PANEL DESCRIPTION
t TONE INDICATORS (p. 70)
➥ Appears when the following tone functions are activated.
• Subaudible tone encoder — “T” appears. (p. 29)
• Tone squelch — “T SQL” appears. (p. 71)
• Pocket beep — “T SQLS” appears. (p. 71)
• DTCS squelch — “DTCS” appears. (p. 71)
• DTCS beep — “SDTCS” appears. (p. 71)
➥ “S” blinks when the correct tone or code is received
during pocket/DTCS beep operation. (p. 71)
y RIT INDICATOR (p. 27)
Appears when the RIT (Receive Incremental Tuning) func-
tion for 630.000 MHz and above is in use.
u SKIP SCAN INDICATOR (p. 47)
➥ “SKIP” appears when a selected memory channel is set
as a skip channel.
➥ “PSKIP” appears when the memory channel frequency
is set as a skip frequency in memory mode.
➥ “P SKIP” appears when the frequency skip function is
turned ON in VFO mode.
i PRIORITY WATCH INDICATOR (p. 50)
Appears when priority watch is in use.
o MEMORY MODE INDICATOR (p. 20)
Appears when a memory channel is selected.
!0 MEMORY CHANNEL NUMBER READOUT (p. 20)
Shows the memory or call channel number, etc.
!1 S/RF INDICATORS (p. 28)
Shows the relative signal strength while receiving. Shows
the relative output power while transmitting.
!2 LOW POWER INDICATOR (p. 28)
Appears when low output power is selected.
!3 VOLUME EXCHANGE INDICATOR (p. 23)
Appears when the functions of tuning dial and [Y]/[Z]
switches are exchanged.
!4 BATTERY INDICATORS
➥ Both segments appear when the batteries have ample
capacity.
•They do not appear when operating with an external power
source.
➥ Only the right segment “” appears when the batteries
are nearing exhaustion.
➥ Blinks while charging the attached Li-Ion battery pack.
!5 ATTENUATOR INDICATOR (p. 27)
Appears when the attenuator is in use.
ww
PANEL DESCRIPTION
