Icom IC-V80E - Inside Views; Main Unit Top View

2 - 1
SECTION 2
.
INSIDE VIEWS
• MAIN UNIT
(TOP VIEW)
ANALOG SW
(IC4)
APC CTRL/
MIC AMP/
LPF/HPF
(IC3)
IF 1ST AMP
(Q14)
2ND IF FILTERS
(FI1 and FI3)
INTERNAL MIC
CONTROLLER
(Q82)
BUFFER
(Q7)
TX PRE-DRIVE AMP
(Q3)
TONE FILTER
(Q53)
REFERENCE FREQ. OSCILLATOR
(X1)
