Icom IF-3002 User Manual

5
2
PANEL DESCRIPTION
■ Front, top and side panels
Microphone
Speaker
r
w
e
q
y
u
i
t
LOWER KEY
UPPER KEY
PTT SWITCH
ANTENNA
CONNECTOR
ROTARY
SELECTOR
LED INDICATO
R
VOLUME
CONTROL
SPEAKER-
MICROPHONE
JACK
q ROTARY SELECTOR
Rotate to select the pre-programmed memory channels.
w VOLUME CONTROL [VOL]
Rotate to turn the power ON/OFF, and adjust the audio level.

Icom IF-3002 Specifications

General

Brand	Icom
Model	IF-3002
Category	Transceiver
Language	English
