S.CER C1005 JB 0J 105K-T T 31/27.4
C522 4030018860 S.CER C1005 JB 0J 105K-T T 30.9/26.5
C523 4030018860 S.CER C1005 JB 0J 105K-T T 30.7/25.5
C524 4030018860 S.CER C1005 JB 0J 105K-T B 26/23.4
C525 4030017460 S.CER C1005 JB 1H 102K-T T 75.9/48.6
C526 4030017460 S.CER C1005 JB 1H 102K-T T 19.2/4.5
C528 4030016930 S.CER C1005 JB 1A 104K-T T 29.2/32.5
C529 4030017570 S.CER C1005 CH 1H 040B-T B 20.5/26.5
C530 4030018860 S.CER C1005 JB 0J 105K-T T 58.1/2
C531 4030017490 S.CER C1608 JB 1A 105K-T T 63.7/49
C532 4030017490 S.CER C1608 JB 1A 105K-T T 58.4/44.8
C533 4030019460 S.CER C1608 JB 0J 106M-T B 40.6/23.5
C534 4520000030 S.NIO NOJB107M004R B 11.3/33.1
J2 6450002010 S.CON HSJ1501-011010 B 6.3/25
J3 6510020561 S.CON AXK5S40347YG B 27.2/31.3
J500 6450002131 CON 04-730A3-02BKA
DS1 5030003251 LCD TAK-35455 RX3250 <ITAK>
DS2 5040003480 S.LED VFY1111C-4BX-4C-TR T 13.8/48.8
DS3 5040003480 S.LED VFY1111C-4BX-4C-TR T 14.1/3.2
S6 2250000390 ENC TP90N00E20-16F-1995
S9 2260001900 SWI SW-149 (SKHLLD)
S10 2230001070 S.SWI JPM1990-2711R B 26.3/4.5
W1 7030012290 JUM RDS2T0R0
W600 7030012290 JUM RDS2T0R0
EP1 6910020610 S.BEA BLM15BD102SN1D T 11.1/37.8
EP2 6910020610 S.BEA BLM15BD102SN1D T 10.9/41.3
EP4 8930058920 LCD SRCN-2605-SP-N-W (SHJ)
EP10 6910014680 S.BEA MMZ1608Y 121BT B 11.2/37
EP11 6910014680 S.BEA MMZ1608Y 121BT B 4/29.9
EP12 6910014690 S.BEA MPZ1608S221A-T B 33.6/40
EP13 6910014690 S.BEA MPZ1608S221A-T T 22.7/43.2
EP14 6910014690 S.BEA MPZ1608S221A-T T 74.9/44.7
EP15 6910014690 S.BEA MPZ1608S221A-T T 74.7/6.2
EP16 6910020610 S.BEA BLM15BD102SN1D B 1.8/20.5
EP17 6910018460 S.BEA MMZ1005Y102C-T T 30.1/32.5
EP18 6910021630 S.BEA BLM18RK102SN1D B 38/23.5
EP19 6910018460 S.BEA MMZ1005Y102C-T T 21.3/10.9
EP20 6910018460 S.BEA MMZ1005Y102C-T T 23.5/9.4
EP21 6910018460 S.BEA MMZ1005Y102C-T T 23.5/7.8
EP22 6910018460 S.BEA MMZ1005Y102C-T T 25.5/6.8
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
S.=Surface mount

Icom IC-R6 Specifications

General

Product color	Black
Channels quantity	1550 channels
Supported radio bands	AM, FM
Battery type	AA
Number of batteries supported	2
Impedance	16 Ω
Frequency range	0.1 - 1309.995 MHz
Product type	Portable CB radio
Housing material	-

Weight and Dimensions

Depth	29.8 mm
Width	58 mm
Height	86 mm
Weight	200 g
