Icom ID-1

[MAIN UNIT]
REF ORDER
DESCRIPTION M.
H/V
NO. NO.
LOCATION
L71 6200006990 S.COL ELJRE 56NG-F T 40.4/78.9
L72 6200006990 S.COL ELJRE 56NG-F T 47.5/72.2
L73 6200006990 S.COL ELJRE 56NG-F T 42.3/68.8
L74 6200009350 S.COL ELJRE R22G-F3 T 41.5/61.3
L131 6200002710 S.COL ELJFC 1R8K-F T 41.8/55.5
L132 6200001980 S.COL NL 252018T-1R0J T 41.8/52.1
L191 6200002710 S.COL ELJFC 1R8K-F T 50.6/35.8
L192 6200002000 S.COL NL 252018T-3R3J T 44.6/48.8
L390 6200006990 S.COL ELJRE 56NG-F T 31.4/53.4
L391 6200006990 S.COL ELJRE 56NG-F T 37/51.3
L400 6200006990 S.COL ELJRE 56NG-F T 9.4/66.9
L404 6200006990 S.COL ELJRE 56NG-F B 14.9/63.7
L415 6200006990 S.COL ELJRE 56NG-F T 9.4/49.4
L470 6200006990 S.COL ELJRE 56NG-F T 23.5/69.5
L471 6200005640 S.COL ELJRE 6N8Z-F T 25.1/71.2
L472 6200009390 S.COL C3328A-8N0J-A T 24.6/78.2
L473 6200002630 S.COL NL 252018T-R10J T 20/79.4
L474 6200005620 S.COL ELJRE 4N7Z-F T 32.2/67.6
L475 6200005640 S.COL ELJRE 6N8Z-F T 32.2/70.2
L476 6200005650 S.COL ELJRE 8N2Z-F T 35.3/73.4
L477 6200005640 S.COL ELJRE 6N8Z-F T 35.3/77.3
L480 6200005640 S.COL ELJRE 6N8Z-F B 27.5/74.6
L481 6200006990 S.COL ELJRE 56NG-F T 14.3/77.8
L550 6200001980 S.COL NL 252018T-1R0J B 21.7/36.1
L551 6200001980 S.COL NL 252018T-1R0J T 28.3/51
L552 6200001980 S.COL NL 252018T-1R0J T 33.8/49.3
L554 6200006990 S.COL ELJRE 56NG-F B 24.9/37.6
L555 6200009350 S.COL ELJRE R22G-F3 B 23.7/27.5
L556 6200009350 S.COL ELJRE R22G-F3 B 2.5/44.9
L557 6200009350 S.COL ELJRE R22G-F3 T 4/29.7
L630 6200009700 S.COL C6328A-28NG-A T 17.7/39.1
L631 6200005700 S.COL ELJRE 22NG-F B 21.4/30.4
L632 6200006990 S.COL ELJRE 56NG-F T 32.8/30.8
L633 6200001980 S.COL NL 252018T-1R0J T 17.7/43.9
L634 6200006990 S.COL ELJRE 56NG-F T 12.4/30.1
L636 6200006990 S.COL ELJRE 56NG-F T 26.7/33.5
L710 6200006990 S.COL ELJRE 56NG-F B 38.8/60.3
L712 6200006990 S.COL ELJRE 56NG-F T 38.4/76.7
L713 6200005620 S.COL ELJRE 4N7Z-F B 36.8/68.7
L714 6200005640 S.COL ELJRE 6N8Z-F B 36.4/74.3
L715 6200006990 S.COL ELJRE 56NG-F B 32.1/77.1
L717 6200006990 S.COL ELJRE 56NG-F T 9.9/69.5
L718 6200006990 S.COL ELJRE 56NG-F T 35.3/58.6
L719 6200006990 S.COL ELJRE 56NG-F T 39/68.7
L720 6200006990 S.COL ELJRE 56NG-F T 36.2/55.9
L770 6200005700 S.COL ELJRE 22NG-F B 31/50.4
