ICP C8MPN - Page 39

39
441 01 2611 06
THIS DATA IS SUBJECT TO CHANGE WITHOUT NOTICE
Manufacturers Number (Mfr No --SeeRatingPlate)
ALL Models (N8MPL)
Specifications
N8MPL
050B12
N8MPL
075B12
N8MPL
075F16
N8MPL
100F20
N8MPL
100J22
N8MPL
125J20
N8MPL
125J22
General
Input(Btuh)
Output(Btuh)
Temp. Rise (
°
F)
50,000
40,000
35--65
75,000
60,000
35--65
75,000
60,000
25--55
100,000
80,000
35--65
100,000
80,000
30--60
125,000
100,000
30--60
125,000
100,000
30--60
Electrical(Volts/Hz) 115/60 115/60 115/60 115/60 115/60 115/60 115/60
RatingPlate Amps/ 8.8 9.5 10.1 13.6 12.3 13.6 11.5
GasType Nat LP Nat LP Nat LP Nat LP Nat LP Nat LP Nat LP
Transformer Size (VA)
T’statHeat Anticipator
40
.10
40
.10
40
.10
40
.10
40
.10
40
.10
40
.10
40
.10
40
.10
40
.10
40
.10
40
.10
40
.10
40
.10
Gas & Ignition
Std. Main Orifices (No/Size)
2/#42 2/#54 3/#42 3/#54 3/#42 3/#54 4/#42 4/#54 4/#42 4/#54 5/#42 5/#54 5/#42 5/#54
GasValve Honeywell SV
Regulation Type
ManifoldPress.(Inch’sWC)
9541
SNAP
3.5
9541
SNAP
10.0
9541
SNAP
3.5
9541
SNAP
10.0
9541
SNAP
3.5
9541
SNAP
10.0
9541
SNAP
3.5
9541
SNAP
10.0
9541
SNAP
3.5
9541
SNAP
10.0
9541
SNAP
3.5
9541
SNAP
10.0
9541
SNAP
3.5
9541
SNAP
10.0
Pilot Orifice Size .018 .011 .018 .011 .018 .011 .018 .011 .018 .011 .018 .011 .018 .011
Ignition Type/Series
Lock--Out Time
HW HSP
NA
HW HSP
NA
HW HSP
NA
HW HSP
NA
HW HSP
NA
HW HSP
NA
HW HSP
NA
Combustion
Flue OutletSize(Inches)
4
4 4
4 4
4 4
Limits& Controls
ThermalSensor (
°
F)
LimitControl
300
See PartsList
300
See PartsList
300
See PartsList
300
See PartsList
300
See PartsList
300
See PartsList
300
See PartsList
Std.PressureSw.(PartNo)
Press(Close)
Press(Open)
1013529
--0.69
--0.59
1013529
--0.69
--0.59
1013529
--0.69
--0.59
1013529
--0.69
--0.59
1013529
--0.69
--0.59
1013529
--0.69
--0.59
1013529
--0.69
--0.59
Fan Control(Type)
Fan Control On
(Timed--secs) Off
HW ST9160
30
60,100,140,180
HW ST9160
30
60,100,140,180
HW ST9160
30
60,100,140,180
HW ST9160
30
60,100,140,180
HW ST9160
30
60,100,140,180
HW ST9160
30
60,100,140,180
HW ST9160
30
60,100,140,180
Blower Data
Type & Size
MotorType/H.p.
Cap. Mfd/Volts
FilterType(600FPM)
Filter Size (²) (Not Supplied)
1600 CFM and over#
Min.Cool Cap. (Tons)
Max.Cool Cap. (Tons)
11--8
PSC/
1
/
2
10/370
Washable
14x25x1
-- --
1.5
3
11--8
PSC/
1
/
2
7.5/370
Washable
14x25x1
-- --
1.5
3
11--10
PSC/
1
/
2
10/370
Washable
16x25x1
16x25x1(2)
3
4
11--10
PSC/
1
/
2
10/370
Washable
16x25x1
16x25x1(2)
3
5
11--10
PSC/
3
/
4
40/370
Washable
20x25x1
16x25x1(2)
3
5.5
11--10
PSC/
1
/
2
10/370
Washable
20x25x1
16x25x1(2)
3
5
11--10
PSC/
3
/
4
40/370
Washable
20x25x1
16x25x1(2)
3
5.5
Gas Conversion Kits
Nat toLP NAHL002LP or *1160991
LP to Nat NAHF002NG, *1009510
* Mustbe orderedfrom Service Parts
Note: Two side filter racks (left and right) required for upflow applications. Side returns are not permitted with downflow or horizontal furnace applica-
tions.
