Audio Specifications
Digital Performance
24-bit resolution
A-D Dynamic Range:102dB (fs=49kHz, 20Hz - 20kHz A-25, 24 bit)
D-A Dynamic Range:104dB (fs=44.1kHz, 20Hz - 20kHz, A-wt, 24 bit)
Supported sample rates: 44.1 kHz, 48 kHz, 88.2kHz, 96 kHz
Microphone Inputs
Gain: 0- 60 dB (1 dB steps)
Frequency Response (flatness): 20 Hz - 20kHz (+/- 0.02 dB)
SNR: +104 dB (1kHz, 1 Vrms, 22Hz-22kHz, A-wt, lowest gain)
THD+N: -90 dB (1kHz, 1 Vrms, 22Hz-22kHz, A-wt, lowest gain)
Line/Instrument Inputs (Balanced Input)
Attenuator: 20 dB (fixed)
Impedance: 800kOhms (Hi-Z), 45 kOhms (Lo-Z)
Frequency Response: 20 Hz - 20kHz
SNR: +104 dB (1kHz, 2 Vrms, 22Hz-22kHz, A-wt)
THD+N: --88 dB (1kHz, 2 Vrms, 22Hz-22kHz, A-wt)
Maximum input level: 8 Vrms, 20 dBu, 18 dBV (1kHz, 22Hz-22kHz, A-wt, 1% THD+N,
SNR=+116 dB)
Line/Instrument Inputs (Single-Ended Input)
Attenuator: 20dB (fixed)
Impedance: 800kOhms (Hi-Z), 45kOhms (Lo-Z)
SNR: +104 dB (1kHz, 2 Vrms, 22Hz-22kHz, A-wt)
THD+N: --88 dB (1kHz, 2 Vrms, 22Hz-22kHz, A-wt)
Maximum input level: 8 Vrms, 20 dBu, 18 dBV (1kHz,22Hz-22kHz, A-wt, 1% THD+N,
SNR= +116dB dB)
Line Outputs
Maximum Output Level: 3.1 Vrms, 12 dBU, 9.8 dBV
Frequency response (flatness): 20 Hz - 20 kHz (+/1 0.1 dB)
SNR: +98 dB (1kHz, 22Hz-22kHz, A-wt)
THD+N: -98 dB (1kHz, 22Hz-22kHz, A-wt)
Headphone
Frequency response (flatness): 20 Hz - 20 kH (+/1 0.1 dB)
SNR: +100 dB (1kHz, 22Hz-22kHz, A-wt)
THD+N: -99 dB (1kHz, 22Hz-22kHz, A-wt)
Power output into 30 Ohms per channel: 34 mW per channel
Features of iConnectAUDIO2
+
are patent pending. For more details see www.iConnectivity.com/patents.
Product features are subject to change.
iPad is a trademark of Apple Inc., registered in the U.S. and other countries.
iConnectivity, iConnectMIDI, iConnectAUDIO, and passThru are trademarks of iKingdom Corp. Copyright (c)
iKingdom Corp. 2016