L880 6200006990 S.COL ELJRE 56NG-F T 50.6/46.5
L881 6200006990 S.COL ELJRE 56NG-F T 46.2/53.6
L891 6200005710 S.COL ELJRE 27NG-F B 40.9/45
L892 6200005720 S.COL ELJRE 33NG-F T 47.5/58.8
L893 6200005730 S.COL ELJRE 39NG-F T 47.5/61.4
L895 6200006990 S.COL ELJRE 56NG-F B 38.2/36.5
L896 6200006990 S.COL ELJRE 56NG-F B 37.5/38.6
L897 6200006990 S.COL ELJRE 56NG-F B 42.5/41.2
L898 6200001980 S.COL NL 252018T-1R0J B 40.7/37.6
L961 6200006990 S.COL ELJRE 56NG-F B 52.6/64.6
L962 6200005650 S.COL ELJRE 8N2Z-F B 55.5/61.8
L964 6200006990 S.COL ELJRE 56NG-F B 43.6/81
L1020 6200006990 S.COL ELJRE 56NG-F B 69.1/53.7
L1021 6200005660 S.COL ELJRE 10NG-F T 72.8/53.8
L1080 6200006770 S.COL ELJRE 1N5Z-F B 100.6/43.6
L1081 6200008180 S.COL 0.25-1.9-10TL 107N T 112.1/45.6
L1082 6200007740 S.COL LQW2BHN47NJ01L T 107.3/48.1
L1085 6200006990 S.COL ELJRE 56NG-F T 106.5/50.4
L1086 6200006990 S.COL ELJRE 56NG-F T 99.8/46.7
L1087 6200006990 S.COL ELJRE 56NG-F B 80.9/106.5
L1161 6200009700 S.COL C6328A-28NG-A T 105.2/95.9
L1162 6200009410 S.COL C3328A-2N5K-A T 85.1/108.6
L1163 6200009410 S.COL C3328A-2N5K-A T 73.7/107.3
L1164 6200006990 S.COL ELJRE 56NG-F B 97.4/127.1
L1166 6200009700 S.COL C6328A-28NG-A T 93/83.6
L1167 6200008910 S.COL 1812CS-122XKBC T 101.1/84.8
L1169 6200006990 S.COL ELJRE 56NG-F T 113.2/69.8
L1170 6200006990 S.COL ELJRE 56NG-F B 82.7/114
L1250 6200005740 S.COL ELJRE 47NG-F B 60.8/126.1
L1251 6200006990 S.COL ELJRE 56NG-F B 76.2/113
L1330 6200006990 S.COL ELJRE 56NG-F T 21.2/93.5
L1331 6200006990 S.COL ELJRE 56NG-F B 22.9/92.3
L1332 6200006990 S.COL ELJRE 56NG-F B 22.5/91
L1333 6200006990 S.COL ELJRE 56NG-F B 45.2/81
L1334 6200006990 S.COL ELJRE 56NG-F B 53.9/71.6
L1335 6200006990 S.COL ELJRE 56NG-F B 62.2/76.6
L1348 6200006990 S.COL ELJRE 56NG-F B 51.8/67.2
L1349 6200006990 S.COL ELJRE 56NG-F B 58.7/57.8
L1360 6200006990 S.COL ELJRE 56NG-F T 37.4/53.2
L1400 6200006990 S.COL ELJRE 56NG-F T 12.7/48.8
L1401 6200006990 S.COL ELJRE 56NG-F T 59.4/1.4
L1550 6200006990 S.COL ELJRE 56NG-F B 17.7/56.8
L1601 6200006990 S.COL ELJRE 56NG-F T 114.7/13.9
L1602 6200006990 S.COL ELJRE 56NG-F T 106.4/16.7
L1603 6200006990 S.COL ELJRE 56NG-F T 106.2/14.3
L1604 6200006990 S.COL ELJRE 56NG-F T 112.1/11.8
[MAIN UNIT]
REF ORDER
DESCRIPTION M.
H/V
NO. NO.
