Icom IC-T81E - Logic Unit

S.=Surface mount
IC1 1140008110 S.IC M38267E8GP [USA-1] only
1140008100 S.IC M38267M8L-230GP [other]
IC2 1130009160 S.IC X24320S8I-2.5T4
IC3 1110004890 S.IC XC6371A500PR
IC4 1130006220 S.IC TC4W53FU (TE12L)
IC5 1110004530 S.IC M62368GP 70ED
IC141 1180001720 S.IC S-81332HG-KC-T1
IC142 1110004540 S.IC S-80928ALMP-DAR-T2
IC201 1110001810 S.IC TA7368F (TP1)
IC202 1110004520 S.IC M5222FP 600C
IC203 1110002750 S.IC TA75S01F (TE85R)
IC241 1110003780 S.IC NJM2902V-TE1
IC301 1110004110 S.IC BA4510F-T1
IC701 1110003490 S.IC TA31136FN (D,EL)
IC751 1130004200 S.IC TC4S66F (TE85R)
Q1 1590001690 S.TRANSISTOR UN9115 (TX)
Q3 1590001980 S.TRANSISTOR XP4315 (TX)
Q7 1590001170 S.TRANSISTOR XP1501-(TX) AB
Q8 1520000460 S.TRANSISTOR 2SB1132 T100 R
Q141 1590001140 S.TRANSISTOR UN9210 (TX)
Q142 1590001170 S.TRANSISTOR XP1501-(TX) AB
Q145 1520000460 S.TRANSISTOR 2SB1132 T100 R
Q151 1540000350 S.TRANSISTOR 2SD2216-S (TX)
Q201 1520000650 S.TRANSISTOR 2SB1201-S-TL
Q202 1590001170 S.TRANSISTOR XP1501-(TX) AB
Q301 1590001690 S.TRANSISTOR UN9115 (TX)
Q302 1520000430 S.TRANSISTOR 2SB1462-R (TX)
Q303 1590001440 S.TRANSISTOR UN9214 (TX)
Q304 1550000010 S.FET 2SJ364-Q (TX)
Q305 1550000010 S.FET 2SJ364-Q (TX)
Q306 1550000010 S.FET 2SJ364-Q (TX)
Q307 1590001440 S.TRANSISTOR UN9214 (TX)
Q308 1590001210 S.TRANSISTOR XP5601-(TX) AB
Q309 1550000010 S.FET 2SJ364-Q (TX)
Q341 1590001440 S.TRANSISTOR UN9214 (TX)
Q361 1550000010 S.FET 2SJ364-Q (TX)
Q602 1590001690 S.TRANSISTOR UN9115 (TX)
Q603 1590001660 S.TRANSISTOR XP4312 (TX)
Q702 1590001690 S.TRANSISTOR UN9115 (TX)
Q751 1590001170 S.TRANSISTOR XP1501-(TX) AB
Q752 1540000350 S.TRANSISTOR 2SD2216-S (TX)
Q753 1590001690 S.TRANSISTOR UN9115 (TX)
Q754 1540000350 S.TRANSISTOR 2SD2216-S (TX)
D2 1790000970 S.DIODE MA729 (TX)
D3 1790001250 S.DIODE MA2S111-(TX)
D4 1790001250 S.DIODE MA2S111-(TX)
D51 1790000820 S.DIODE MA132K (TX) [UK], [AUS]
1790000830 S.DIODE MA132HK (TX) [EUR], [USA-1]
1790000850 S.DIODE MA132WK (TX) [SEA]
D52 1790000830 S.DIODE MA132HK (TX)
[ITA], [AUS], [SEA], [USA-1]
D53 1790000850 S.DIODE MA132WK (TX) except [ITA]
