ICP PGD4 E Series - Page 35

46201200402 35
Specifications are subject to change without notice.
Table 10 -- Dry Coil Air Delivery* -- Horizontal and Downflow Discharge -- Sizes 24-- 60 208/230VAC -- 1 Phase (Cont.)
Unit
Size
Heating Rise
Range
o
F(
o
C)
Motor
Speed
Wire
Color
External Static Pressure (IN. W.C.)
0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1
60115
30 --- 60
( 17 --- 3 3)
Low
3
Blue
CFM 1330 1277 1232 1191 1147 1103 1060 1004 963 919 BHP 0.26 0.27 0.29 0.30 0.31 0.32 0.33 0.34 0.36 0.37 Heat Rise (
o
F) NA NA NA NA NA NA NA NA NA NA
Heat Rise (
o
C) NA NA NA NA NA NA NA NA NA NA
Med---Low Pink
CFM 1475 1436 1399 1351 1317 1270 1236 1188 1152 1105 BHP 0.35 0.36 0.37 0.38 0.40 0.41 0.42 0.43 0.45 0.45 Heat Rise (
o
F) 59 60 NA NA NA NA NA NA NA NA
Heat Rise (
o
C) 33 33 NA NA NA NA NA NA NA NA
Medium
2
Red
CFM 1736 1710 1668 1630 1600 1557 1522 1479 1450 1406 BHP 0.53 0.54 0.55 0.58 0.59 0.60 0.62 0.63 0.64 0.65 Heat Rise (
o
F) 50 51 52 53 54 56 57 58 60 NA
Heat Rise (
o
C) 28 28 29 29 30 31 32 32 33 NA
Med---High
1
Orange
CFM 1935 1909 1867 1836 1808 1766 1696 1619 1535 1454 BHP 0.71 0.73 0.74 0.76 0.78 0.79 0.77 0.75 0.72 0.68 Heat Rise (
o
F) 45 45 46 47 48 49 51 53 56 59
Heat Rise (
o
C) 25 25 26 26 27 27 28 30 31 33
High Black
CFM 2205 2150 2078 2011 1941 1852 1779 1672 1572 1473 BHP 1.04 1.02 0.99 0.95 0.92 0.87 0.85 0.79 0.75 0.70 Heat Rise (
o
F) 39 40 42 43 45 47 49 52 55 59
Heat Rise (
o
C) 22 22 23 24 25 26 27 29 31 33
PGD4, PGS4, WPG4
