ICP PGD4 E Series - Page 34

34 46201200402
Specifications are subject to change without notice.
Table 10 -- Dry Coil Air Delivery* -- Horizontal and Downflow Discharge -- Sizes 24-- 60 208/230VAC -- 1 Phase (Cont.)
Unit
Size
Heating Rise
Range
o
F(
o
C)
Motor
Speed
Wire
Color
External Static Pressure (IN. W.C.)
0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1
48130
35 --- 65
( 19 --- 3 6)
Low
3
Blue
CFM 1378 1344 1295 1260 1216 1179 1135 1087 1035 995 BHP 0.26 0.27 0.29 0.31 0.31 0.33 0.34 0.36 0.36 0.38 Heat Rise (
o
F) NA NA NA NA NA NA NA NA NA NA
Heat Rise (
o
C) NA NA NA NA NA NA NA NA NA NA
M e d --- L o w
2
Pink
CFM 1696 1671 1631 1607 1574 1539 1507 1463 1432 1393 BHP 0.45 0.47 0.49 0.50 0.52 0.52 0.54 0.55 0.57 0.58 Heat Rise (
o
F) 57 57 59 60 61 62 64 NA NA NA
Heat Rise (
o
C) 31 32 33 33 34 35 35 NA NA NA
Medium Red
CFM 1994 1968 1943 1910 1882 1835 1774 1702 1614 1512 BHP 0.72 0.73 0.75 0.76 0.78 0.78 0.76 0.73 0.70 0.66 Heat Rise (
o
F) 48 49 49 50 51 52 54 56 59 63
Heat Rise (
o
C) 27 27 27 28 28 29 30 31 33 35
Med---High
1
Orange
CFM 2054 2013 1986 1964 1919 1854 1779 1695 1605 1498 BHP 0.77 0.79 0.80 0.82 0.81 0.80 0.76 0.74 0.69 0.65 Heat Rise (
o
F) 47 48 48 49 50 52 54 57 60 64
Heat Rise (
o
C) 26 26 27 27 28 29 30 31 33 36
High Black
CFM 2267 2201 2133 2071 1997 1923 1835 1739 1654 1551 BHP 1.03 1.00 0.97 0.93 0.89 0.86 0.82 0.78 0.74 0.69 Heat Rise (
o
F) 42 44 45 46 48 50 52 55 58 62
Heat Rise (
o
C) 24 24 25 26 27 28 29 31 32 34
60090
35 --- 65
( 19 --- 3 6)
Low
3
Blue
CFM 1330 1277 1232 1191 1147 1103 1060 1004 963 919 BHP 0.26 0.27 0.29 0.30 0.31 0.32 0.33 0.34 0.36 0.37 Heat Rise (
o
F) 51 53 55 57 59 61 64 NA NA NA
Heat Rise (
o
C) 28 29 31 32 33 34 35 NA NA NA
M e d --- L o w
1
Pink
CFM 1475 1436 1399 1351 1317 1270 1236 1188 1152 1105 BHP 0.35 0.36 0.37 0.38 0.40 0.41 0.42 0.43 0.45 0.45 Heat Rise (
o
F) 46 47 48 50 51 53 55 57 59 61
Heat Rise (
o
C) 25 26 27 28 29 30 30 32 33 34
Medium
2
Red
CFM 1736 1710 1668 1630 1600 1557 1522 1479 1450 1406 BHP 0.53 0.54 0.55 0.58 0.59 0.60 0.62 0.63 0.64 0.65 Heat Rise (
o
F) 39 40 41 42 42 43 44 46 47 48
Heat Rise (
o
C) 22 22 23 23 23 24 25 25 26 27
M e d --- H i g h Orange
CFM 1935 1909 1867 1836 1808 1766 1696 1619 1535 1454 BHP 0.71 0.73 0.74 0.76 0.78 0.79 0.77 0.75 0.72 0.68 Heat Rise (
o
F) 35 35 36 37 37 38 40 42 44 47
Heat Rise (
o
C) 19 20 20 20 21 21 22 23 24 26
High Black
CFM 2205 2150 2078 2011 1941 1852 1779 1672 1572 1473 BHP 1.04 1.02 0.99 0.95 0.92 0.87 0.85 0.79 0.75 0.70 Heat Rise (
o
F) NA NA NA NA 35 37 38 40 43 46
Heat Rise (
o
C) NA NA NA NA 19 20 21 22 24 26
PGD4, PGS4, WPG4