D55 1790001250 S.DIODE MA2S111-(TX) except [ITA]
D58 1790001200 S.DIODE MA6S121 (TX)
D59 1790001200 S.DIODE MA6S121 (TX)
D61 1790001250 S.DIODE MA2S111-(TX) except [ITA]
D141 1790001250 S.DIODE MA2S111-(TX)
D143 1790001250 S.DIODE MA2S111-(TX)
D144 1790001240 S.DIODE MA2S728-(TX)
D151 1730002330 S.ZENER MA8100-M (TX)
D152 1790001250 S.DIODE MA2S111-(TX)
D304 1730000020 S.ZENER RD5.1M-T2B3
D701 1750000360 S.DIODE 1SS364 (TE85L)
D702 1750000360 S.DIODE 1SS364 (TE85L)
FI701 2020001480 S.CERAMIC PBFC450R15DR
X1 6050010530 S.XTAL CR-639 (5.039 MHz)
L1 6200006720 S.COIL 5CA-395KN-0369AQ=P3
L2 6200003550 S.COIL MLF1608A 4R7K-T
L3 6200001820 S.COIL LQH 3N 331K 04
L702 6150005010 S.COIL LS-528 (637AN-0223GW=P3)
R1 7510000910 S.THERMISTOR NTCCF2012 4AH 473KC-T
R2 7030005090 S.RESISTOR ERJ2GEJ 104 X (100 kΩ)
R4 7030008280 S.RESISTOR ERJ2GEJ 271 X (270 Ω)
R5 7030008280 S.RESISTOR ERJ2GEJ 271 X (270 Ω)
R8 7030005050 S.RESISTOR ERJ2GEJ 103 X (10 kΩ)
R9 7030005110 S.RESISTOR ERJ2GEJ 224 X (220 kΩ)
R10 7030005220 S.RESISTOR ERJ2GEJ 223 X (22 kΩ)
R12 7030005840 S.RESISTOR RR0510R-473-D (47 kΩ)
R13 7030005840 S.RESISTOR RR0510R-473-D (47 kΩ)
R14 7030005840 S.RESISTOR RR0510R-473-D (47 kΩ)
R16 7030005050 S.RESISTOR ERJ2GEJ 103 X (10 kΩ)
R17 7030005090 S.RESISTOR ERJ2GEJ 104 X (100 kΩ)
R18 7030005040 S.RESISTOR ERJ2GEJ 472 X (4.7 kΩ)
R19 7030005040 S.RESISTOR ERJ2GEJ 472 X (4.7 kΩ)
R21 7030005120 S.RESISTOR ERJ2GEJ 102 X (1 kΩ)
R22 7030005120 S.RESISTOR ERJ2GEJ 102 X (1 kΩ)
R23 7030005120 S.RESISTOR ERJ2GEJ 102 X (1 kΩ)
R24 7030005120 S.RESISTOR ERJ2GEJ 102 X (1 kΩ)
R25 7030005120 S.RESISTOR ERJ2GEJ 102 X (1 kΩ)
R26 7030005040 S.RESISTOR ERJ2GEJ 472 X (4.7 kΩ)
R27 7030005120 S.RESISTOR ERJ2GEJ 102 X (1 kΩ)
R28 7030005120 S.RESISTOR ERJ2GEJ 102 X (1 kΩ)
R29 7030005120 S.RESISTOR ERJ2GEJ 102 X (1 kΩ)
R30 7030005120 S.RESISTOR ERJ2GEJ 102 X (1 kΩ)
R31 7030005120 S.RESISTOR ERJ2GEJ 102 X (1 kΩ)
R32 7030005120 S.RESISTOR ERJ2GEJ 102 X (1 kΩ)
R33 7030005120 S.RESISTOR ERJ2GEJ 102 X (1 kΩ)
R34 7030005120 S.RESISTOR ERJ2GEJ 102 X (1 kΩ)
R35 7030005120 S.RESISTOR ERJ2GEJ 102 X (1 kΩ)
