5 - 13
5-3 TRANSMIT ADJUSTMENT (Continued)
5-4 RECEIVE ADJUSTMENTS (Continued)
1) Select an adjustment item (band) using
/
.
2) Set the SSG as specifi ed (frequency, deviation and output level), and then push to automatically adjust.
ADJUSTMENT
ADJUSTMENT
ITEM
OPERATION VALUE
SQUELCH
1 1) Set the power supply voltage to 7.4 V.
2) Connect an SSG to the antenna connector and set as;
Modulation : 1 kHz
[BC BAND]
-1.010 MHz-
[ASQ]
2 • Set the SSG as;
Frequency : (Displayed on the function display)
Level : –3 dBµ
(–110 dBm)
Deviation : 30% (AM)
Push .
(Automatic
adjustment)
-87.5 MHz-
[WSQ]
3 • Set the SSG as;
Frequency : (Displayed on the function display)
Level : –3 dBµ
(–110 dBm)
Deviation : 52.5 kHz
[A BAND]
-VHF-
FM mode
[VSQ]
1 • Set the SSG as;
Frequency : (Displayed on the function display)
Level : OFF
FM-N mode
2
-UHF-
FM mode
[USQ]
3
FM-N mode
4
[AIR BAND]
[ASQ]
1 1) Set the power supply voltage to 7.4 V.
2) Connect an SSG to the antenna connector and set as;
Frequency : (Displayed on the function display)
Level : –26 dBµ
(–133 dBm)
Modulation : 1 kHz
Deviation : 30% (AM)
[B BAND]
-VHF-
[VSQ]
2 • Set the SSG as;
Frequency : (Displayed on the function display)
Level : –25 dBµ
(–132 dBm)
Deviation : 3.5 kHz
-UHF-
[USQ]
3
; This output level of a standard signal generator (SSG) is indicated as SSG’s open circuit.
