DGX-IP1000C/IP100H -V1.0
27
Set an access point, PC, IP1000C, IP100H, and IP100FS using the following steps.
STEP 1: CONNECTION EXAMPLE
See each equipment’s instruction manual for connecting and setting details.
2-5 HOW TO SET AND USE THE IP100FS
IMPORTANT! We recommend that you connect the access point, IP1000C and PC in a standalone
configuration. If you connect them to your local network with the following connection settings, your local
network may not operate correctly. (IP addresses may overlap.)
STEP 1: CONNECTION EXAMPLE
STEP 2: ACCESS POINT SETTINGS
STEP 6: DEMONSTRATION
STEP 3: IP1000C SETTINGS
STEP 4: IP100H SETTINGS
STEP 5: IP100FS SETTINGS
Access point
IP address: 192.168.0.50
Subnet mask: 255.255.255.0
IP1000C
IP address: 192.168.0.1
Subnet mask: 255.255.255.0
DHCP Server: Enable
PC
IP address: 192.168.0.70
Subnet mask: 255.255.255.0
[LAN]
[LAN 1]
