ICP SAVANNAH XL User Manual

MAINTENANCE MANUAL
SAVANNAH VG AND
SAVANNAH XL
Doc. No.:
MM-SVNH-VG&XL-EN
Revision:
05
Rev. Date:
28/12/2022
Proj. Ref.:
Savannah Model 51
A/C: Savannah VG&XL
Applies to Generic Serial Number: yy-mm-51-xxx
Page:
11/24
OC FMM00
2.2. 50 hours / 6 months
CAUTION
To properly maintain the engine, it’s strongly recommended to follow the
engine manufacturer instructions and all Rotax service information
N.
Description
1
Check the general conditions of the whole airframe
2
Remove all the engine cowlings
3
Check propeller for dents and cracks; check blades leading edge protection for condition;
NOTE
If some vibrations are noted the propeller shall be balanced
4
Check for presence and integrity of the safety nuts or the safety wire on the propeller’s hub
5
Check the tightening of the bolts of the propeller
6
Check throttle lever on firewall and in particular the welding on the levers
7
Check the radiator is fully accessible by the cooling air and the duct isn’t obstructed by
grass, leaves or other debris; check for coolant leaks, all the hoses and clamps are in place
and properly secured
8
Fuel system: visually inspect pipes, clamps, fuel filter, electric pump and mechanical pump;
clean and inspect float chambers and replace fuel filter if necessary
9
Check and lubricate throttle and mixture cables and linkages; if required, adjust engine idle
and idle carburation
10
Check the air hoses and air filters condition
11
Lubrication system: check for condition all pipes and clamps; check for the proper oil level,
refill if required
12
Cooling system: check for condition all pipes and clamps, coolant level and coolant level in
the coolant recovery reservoir, check all cooling system components are properly secured
13
Engine electrical system, ignition system: check for general condition, properly fastened
electrical connections, no damaged wires, no connections oxidation, etc.; check the ignition
harnesses be properly connected to the spark plugs
14
Check the engine silent-blocks, the engine and engine mount attachments
15
Check the exhaust system for cracks, loose fasteners, springs in place and oxidation
16
Thoroughly clean both the engine and its accessories
17
Check for condition of the air-box (if installed) and its supports
18
Check the nose gear elastic bungee and the sliding strut for excess of play, clean and
lubricate properly
19
Check the nose landing gear wheel and rudder alignment
20
Check and, if required, purge the brake control
21
Check the pedal rods and rod-ends; clean and lubricate properly
22
Lubricate the brake system cables, the brake pedals and the rudder pedals
23
Check the brakes operating effectiveness; clean or replace the pads as required
24
Open the inspection panel on the bottom of the fuselage
25
Check the battery for proper liquid level, drain pipe condition, corrosion due to acid spills
and for electrodes condition