LOCATION
L1606 6200006990 S.COL ELJRE 56NG-F B 114.8/10.8
L1607 6200006990 S.COL ELJRE 56NG-F T 115.8/11.7
L1608 6200006990 S.COL ELJRE 56NG-F B 95.2/.9
L1609 6200006990 S.COL ELJRE 56NG-F B .9/51
L1610 6200006990 S.COL ELJRE 56NG-F T 105.3/11.8
L1611 6200006990 S.COL ELJRE 56NG-F B 108.3/6.8
L1612 6200003590 S.COL EXCCL3225U1 B 1.8/80.4
L1613 6200003590 S.COL EXCCL3225U1 B 13.7/124.3
L1614 6200003590 S.COL EXCCL3225U1 B 12.9/129.4
L1801 6200006990 S.COL ELJRE 56NG-F B 27.4/103.3
L1802 6200006990 S.COL ELJRE 56NG-F B 26.6/102
L1803 6200006990 S.COL ELJRE 56NG-F B 26.2/100.7
L1804 6200006990 S.COL ELJRE 56NG-F B 26.2/99.4
L1805 6200006990 S.COL ELJRE 56NG-F B 54.5/108.5
R1 7030003320 S.RES ERJ3GEYJ 101 V (100
Ω
) T 55.4/106.3
R2 7030003320 S.RES ERJ3GEYJ 101 V (100
Ω
) T 56.6/98.5
R3 7030003630 S.RES ERJ3GEYJ 393 V (39 k
Ω
) T 53.5/93.2
R4 7030003600 S.RES ERJ3GEYJ 223 V (22 k
Ω
) T 49.4/92.8
R5 7030003320 S.RES ERJ3GEYJ 101 V (100
Ω
) T 55.2/89.3
R6 7030003320 S.RES ERJ3GEYJ 101 V (100
Ω
) T 55.2/88
R7 7030003340 S.RES ERJ3GEYJ 151 V (150
Ω
) B 47.5/85.1
R8 7030003270 S.RES ERJ3GEYJ 390 V (39
Ω
) B 47.7/83.1
R9 7030003340 S.RES ERJ3GEYJ 151 V (150
Ω
) B 49.6/82.3
R70 7030003200 S.RES ERJ3GEYJ 100 V (10
Ω
) T 40.7/76.6
R71 7030003320 S.RES ERJ3GEYJ 101 V (100
Ω
) T 44.4/73.8
R78 7030003710 S.RES ERJ3GEYJ 184 V (180 k
Ω
) T 93.6/27.4
R84 7030003440 S.RES ERJ3GEYJ 102 V (1 k
Ω
) T 91/28.7
R85 7030003680 S.RES ERJ3GEYJ 104 V (100 k
Ω
) T 95.5/27.4
R87 7030003790 S.RES ERJ3GEYJ 824 V (820 k
Ω
) T 98.2/23
R91 7030003430 S.RES ERJ3GEYJ 821 V (820
Ω
) B 105.3/24.9
R92 7030003680 S.RES ERJ3GEYJ 104 V (100 k
Ω
) T 95.5/30
R93 7030003560 S.RES ERJ3GEYJ 103 V (10 k
Ω
) T 93.6/30
R94 7030003620 S.RES ERJ3GEYJ 333 V (33 k
Ω
) T 98.9/33.3
R131 7030003600 S.RES ERJ3GEYJ 223 V (22 k
Ω
) T 44.2/61.3
R132 7030003560 S.RES ERJ3GEYJ 103 V (10 k
Ω
) T 44.8/60
R133 7030003300 S.RES ERJ3GEYJ 680 V (68
Ω
) T 44.3/56.1
R134 7030003320 S.RES ERJ3GEYJ 101 V (100
Ω
) T 50.9/72.9
R135 7030003440 S.RES ERJ3GEYJ 102 V (1 k
Ω
) B 39.1/54.5
R136 7030003440 S.RES ERJ3GEYJ 102 V (1 k
Ω
) T 40.2/49.8
R144 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k
Ω
) T 37.6/26
R188 7030003320 S.RES ERJ3GEYJ 101 V (100
Ω
) T 58.4/43.8
R189 7030003320 S.RES ERJ3GEYJ 101 V (100
Ω
) T 53.5/13.8
R190 7030003320 S.RES ERJ3GEYJ 101 V (100
Ω
) T 54.8/13.6
R191 7030003680 S.RES ERJ3GEYJ 104 V (100 k
Ω
) T 47.9/36.3
R192 7030003460 S.RES ERJ3GEYJ 152 V (1.5 k
Ω
) T 44.8/37.5
R193 7030003400 S.RES ERJ3GEYJ 471 V (470
Ω
) T 52.5/36.1
R194 7030003280 S.RES ERJ3GEYJ 470 V (47
Ω
) T 51.8/33.3
