11
9
61
7
7
5
5
8
8
23
33
66
9. Attach the Console Crossbar (61) to the Right
and Left Uprights (33, 66) with four #10 x 3/4"
Screws (8) and four #10 Star Washers (23);
start all four Screws, and then tighten them.
Firmly tighten the two 5/16" x 3/4" Screws (5)
and the two 5/16" x 3" Screws (7).
8. Remove and discard the four indicated screws
(D).
8
D
D
23
To Next Page
