DGX-IP1000C/IP100H -V1.0
10
STEP2: CONNECTION EXAMPLE
See each equipment’s instruction manual for connection details.
STEP3: ACCESS POINT SETTINGS
Ask your system administrator for the access point’s IP address, and then enter it into the access point field,
and then set the SSID to WAVEMASTER-0.
[RECOMMENDATION]
We recommend that you set the access point’s authentication as follows:
For example:
• Authentication: WPA-PSK·WPA2-PSK
• Encryption Type: TKIP·AES
• PSK: 5cf97dgh6
IMPORTANT! If you turn ON the Hide SSID function on IEEE802.11a, IP100H may not connect to the
access point.
STEP 1 STEP 2 STEP 3 STEP 4 STEP 5 STEP 6
STEP 1 STEP 2
STEP 3
STEP 4 STEP 5 STEP 6
Access point
Ask your system
administrator for the IP
address and subnet
mask.
IP1000C
Ask your system administrator for
the IP address and subnet mask.
PC
DHCP Client: Enable
[LAN]
To Next Page
