Icom ID-1

[MAIN UNIT]
REF ORDER
DESCRIPTION M.
H/V
NO. NO.
LOCATION
R1412 7030003640 S.RES ERJ3GEYJ 473 V (47 k
Ω
) T 43.1/18
R1413 7030003320 S.RES ERJ3GEYJ 101 V (100
Ω
) T 40.5/18
R1414 7030003800 S.RES ERJ3GEYJ 105 V (1 M
Ω
) T 46.7/19.6
R1415 7030003800 S.RES ERJ3GEYJ 105 V (1 M
Ω
) T 45.4/19.6
R1460 7030003670 S.RES ERJ3GEYJ 823 V (82 k
Ω
) T 40.5/9.3
R1461 7030003670 S.RES ERJ3GEYJ 823 V (82 k
Ω
) T 42.4/8.6
R1462 7030003670 S.RES ERJ3GEYJ 823 V (82 k
Ω
) T 45.4/8.7
R1463 7030003690 S.RES ERJ3GEYJ 124 V (120 k
Ω
) T 49.4/4.5
R1464 7030003680 S.RES ERJ3GEYJ 104 V (100 k
Ω
) T 50.2/6.4
R1465 7030003740 S.RES ERJ3GEYJ 334 V (330 k
Ω
) T 54.2/5.2
R1466 7030003700 S.RES ERJ3GEYJ 154 V (150 k
Ω
) T 54.1/3.3
R1467 7030003320 S.RES ERJ3GEYJ 101 V (100
Ω
) T 52.8/7
R1468 7030003760 S.RES ERJ3GEYJ 474 V (470 k
Ω
) T 51.5/6.4
R1469 7030003320 S.RES ERJ3GEYJ 101 V (100
Ω
) B 39.4/13.5
R1470 7030003560 S.RES ERJ3GEYJ 103 V (10 k
Ω
) B 37.8/13.5
R1471 7030003560 S.RES ERJ3GEYJ 103 V (10 k
Ω
) B 39.2/6.9
R1472 7030003800 S.RES ERJ3GEYJ 105 V (1 M
Ω
) B 40/9.3
R1473 7030003800 S.RES ERJ3GEYJ 105 V (1 M
Ω
) B 40/10.9
R1474 7030003570 S.RES ERJ3GEYJ 123 V (12 k
Ω
) B 42.4/8.5
R1475 7030003570 S.RES ERJ3GEYJ 123 V (12 k
Ω
) B 42.4/5.7
R1476 7030003570 S.RES ERJ3GEYJ 123 V (12 k
Ω
) B 44/7.2
R1477 7030003570 S.RES ERJ3GEYJ 123 V (12 k
Ω
) B 44/10.1
R1478 7030003670 S.RES ERJ3GEYJ 823 V (82 k
Ω
) B 45/17.3
R1479 7030003640 S.RES ERJ3GEYJ 473 V (47 k
Ω
) B 49.8/14.1
R1480 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k
Ω
) B 55/12.7
R1481 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k
Ω
) T 50.6/16.9
R1482 7030003790 S.RES ERJ3GEYJ 824 V (820 k
Ω
) B 52.2/13.3
R1483 7030003690 S.RES ERJ3GEYJ 124 V (120 k
Ω
) T 35.4/12.4
R1484 7030003640 S.RES ERJ3GEYJ 473 V (47 k
Ω
) T 36.7/13.2
R1485 7030003640 S.RES ERJ3GEYJ 473 V (47 k
Ω
) T 39.8/11.2
R1486 7030003640 S.RES ERJ3GEYJ 473 V (47 k
Ω
) T 42.4/11.2
R1487 7030003650 S.RES ERJ3GEYJ 563 V (56 k
Ω
) T 48.6/11.4
R1488 7030003600 S.RES ERJ3GEYJ 223 V (22 k
Ω
) T 47.3/17.2
R1489 7030003750 S.RES ERJ3GEYJ 394 V (390 k
Ω
) T 47.3/14.6
R1490 7030003320 S.RES ERJ3GEYJ 101 V (100
Ω
) B 60.5/10.7
R1491 7030003800 S.RES ERJ3GEYJ 105 V (1 M
Ω
) T 7.5/71.7
R1492 7030003480 S.RES ERJ3GEYJ 222 V (2.2 k
Ω
) T 7.5/73
R1493 7030003800 S.RES ERJ3GEYJ 105 V (1 M
Ω
) T 7.8/75.3
R1494 7030003560 S.RES ERJ3GEYJ 103 V (10 k
Ω
) T 7.1/79.6
R1495 7030003680 S.RES ERJ3GEYJ 104 V (100 k
Ω
) B 62.1/10.7
R1496 7030003660 S.RES ERJ3GEYJ 683 V (68 k
Ω
) T 39.2/6.7
R1550 7030003640 S.RES ERJ3GEYJ 473 V (47 k
Ω
) B 16.5/54.2
R1551 7030003680 S.RES ERJ3GEYJ 104 V (100 k
Ω
) B 6/55
R1552 7030003600 S.RES ERJ3GEYJ 223 V (22 k
Ω
) T 5.3/62.9
R1553 7030003320 S.RES ERJ3GEYJ 101 V (100
Ω
) B 17.3/59.1
R1555 7030003680 S.RES ERJ3GEYJ 104 V (100 k
