ID Tech MINIMAG User Manual

20
The last line will generate two formulas, one for Credit Card and the
other for DMV card.
Example Two:
/e/d/fn<CR>
/e/d/fe 10<CR>
/e/d/fr \cr<CR>
/e/d/fs c1a0101? d2b0101=0101=<CR>
/e/d/ft 7d1a0a2b0a<CR>
The first line “/e/d/fn<CR>” is to clear all previous settings.
The second line “/e/d/fe 10<CR>” is to enable the data editing and will
not send out original data if it does not match the formula.
The third line “/e/d/fr \cr<CR> is to create an added field, “field a” -
<CR>.
The fourth line “/e/d/fs c1a0101? d2b0101=0101=<CR>” will try to
generate two flexible fields as described in page19.
The last line will generate a single formula for “custom format”. Any
card data can be treated as a custom format as long as it does
not match any other format specified by other formula. Try your
DMV card will see the result, any card does not match the
formula will not be send.
The Flexible Field is:
7d1a0a2b0a
7d: Flexible format
1a: Track1 data before end sentinel (?)
0a: Added field a (<CR>)
2b: Track2 data between the first equal sign and the second equal sign
0a: Added field a (<CR>)
Data will be output as following(if matches the format) or nothing(if
does not match the format):
<Track1 data before end sentinel>
<Track2 date between the first “=” and the second “=”>

ID Tech MINIMAG Specifications

General

Interface	TTL
Scan speed (max)	76.2 mm/sec
Operating voltage	5 V
Power consumption	4 mA
LED indicators	Yes
Storage temperature (T-T)	-30 - 70 °C
Operating temperature (T-T)	0 - 55 °C
Cable length	1.8 m

Weight and Dimensions

Weight	130 g
Dimensions (WxDxH)	34 x 90 x 28 mm
