SPECIFICATIONS AND OPTIONS
20
6
Installing the AH-40
Specification
• Frequency range: 1616 ~ 1626.5 MHz
• Antenna impedance:
• Operating temperature range:
• VSWR: 2.0:1 (At resonance point)
• 36 (d) × 52.3 (H) mm,
(1.4 (d) × 2.1 (H) inches)
• Weight (approximate): 55 g, 0.12 lb
• Connector: SMA
6. Attach antenna unit cover.
Y Type
Screw
NOTE:
When the AH-40 cable is inserted into the antenna
cover, or the antenna unit cover is removed, the
antenna unit does not meet IP67 requirements for
waterproof protection.