Ω
) B 13.4/67.2
R1556 7030003510 S.RES ERJ3GEYJ 392 V (3.9 k
Ω
) B 11/66.1
R1557 7030003440 S.RES ERJ3GEYJ 102 V (1 k
Ω
) B 11/67.4
R1558 7030003440 S.RES ERJ3GEYJ 102 V (1 k
Ω
) B 8.5/66.9
R1559 7030003560 S.RES ERJ3GEYJ 103 V (10 k
Ω
) B 7.4/73.7
R1560 7030003590 S.RES ERJ3GEYJ 183 V (18 k
Ω
) B 8.2/77.4
R1561 7030003400 S.RES ERJ3GEYJ 471 V (470
Ω
) T 16.7/115
R1562 7030007180 S.RES ERJ12YJ150U (15
Ω
) B 42.9/113.9
R1601 7030004050 S.RES ERJ3GEYJ 1R0 V (1
Ω
) B 113.5/18.1
R1602 7030004030 S.RES ERJ3GEYJ 5R6 V (5.6
Ω
) B 106.8/21.5
R1603 7030003390 S.RES ERJ3GEYJ 391 V (390
Ω
) B 106.8/22.8
R1605 7030003320 S.RES ERJ3GEYJ 101 V (100
Ω
) B 101.2/21.6
R1606 7030003560 S.RES ERJ3GEYJ 103 V (10 k
Ω
) B 102/17.7
R1607 7030003570 S.RES ERJ3GEYJ 123 V (12 k
Ω
) B 102/19.3
R1608 7030003600 S.RES ERJ3GEYJ 223 V (22 k
Ω
) T 109.5/17.6
R1609 7030003560 S.RES ERJ3GEYJ 103 V (10 k
Ω
) T 110.6/20.3
R1610 7030003480 S.RES ERJ3GEYJ 222 V (2.2 k
Ω
) T 108.2/17.6
R1669 7030003680 S.RES ERJ3GEYJ 104 V (100 k
Ω
) T 97.9/12.8
R1670 7030003500 S.RES ERJ3GEYJ 332 V (3.3 k
Ω
) T 100.6/16.1
R1671 7030005331 S.RES ERA3YED 562V T 100.6/14.8
R1672 7030003560 S.RES ERJ3GEYJ 103 V (10 k
Ω
) T 95.6/14.9
R1674 7030003560 S.RES ERJ3GEYJ 103 V (10 k
Ω
) T 5.3/84.8
R1678 7030003680 S.RES ERJ3GEYJ 104 V (100 k
Ω
) T 100.6/13.5
R1679 7030003580 S.RES ERJ3GEYJ 153 V (15 k
Ω
) T 97/18.9
R1680 7030003680 S.RES ERJ3GEYJ 104 V (100 k
Ω
) T 92.8/14.5
R1681 7030003320 S.RES ERJ3GEYJ 101 V (100
Ω
) T 88.9/14.4
R1682 7030003420 S.RES ERJ3GEYJ 681 V (680
Ω
) T 90.8/15.2
R1683 7030003280 S.RES ERJ3GEYJ 470 V (47
Ω
) T 94.4/18.9
R1684 7030003800 S.RES ERJ3GEYJ 105 V (1 M
Ω
) T 81.6/15
R1685 7030003800 S.RES ERJ3GEYJ 105 V (1 M
Ω
) T 87/15.2
R1686 7030003510 S.RES ERJ3GEYJ 392 V (3.9 k
Ω
) B 84.4/13
R1687 7030003750 S.RES ERJ3GEYJ 394 V (390 k
Ω
) B 86.4/17
R1688 7030003740 S.RES ERJ3GEYJ 334 V (330 k
Ω
) B 82/12.2
R1689 7030003680 S.RES ERJ3GEYJ 104 V (100 k
Ω
) B 79.2/12.2
R1690 7030003320 S.RES ERJ3GEYJ 101 V (100
Ω
) B 79.4/10.6
R1691 7030003550 S.RES ERJ3GEYJ 822 V (8.2 k
Ω
) B 86.4/13
R1693 7030003650 S.RES ERJ3GEYJ 563 V (56 k
Ω
) B 86.8/18.8
R1695 7030003790 S.RES ERJ3GEYJ 824 V (820 k
Ω
) B 80.4/13.8
R1696 7030003640 S.RES ERJ3GEYJ 473 V (47 k
Ω
) B 84/18.6
R1697 7030003670 S.RES ERJ3GEYJ 823 V (82 k
Ω
) B 84.3/24.2
R1698 7030003720 S.RES ERJ3GEYJ 224 V (220 k
Ω
) B 84.3/21.5
R1699 7030003670 S.RES ERJ3GEYJ 823 V (82 k
Ω
) B 83.4/27.3
R1700 7030003670 S.RES ERJ3GEYJ 823 V (82 k
Ω
) B 81/26
R1704 7310005050 S.TRI RH03ADCS3X 4.7k T 69.4/10.8
R1705 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k
Ω
) B 76.4/24.8
R1706 7030003450 S.RES ERJ3GEYJ 122 V (1.2 k
Ω
) B 73.6/24.8
R1707 7310002800 S.TRI RH03ADCJ5X 220 k T 69.4/6.8
[MAIN UNIT]
REF ORDER
DESCRIPTION M.
