ICP SAVANNAH XL User Manual

MAINTENANCE MANUAL
SAVANNAH VG AND
SAVANNAH XL
Doc. No.:
MM-SVNH-VG&XL-EN
Revision:
05
Rev. Date:
28/12/2022
Proj. Ref.:
Savannah Model 51
A/C: Savannah VG&XL
Applies to Generic Serial Number: yy-mm-51-xxx
Page:
14/24
OC FMM00
2.3. 100 hours / 12 months
CAUTION
To properly maintain the engine, it’s strongly recommended to follow the
engine manufacturer instructions and all Rotax service information
NOTE
The 100 hours/12 months inspection requires that a 50 hours inspection
(25 hours plus the 50 hours adding checks) is carried out plus the checks
below stated
N.
Description
1
Thoroughly check the nose landing gear steering and shock absorbing systems; recover
excessive plays as required
2
Check the integrity of the front wheel column
3
Thoroughly inspect the firewall for corrosion, cracks, security and general condition
4
Fuselage: carefully inspect the fuselage interior and exterior for loose rivets, unproperly
tightened bolts, corrosion and panel deformations which can be caused by excessive
dynamic loads or hits
5
Flight controls: check for excessive play, worn components, attachment fittings for condition
6
Check the movable surfaces travel stops
7
Check the flaperon attachment fittings
8
Wings and wing struts: thoroughly check the wing skin for loose rivets, corrosion, panels
deformation and damage, inspect the wing leading and trailing edges; check all the bolts
and safety locks
9
Empennages: thoroughly the empennages skin for loose rivets, corrosion, panels
deformation and damage, inspect the empennages leading and trailing edges; check all the
bolts and safety locks
10
Drain and refill the engine oil
11
Replace the oil filter
12
Check fuel main valve functionality:
 Brake air plane with the wedge and with brake pedals
 Start engine (3000 RPM) and close the fuel main valve (take out safety wire); wait until
engine stop
 Open the fuel main valve and make again the safety wire.
13
Check the ball joints of the flap control rod by removing the stud and checking the wear of
the ball joints, the absence of clearances, the integrity of the stud and the ovalization of the
holes which connect to the moving surfaces
14
Check the inflating pressure of the tires, the wear of the treads and the presence of cuts or
abrasions on the tire itself
15
Visually check that there are no leakages in the brake pumps and cylinders
16
Check the wear of the 4 silent blocks of the engine mounting and the silencer springs
17
Check the integrity of the fuel pipe and of the piping for the water and oil radiators, radiators
attachments and no leakage present. Inspect then the structure of the engine mounting
(status of the welds) and the attachment bolts to the firewall