R195 7030003450 S.RES ERJ3GEYJ 122 V (1.2 k
Ω
) T 52.9/27.9
R196 7030003460 S.RES ERJ3GEYJ 152 V (1.5 k
Ω
) T 40.2/32.4
R197 7030003560 S.RES ERJ3GEYJ 103 V (10 k
Ω
) T 51.9/18.7
R198 7030003560 S.RES ERJ3GEYJ 103 V (10 k
Ω
) T 56.7/15.7
R199 7030003320 S.RES ERJ3GEYJ 101 V (100
Ω
) T 38.3/50.1
R200 7030003560 S.RES ERJ3GEYJ 103 V (10 k
Ω
) T 56.7/14.4
R201 7030003570 S.RES ERJ3GEYJ 123 V (12 k
Ω
) B 48/27.2
R202 7030003570 S.RES ERJ3GEYJ 123 V (12 k
Ω
) B 45.8/24.9
R203 7030003720 S.RES ERJ3GEYJ 224 V (220 k
Ω
) T 41/27.9
R204 7030003740 S.RES ERJ3GEYJ 334 V (330 k
Ω
) T 39.9/24.7
R205 7030003500 S.RES ERJ3GEYJ 332 V (3.3 k
Ω
) T 43.6/23.8
R206 7510001530 S.TMR NTCG20 3NH 103JT T 42/23.8
R207 7030003680 S.RES ERJ3GEYJ 104 V (100 k
Ω
) T 39.9/22.8
R208 7030003600 S.RES ERJ3GEYJ 223 V (22 k
Ω
) T 43.2/26
R209 7030003440 S.RES ERJ3GEYJ 102 V (1 k
Ω
) T 48.5/25.1
R210 7030003440 S.RES ERJ3GEYJ 102 V (1 k
Ω
) T 51.1/26
R211 7030003680 S.RES ERJ3GEYJ 104 V (100 k
Ω
) T 50.3/24.1
R212 7030003550 S.RES ERJ3GEYJ 822 V (8.2 k
Ω
) T 54.5/34.7
R213 7030003620 S.RES ERJ3GEYJ 333 V (33 k
Ω
) T 55.6/36.1
R214 7030003640 S.RES ERJ3GEYJ 473 V (47 k
Ω
) T 54.8/32.8
R215 7030003600 S.RES ERJ3GEYJ 223 V (22 k
Ω
) T 57.5/35.6
R216 7030003460 S.RES ERJ3GEYJ 152 V (1.5 k
Ω
) T 58.9/32.8
R217 7030003320 S.RES ERJ3GEYJ 101 V (100
Ω
) T 54.3/37.7
R218 7030003640 S.RES ERJ3GEYJ 473 V (47 k
Ω
) T 62.7/29.9
R219 7030003560 S.RES ERJ3GEYJ 103 V (10 k
Ω
) T 57.4/24
R270 7030003490 S.RES ERJ3GEYJ 272 V (2.7 k
Ω
) B 82.6/30.5
R271 7030003680 S.RES ERJ3GEYJ 104 V (100 k
Ω
) T 78.7/25.6
R272 7030003510 S.RES ERJ3GEYJ 392 V (3.9 k
Ω
) B 84.7/31.3
R273 7030003590 S.RES ERJ3GEYJ 183 V (18 k
Ω
) B 77.9/33
R274 7030003590 S.RES ERJ3GEYJ 183 V (18 k
Ω
) B 80/32.2
R276 7030003450 S.RES ERJ3GEYJ 122 V (1.2 k
Ω
) T 71/35.7
R277 7030003280 S.RES ERJ3GEYJ 470 V (47
Ω
) T 74.2/38.3
R278 7030003380 S.RES ERJ3GEYJ 331 V (330
Ω
) T 79.4/40.6
R279 7030003640 S.RES ERJ3GEYJ 473 V (47 k
Ω
) T 63.2/41.1
R280 7030003640 S.RES ERJ3GEYJ 473 V (47 k
Ω
) T 57.6/41.9
R281 7030003380 S.RES ERJ3GEYJ 331 V (330
Ω
) T 68.1/40.6
R282 7030003570 S.RES ERJ3GEYJ 123 V (12 k
Ω
) B 43.7/53.9
R283 7030003640 S.RES ERJ3GEYJ 473 V (47 k
Ω
) T 66.5/43.5
R284 7030003320 S.RES ERJ3GEYJ 101 V (100
Ω
) T 69.4/40.6
R285 7030003380 S.RES ERJ3GEYJ 331 V (330
Ω
) B 80.3/46.2
R287 7030003320 S.RES ERJ3GEYJ 101 V (100
Ω
) B 73.9/41.7
R288 7030003360 S.RES ERJ3GEYJ 221 V (220
Ω
) B 75.8/41.3
R289 7030003580 S.RES ERJ3GEYJ 153 V (15 k
Ω
) B 77.1/42.1
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
S.=Surface mount
6 - 2