H/V
NO. NO.
LOCATION
R1708 7030003480 S.RES ERJ3GEYJ 222 V (2.2 k
Ω
) T 79/13.1
R1709 7030005331 S.RES ERA3YED 562V T 79/14.4
R1710 7030003800 S.RES ERJ3GEYJ 105 V (1 M
Ω
) T 79/15.7
R1711 7030003320 S.RES ERJ3GEYJ 101 V (100
Ω
) T 72.9/15.2
R1712 7030003320 S.RES ERJ3GEYJ 101 V (100
Ω
) B 73.6/19.9
R1713 7030003750 S.RES ERJ3GEYJ 394 V (390 k
Ω
) B 73.6/18.3
R1714 7030003800 S.RES ERJ3GEYJ 105 V (1 M
Ω
) B 76.4/18.3
R1715 7030003560 S.RES ERJ3GEYJ 103 V (10 k
Ω
) T 6.1/82.8
R1716 7030003680 S.RES ERJ3GEYJ 104 V (100 k
Ω
) B 5.6/87.9
R1717 7030003680 S.RES ERJ3GEYJ 104 V (100 k
Ω
) B 6.3/85.7
R1718 7030003740 S.RES ERJ3GEYJ 334 V (330 k
Ω
)
[EUR2], [EUR3]
only B 6.3/83.5
R1750 7030003680 S.RES ERJ3GEYJ 104 V (100 k
Ω
) T 25.3/115.6
R1751 7030003440 S.RES ERJ3GEYJ 102 V (1 k
Ω
) T 29.4/121.3
R1800 7030003640 S.RES ERJ3GEYJ 473 V (47 k
Ω
) T 9.5/20.2
R1801 7030003600 S.RES ERJ3GEYJ 223 V (22 k
Ω
) B 4.2/25.9
R1802 7030003600 S.RES ERJ3GEYJ 223 V (22 k
Ω
) T 13.7/24.8
R1803 7030003320 S.RES ERJ3GEYJ 101 V (100
Ω
) T 61.9/6.9
C2 4030009530 S.CER C1608 CH 1H 030B-T T 67.6/107.5
C3 4030009540 S.CER C1608 CH 1H 1R5B-T T 65/107.5
C4 4030009540 S.CER C1608 CH 1H 1R5B-T T 62.4/107.2
C5 4030009510 S.CER C1608 CH 1H 010B-T T 59.7/107.2
C6 4030007090 S.CER C1608 CH 1H 470J-T T 54.1/106.3
C7 4030006860 S.CER C1608 JB 1H 102K-T T 54.3/108.2
C8 4030007010 S.CER C1608 CH 1H 100D-T T 57.5/108
C9 4030007090 S.CER C1608 CH 1H 470J-T T 58.8/103.2
C10 4030006860 S.CER C1608 JB 1H 102K-T T 58.8/101.9
C11 4030007010 S.CER C1608 CH 1H 100D-T T 58.8/100.6
C12 4030009910 S.CER C1608 CH 1H 040B-T T 54.8/104.4
C13 4030007090 S.CER C1608 CH 1H 470J-T T 58.8/99.3
C14 4030007010 S.CER C1608 CH 1H 100D-T T 58.8/98
C15 4030006860 S.CER C1608 JB 1H 102K-T T 58.8/96.7
C16 4030006860 S.CER C1608 JB 1H 102K-T T 51.3/96.2
C17 4030011770 S.CER C1608 CH 1H 060B-T T 51.3/93.6
C18 4030006860 S.CER C1608 JB 1H 102K-T T 55.2/91.9
C19 4030006850 S.CER C1608 JB 1H 471K-T T 57/89.8
C21 4030007010 S.CER C1608 CH 1H 100D-T T 55.2/86.7
C22 4030009550 S.CER C1608 CH 1H 2R5B-T T 53.2/87.4
C23 4030006860 S.CER C1608 JB 1H 102K-T T 48.4/79.5
C70 4030006860 S.CER C1608 JB 1H 102K-T T 39.9/73.6
C72 4030007050 S.CER C1608 CH 1H 220J-T T 42.5/73.6
C74 4030007090 S.CER C1608 CH 1H 470J-T T 43/79.4
C75 4030009500 S.CER C1608 CH 1H 0R5B-T T 45.5/79.5
C76 4030006860 S.CER C1608 JB 1H 102K-T T 50.3/78
C77 4030007090 S.CER C1608 CH 1H 470J-T T 50.3/76.7
