Appendix A. Default Settings Table
The MiniMag reader is shipped from the factory with the following
default settings already programmed:
Magnetic Track Basic Data Format
Track 1: <SS1><T
1
Data><ES><ENTER>*
Track 2: <SS2><T
2
Data><ES><ENTER>*
Track 3: <SS3><T
3
Data><ES><Enter>*
where: SS1(start sentinel track 1) = %
SS2(start sentinel track 2) = ;
SS3(start sentinel track 3) = ; for ISO, ! for CDL, %
for AAMVA
ES(end sentinel all tracks) = ?
Keyboard Wedge Communication Default Settings
Terminal type: IBM PC/AT
Intercharacter delay: 2 ms
Language: US English
Start or End Sentinel: Characters in encoding format which come
before the first data character (start) and after the last data character
(end), indicating the beginning and end, respectively, of data.
Track Separator: A designated character which separates data tracks.
Terminator: A designated character which comes at the end of the last
track of data, to separate card reads.
LRC: Check character, following end sentinel.
CDL: Old California Drivers License format.
*Note: The <ENTER> commands shown above for tracks 1 & 2 and 2 & 3
denote the default character for this position, the Track Separator position.
The <Enter> command shown for track 3 denotes the default character for
this position, the Terminator position.
