Icom IP100H - Page 53

DGX-IP1000C/IP100H -V1.0
50
When calling from the IP100FS to a specified IP100H (Individual Call)
(1) Click the IP100H (TR 1) icon, and then the selection detail is displayed on the IP100FS screen.
(2) Click and hold IP100FS’s [PTT], and then speak into the microphone at a normal voice level.
The IP100FS displays the following screen, and your voice is heard from TR 1’s speaker.
After speaking, release IP100FS’s [PTT] to listen.
IP100FS
TR 1
Access point
IP1000C
Click
The background lights red while making a
call.
The action, type of call and ID are
displayed.
Click and hold IP100FS’s
[PTT] to speak to the target
user.
Selection detail is
displayed