C78 4030006860 S.CER C1608 JB 1H 102K-T T 50.2/75.2
C79 4030009910 S.CER C1608 CH 1H 040B-T T 49.6/72.9
C80 4030009510 S.CER C1608 CH 1H 010B-T T 47.5/73.6
C81 4030009550 S.CER C1608 CH 1H 2R5B-T T 41/68.8
C82 4030009910 S.CER C1608 CH 1H 040B-T T 42.3/66.1
C131 4030006860 S.CER C1608 JB 1H 102K-T T 38.9/57.5
C132 4030010760 S.CER C1608 CH 1H 331J-T T 44.3/54.8
C133 4030006860 S.CER C1608 JB 1H 102K-T T 44.9/58.7
C134 4030011600 S.CER C1608 JB 1E 104K-T T 44.7/57.4
C136 4030006860 S.CER C1608 JB 1H 102K-T T 44.3/53.5
C137 4030006900 S.CER C1608 JB 1H 103K-T T 44.3/52.2
C138 4030011600 S.CER C1608 JB 1E 104K-T T 44.3/50.9
C140 4030006860 S.CER C1608 JB 1H 102K-T T 38.5/55.5
C141 4030007050 S.CER C1608 CH 1H 220J-T T 41.6/48.5
C191 4030011770 S.CER C1608 CH 1H 060B-T T 46.9/48.9
C192 4030009540 S.CER C1608 CH 1H 1R5B-T T 50.3/43.1
C195 4030011600 S.CER C1608 JB 1E 104K-T T 47.4/34.4
C196 4030006900 S.CER C1608 JB 1H 103K-T T 39.7/47.9
C197 4030006860 S.CER C1608 JB 1H 102K-T T 48.7/34.4
C198 4030007120 S.CER C1608 CH 1H 820J-T T 51.6/29.2
C199 4030006860 S.CER C1608 JB 1H 102K-T T 47.3/26.4
C200 4550006250 S.TAN TEESVA 1A 106M8L T 41.4/34.1
C201 4030006850 S.CER C1608 JB 1H 471K-T T 52.9/31.8
C202 4030011600 S.CER C1608 JB 1E 104K-T T 40.2/31.1
C203 4030011600 S.CER C1608 JB 1E 104K-T T 40.2/29.8
C204 4030007160 S.CER C1608 CH 1H 181J-T T 39.4/27.9
C205 4030007160 S.CER C1608 CH 1H 181J-T T 40.2/26
C206 4030011600 S.CER C1608 JB 1E 104K-T B 45/27.3
C207 4030011600 S.CER C1608 JB 1E 104K-T T 63.2/39.8
C208 4030011600 S.CER C1608 JB 1E 104K-T B 48.2/29.1
C209 4030006860 S.CER C1608 JB 1H 102K-T T 45.9/25.1
C210 4030006860 S.CER C1608 JB 1H 102K-T T 51.9/24.1
C211 4030011810 S.CER C1608 JB 1A 224K-T T 57.7/38.8
C212 4030006880 S.CER C1608 JB 1H 472K-T T 60.8/33.6
C213 4030011810 S.CER C1608 JB 1A 224K-T T 62.7/31.2
C214 4030011600 S.CER C1608 JB 1E 104K-T T 54.8/24
C215 4030011600 S.CER C1608 JB 1E 104K-T T 51.9/21.3
C216 4030011600 S.CER C1608 JB 1E 104K-T T 60.7/15.7
C217 4030011600 S.CER C1608 JB 1E 104K-T T 61.2/24.2
C218 4030011600 S.CER C1608 JB 1E 104K-T T 60.7/14.4
C219 4030011600 S.CER C1608 JB 1E 104K-T T 53.3/15.7
C220 4030011810 S.CER C1608 JB 1A 224K-T T 52.3/39.4
C271 4030011600 S.CER C1608 JB 1E 104K-T T 82/41.9
C272 4550006250 S.TAN TEESVA 1A 106M8L T 82.8/43.6
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
S.=Surface mount
6 - 4