R36 7030005120 S.RESISTOR ERJ2GEJ 102 X (1 kΩ)
R37 7030005120 S.RESISTOR ERJ2GEJ 102 X (1 kΩ)
R38 7030005090 S.RESISTOR ERJ2GEJ 104 X (100 kΩ)
R39 7030005090 S.RESISTOR ERJ2GEJ 104 X (100 kΩ)
R42 7030008280 S.RESISTOR ERJ2GEJ 271 X (270 Ω)
R51 7030005160 S.RESISTOR ERJ2GEJ 105 X (1 MΩ)
R53 7030005110 S.RESISTOR ERJ2GEJ 224 X (220 kΩ)
R54 7030005110 S.RESISTOR ERJ2GEJ 224 X (220 kΩ)
R55 7030005110 S.RESISTOR ERJ2GEJ 224 X (220 kΩ)
R56 7030005040 S.RESISTOR ERJ2GEJ 472 X (4.7 kΩ)
R141 7030007340 S.RESISTOR ERJ2GEJ 153 X (15 kΩ)
R142 7030005830 S.RESISTOR RR0510R-223-D (22 kΩ)
R143 7030005050 S.RESISTOR ERJ2GEJ 103 X (10 kΩ)
R144 7030005040 S.RESISTOR ERJ2GEJ 472 X (4.7 kΩ)
R145 7030005050 S.RESISTOR ERJ2GEJ 103 X (10 kΩ)
R146 7030005160 S.RESISTOR ERJ2GEJ 105 X (1 MΩ)
R148 7030008270 S.RESISTOR RR0510R-104-D (100 kΩ)
R151 7030005120 S.RESISTOR ERJ2GEJ 102 X (1 kΩ)
R153 7030005240 S.RESISTOR ERJ2GEJ 473 X (47 kΩ)
R154 7030005050 S.RESISTOR ERJ2GEJ 103 X (10 kΩ)
R196 7030005110 S.RESISTOR ERJ2GEJ 224 X (220 kΩ)
R197 7030005050 S.RESISTOR ERJ2GEJ 103 X (10 kΩ)
R201 7030005530 S.RESISTOR ERJ2GEJ 100 X (10 Ω)
R202 7030007270 S.RESISTOR ERJ2GEJ 151 X (150 Ω)
R203 7030000240 S.RESISTOR MCR10EZHJ 68 Ω (680)
R204 7030000240 S.RESISTOR MCR10EZHJ 68 Ω (680)
R205 7030000240 S.RESISTOR MCR10EZHJ 68 Ω (680)
R206 7030005040 S.RESISTOR ERJ2GEJ 472 X (4.7 kΩ)
R207 7030005160 S.RESISTOR ERJ2GEJ 105 X (1 MΩ)
R208 7030005050 S.RESISTOR ERJ2GEJ 103 X (10 kΩ)
R209 7030005120 S.RESISTOR ERJ2GEJ 102 X (1 kΩ)
R210 7030005950 S.RESISTOR RR0510R-123-D (12 kΩ)
R211 7030005820 S.RESISTOR RR0510P-103-D (10 kΩ)
R212 7030005220 S.RESISTOR ERJ2GEJ 223 X (22 kΩ)
R213 7030005830 S.RESISTOR RR0510R-223-D (22 kΩ)
R214 7030008270 S.RESISTOR RR0510R-104-D (100 kΩ)
R215 7030005040 S.RESISTOR ERJ2GEJ 472 X (4.7 kΩ)
R241 7030005160 S.RESISTOR ERJ2GEJ 105 X (1 MΩ)
R242 7030005170 S.RESISTOR ERJ2GEJ 474 X (470 kΩ)
R243 7030005080 S.RESISTOR ERJ2GEJ 823 X (82 kΩ)
R244 7030005080 S.RESISTOR ERJ2GEJ 823 X (82 kΩ)
6 - 1
REF ORDER
DESCRIPTION
NO. NO.
[LOGIC UNIT]
REF ORDER
DESCRIPTION
NO. NO.
[LOGIC UNIT]
SECTION 6 PARTS LIST
